PWO-6
< REMOVAL AND INSTALLATION >
POWER SOCKET
REMOVAL AND INSTALLATION
POWER SOCKET
Removal and InstallationINFOID:0000000009460698
FRONT POWER SOCKET OR FRONT CONSOLE POWER SOCKET
NOTE:
If unable to use the Tool because of the power socke t location or access to the harness connector, then
removal of interior components may be required. Refer to IP-18, "Removal and Installation"
(Front Power
Socket) or IP-18, "Removal and Installation"
(Front Console Power Socket).
Removal
1. Remove the fuse for the power socket.
2. Insert one end of the Tool (A) into one of the square holes inside the power socket.
3. Lift up the handle of the Tool until the other side snaps into the other square hole in the power socket.
4. Pull the power socket straight out with the Tool.
5. Disconnect harness connector from the power socket.
6. Remove ring from power socket finisher while pressing the pawls.
Installation
Installation is in the reverse order of removal.
NOTE:
Make sure to align the tab with the square notched area during
installation. Tool number: — (J-42059)
AWMIA1182GB
WKIA1035E
AWMIA1183GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3658 of 4801

RAX-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION RAX
A
B
RAX
N
O P
CONTENTS
REAR AXLE
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
General Precautions .................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Commercial Service Tool .................................... ......3
SYMPTOM DIAGNOSIS ...............................4
NOISE, VIBRATION, AND HARSH-
NESS(NVH) TROUBLESHOOTING ............... .....
4
NVH Troubleshooting Chart ................................ ......4
PERIODIC MAINTENANCE .........................5
WHEEL HUB ......................................................5
On-vehicle Service .............................................. .....5
REMOVAL AND INSTALLATION ................6
WHEEL HUB ......................................................6
Exploded View ..................................................... .....6
Removal and Installation ..........................................6
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... ..............................................
8
SERVICE DATA AND SPECIFICATIONS
(SDS) ..................................................................
8
Wheel Hub Bearing ............................................. .....8
Revision: November 20132014 Altima NAM
Page 3659 of 4801

RAX-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951702
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
General PrecautionsINFOID:0000000009460673
• When installing each rubber part, final tightening must be carried out under unladen condition* with
tires on ground.
*: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated posi-
tions.
• After installing removed suspensi on parts, check wheel alignment.
• Do not jack up at the trailing arm and lateral link.
Revision: November 20132014 Altima NAM
Page 3660 of 4801
PREPARATIONRAX-3
< PREPARATION >
CEF
G H
I
J
K L
M A
B
RAX
N
O P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000009460675
Tool name Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: November 20132014 Altima NAM
Page 3661 of 4801
RAX-4
< SYMPTOM DIAGNOSIS >
NOISE, VIBRATION, AND HARSHNESS(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS(NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000009460674
Use the chart below to help you find the cause of the sy mptom. If necessary, repair or replace these parts.
×: ApplicableReference page
RAX-6, "Removal and Installation"RAX-6, "Removal and Installation"RAX-6, "Removal and Installation"WT-52, "NVH Troubleshooting Chart"WT-52, "NVH Troubleshooting Chart"
Possible cause and SUSPECTED PARTS
Improper installation, looseness
Parts interference
Wheel bearing damage
TIRES
ROAD WHEEL
Symptom REAR AXLE Noise
×× ××
Shake ×× ××
Vibration ×× ×
Shimmy ×× ××
Shudder ×××
Poor quality ride or handling × × ×××
Revision: November 20132014 Altima NAM
Page 3662 of 4801
WHEEL HUBRAX-5
< PERIODIC MAINTENANCE >
CEF
G H
I
J
K L
M A
B
RAX
N
O P
PERIODIC MAINTENANCE
WHEEL HUB
On-vehicle ServiceINFOID:0000000009460676
Check axle and suspension parts for excessive play, wear or damage.
