P0078 EVT CONTROL SOLENOID VALVEEC-225
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0078 EVT CONTROL SOLENOID VALVE
DTC LogicINFOID:0000000009462175
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-225, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462176
1.CHECK EXHAUST VALVE TIMING CONT ROL SOLENOID VALVE POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect exhaust valve timing (EVT) control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check the voltage between exhaust valve timing control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK EXHAUST VALVE TIMING CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between EVT control sol enoid valve harness connector and IPDM E/R harness con-
nector.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0078 EX V/T ACT/CIRC-B1
(Exhaust valve control solenoid cir-
cuit bank 1) An improper voltage is sent to the ECM
through exhaust valve timing control
solenoid valve. • Harness or connectors
(Exhaust valve timing control solenoid
valve circuit is open or shorted.)
• Exhaust valve timing control solenoid valve
+
−Vo l ta g e
EVT control solenoid valve
Connector Terminal F80 1 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1226 of 4801
![NISSAN TEANA 2014 Service Manual
EC-226
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0078 EVT CONTROL SOLENOID VALVE
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power s NISSAN TEANA 2014 Service Manual
EC-226
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0078 EVT CONTROL SOLENOID VALVE
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power s](/manual-img/5/57390/w960_57390-1225.png)
EC-226
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0078 EVT CONTROL SOLENOID VALVE
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK EXHAUST VALVE TIMING CONT ROL SOLENOID VALVE GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVT control solenoid valve harness connector and ECM harness connec-
tor.
*1: Except for California
*2: For California
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK EXHAUST VALVE TIMING CONTROL SOLENOID VALVE
Check the exhaust valve timing control solenoid valve. Refer to EC-214, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace exhaust valve timing control solenoid valve.
Component InspectionINFOID:0000000009462177
1.CHECK EXHAUST VALVE TIMING CONTROL SOLENOID VALVE-1
1. Turn ignition switch OFF.
2. Disconnect exhaust valve timing control solenoid valve harness connector.
3. Check resistance between exhaust valve timing control solenoid valve terminals as per the following.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace exhaust valve timing control solenoid valve. Refer to EM-61, "Exploded View"
.
2.CHECK EXHAUST VALVE TIMING CONTROL SOLENOID VALVE-2
++
Continuity
EVT control solenoid valve IPDM E/R
Connector Terminal Connector Terminal F801F8359Existed
++ Continuity
EVT control solenoid valve ECM
Connector Terminal Connector Terminal
F80 2 F13
*1
F90*294 Existed
Exhaust valve timing control solenoid valve
Resistance
+ −
Te r m i n a l
1 2 7.0 - 7.7 Ω [at 20 °C (68 °F)]
1 Ground ∞
Ω
(Continuity should not exist)
2
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1227 of 4801
P0078 EVT CONTROL SOLENOID VALVEEC-227
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Remove exhaust valve timing control solenoid valve. Refer to
EM-61, "Exploded View".
2. Provide 12 V DC between exhaust valve timing control solenoid valve terminals 1 and 2, and then interrupt it. Check that the
plunger moves as shown in the figure.
CAUTION:
Do not apply 12 V DC continuously for 5 seconds or more.
Doing so may result in damage to the coil in exhaust valve
timing control solenoid valve.
NOTE:
Always replace O-ring when exhaust valve timing control
solenoid valve is removed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace exhaust valve timing control solenoid valve. Refer to EM-61, "Exploded View"
.
JMBIA0079ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1228 of 4801
![NISSAN TEANA 2014 Service Manual
EC-228
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
P0101 MAF SENSOR
DTC LogicINFOID:0000000009462178
DTC DETECTION LOGIC
NOTE:
If DTC P0101 is displayed with other DTC, fi rst perform the tro NISSAN TEANA 2014 Service Manual
EC-228
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
P0101 MAF SENSOR
DTC LogicINFOID:0000000009462178
DTC DETECTION LOGIC
NOTE:
If DTC P0101 is displayed with other DTC, fi rst perform the tro](/manual-img/5/57390/w960_57390-1227.png)
EC-228
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
P0101 MAF SENSOR
DTC LogicINFOID:0000000009462178
DTC DETECTION LOGIC
NOTE:
If DTC P0101 is displayed with other DTC, fi rst perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC CONFIRMATION PROCEDURE has been previously conducted, always perform the following proce-
dure before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Drive the vehicle for at least 5 seconds under the following conditions: CAUTION:
Always drive vehicle at safe speed.
NOTE:
• The gear must be fixed while driving the vehicle.
• Keep the accelerator pedal as st eady as possible during cruising.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-228, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462179
1.CHECK INTAKE SYSTEM
Check the following for connection.
• Air duct
• Vacuum hoses
• Intake air passage between air duct and intake manifold
Is the inspection result normal?
YES >> GO TO 2.
NO >> Reconnect the parts.
2.CHECK MASS AIR FLOW (M AF) SENSOR POWER SUPPLY
DTC No.CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0101 MAF SEN/CIRCUIT-B1
(Mass or volume air Flow ″A ″
circuit range/performance) • A high voltage from the sensor is sent to
ECM under light load driving condition.
• A low voltage from the sensor is sent to ECM under heavy load driving condition. • Harness or connectors
(MAF sensor circuit is open or short-
ed.)
• Intake air leaks
• MAF sensor
• EVAP control system pressure sensor
• Intake air temperature sensor
• Sensor power supply 2 circuit
Selector lever Suitable position
Vehicle speed 40 km/h (25 MPH) or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1229 of 4801
![NISSAN TEANA 2014 Service Manual
P0101 MAF SENSOREC-229
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch OFF.
2. Disconnect MAF sensor harness connector.
3. Turn ignition switch ON.
4. C NISSAN TEANA 2014 Service Manual
P0101 MAF SENSOREC-229
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch OFF.
2. Disconnect MAF sensor harness connector.
3. Turn ignition switch ON.
4. C](/manual-img/5/57390/w960_57390-1228.png)
P0101 MAF SENSOREC-229
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Turn ignition switch OFF.
2. Disconnect MAF sensor harness connector.
3. Turn ignition switch ON.
4. Check the voltage between MAF sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY 2 CIRCUIT
Perform EC-525, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
4.CHECK MAF SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between MAF sensor harness connector and ECM harness connector.
*1: Except for California
*2: For California
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK MAF SENSOR INPUT SIGNAL CIRCUIT
1. Check the continuity between MAF sensor harness connector and ECM harness connector.
*1: Except for California
*2: For California
2. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace error-detected parts
6.CHECK INTAKE AIR TEMPERATURE SENSOR
Check the intake air temperature sensor. Refer to EC-240, "Component Inspection"
.
+
−Vo l ta g e
MAF sensor
Connector Terminal F31 6 Ground 5 V
+ −
Continuity
MAF sensor ECM
Connector Terminal Connector Terminal
F31 5 F14
*1
F91*234 Existed
+
−
Continuity
MAF sensor ECM
Connector Terminal Connector Terminal
F31 4 F14
*1
F91*235 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1230 of 4801
![NISSAN TEANA 2014 Service Manual
EC-230
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace MAF sensor (with intake air temperature sensor). Refer to EM-29, "Exploded V NISSAN TEANA 2014 Service Manual
EC-230
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace MAF sensor (with intake air temperature sensor). Refer to EM-29, "Exploded V](/manual-img/5/57390/w960_57390-1229.png)
EC-230
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0101 MAF SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace MAF sensor (with intake air temperature sensor). Refer to EM-29, "Exploded View"
.
7.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR
Check the EVAP control system pressure sensor. Refer to EC-361, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace EVAP control system pressure sensor. Refer to FL-18, "Removal and Installation"
.
8.CHECK MAF SENSOR
Check the MAF sensor. Refer to EC-230, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace MAF sensor. Refer to EM-29, "Exploded View"
.
Component InspectionINFOID:0000000009462180
1.CHECK MASS AIR FLOW SENSOR-1
With CONSULT
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Start engine and warm it up to normal operating temperature.
4. Connect CONSULT and select “DATA MONITOR” mode of “ENGINE”.
5. Select “MAS A/F SE-B1” and check indication.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK FOR THE CAUSE OF UNEVEN AIR FL OW THROUGH MASS AIR FLOW SENSOR
1. Turn ignition switch OFF.
2. Check for the cause of uneven air flow through mass air flow sensor. Refer to the following.
- Crushed air ducts
- Malfunctioning seal of air cleaner element
- Uneven dirt of air cleaner element
- Intake valve deposits
- Improper specification of intake air system parts
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK MASS AIR FLOW SENSOR-2
With CONSULT
1. Repair or replace malfunctioning part.
2. Start engine and warm it up to normal operating temperature.
3. Connect CONSULT and select “DATA MONITOR” mode of “ENGINE”.
4. Select “MAS A/F SE-B1” and check indication.
Monitor item Condition MAS A/F SE-B1
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 1.3 V
Idle (Engine is warmed-up to normal operating temper-
ature.) 1.3- 1.6 V
2,500 rpm (Engine is warmed-up to normal operating
temperature.) 1.8 - 2.2 V
Idle to about 4,000 rpm 1.3 - 1.6 V to Approx. 2.5 V*
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1231 of 4801
![NISSAN TEANA 2014 Service Manual
P0101 MAF SENSOREC-231
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection NISSAN TEANA 2014 Service Manual
P0101 MAF SENSOREC-231
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection](/manual-img/5/57390/w960_57390-1230.png)
P0101 MAF SENSOREC-231
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 4.
4.CHECK MASS AIR FLOW SENSOR-3
With CONSULT
1. Turn ignition switch OFF.
2. Disconnect mass air flow sensor har ness connector and reconnect it again.
3. Start engine and warm it up to normal operating temperature.
4. Connect CONSULT and select “DATA MONITOR” mode of “ENGINE”.
5. Select “MAS A/F SE-B1” and check indication.
*: Check for linear voltage rise in response to engine being increased to about 4,000 rpm.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Clean or replace mass air flow sensor. Refer to EM-29, "Exploded View"
.
Monitor item Condition MAS A/F SE-B1
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 1.3 V
Idle (Engine is warmed-up to normal operating temper-
ature.) 1.3 - 1.6 V
2,500 rpm (Engine is warmed-up to normal operating
temperature.) 1.8 - 2.2 V
Idle to about 4,000 rpm 1.3 - 1.6 V to Approx. 2.5 V*
Monitor item Condition MAS A/F SE-B1
MAS A/F SE-B1 Ignition switch ON (Engine stopped.) Approx. 1.3 V
Idle (Engine is warmed-up to normal operating temper-
ature.) 1.3 - 1.6 V
2,500 rpm (Engine is warmed-up to normal operating
temperature.) 1.8 - 2.2 V
Idle to about 4,000 rpm 1.3 - 1.6 V to Approx. 2.5 V*
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1232 of 4801
![NISSAN TEANA 2014 Service Manual
EC-232
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0102, P0103 MAF SENSOR
P0102, P0103 MAF SENSOR
DTC LogicINFOID:0000000009462181
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Conf NISSAN TEANA 2014 Service Manual
EC-232
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0102, P0103 MAF SENSOR
P0102, P0103 MAF SENSOR
DTC LogicINFOID:0000000009462181
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Conf](/manual-img/5/57390/w960_57390-1231.png)
EC-232
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0102, P0103 MAF SENSOR
P0102, P0103 MAF SENSOR
DTC LogicINFOID:0000000009462181
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
Which DTC is detected?
P0102 >> GO TO 2.
P0103 >> GO TO 3.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P0102
1. Start engine and wait at least 5 seconds.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-232, "Diagnosis Procedure".
NO >> INSPECTION END
3.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P0103-1
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-232, "Diagnosis Procedure".
NO >> GO TO 4.
4.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P0103-2
1. Start engine and wait at least 5 seconds.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-232, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462182
1.INSPECTION START
Confirm the detected DTC.
Which DTC is detected?
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0102 MAF SEN/CIRCUIT-B1
(Mass or volume air flow ″A ″
circuit low) An excessively low voltage from the mass air
flow sensor is sent to ECM. • Harness or connectors
(Mass air flow sensor circuit is open or
shorted.)
• Intake air leaks
• Mass air flow sensor
• Sensor power supply 2 circuit
P0103 MAF SEN/CIRCUIT-B1
(Mass or volume air flow ″A ″
circuit high) An excessively high voltage from the mass air
flow sensor is sent to ECM. • Harness or connectors
(Mass air flow sensor circuit is open or
shorted.)
• Mass air flow sensor
• Sensor power supply 2 circuit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
