2014 NISSAN TEANA Service Manual

bonnet catalytic converter fuel tank removal buttons gearbox spare tire

Page 4169 of 4801

NISSAN TEANA 2014 Service Manual
STC-18
< WIRING DIAGRAM >
HYDRAULIC PUMP ELECTRIC POWER STEERING SYSTEM
ABGIA0100GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4170 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS AND REPAIR WORK FLOWSTC-19
< BASIC INSPECTION >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000009460354
DETAILED FLOW
1.INTERVIE

DIAGNOSIS AND REPAIR WORK FLOWSTC-19
< BASIC INSPECTION >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000009460354
DETAILED FLOW
1.INTERVIEW FROM THE CUSTOMER
Clarify customer complaints before inspection. First of all, perform an interview utilizing STC-20, "Diagnostic
Work Sheet" and reproduce symptoms to understand them fully. A sk customer about his/her complaints care-
fully. Check symptoms by driving v ehicle with customer, if necessary.
CAUTION:
Customers are not professional. Never make assumpti ons like “maybe the customer means that...,” or
“maybe the customer mentioned this symptom”.
>> GO TO 2.
2.CHECK SYMPTOM
Reproduce the symptom that is indicated by the cu stomer, based on the information from the customer
obtained by interview. Also check that the symptom is not caused by protection function. Refer to STC-12,
"Protection Function".
CAUTION:
When the symptom is caused by normal operation, fully inspect each portion and obtain the under-
standing of customer that the symptom is not caused by a malfunction.
>> GO TO 3.
3.CHECK VEHICLE CONDITION
With CONSULT
1. Turn ignition switch ON.
2. Check “C/U TEMP“ and “C/U TEMP A“ in “DATA MONITOR“ of “EPS“.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Wait with the ignition switch OFF until the data monitor indication becomes 90 °C (194 °F) or less.
Go to 4 after the temperature drops to 90 °C (194 °F) or less.
4.PERFORM SELF-DIAGNOSIS
With CONSULT
Perform self-diagnosis.
Is any DTC detected?
YES >> Record or print DTC and freeze frame data (FFD). GO TO 5.
NO >> GO TO 7.
5.RECHECK SYMPTOM
With CONSULT
1. Erase self-diagnostic results for “EPS”.
2. Perform DTC confirmation procedures for the malfunctioning system.
NOTE:
If some DTCs are detected at the same time, determine the order for performing the diagnosis based on STC-
13, "DTC Inspection Priority Chart".
Is any DTC detected?
Monitor item Values
C/U TEMP 90 °C (194 °F) or less
C/U TEMP A 90 °C (194 °F) or less
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4171 of 4801

NISSAN TEANA 2014 Service Manual
STC-20
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
YES >> GO TO 6.
NO >> Check harness and connectors based on the information obtained by interview.
6.REPAIR OR REPLACE THE MALFUNCTIONING C

STC-20
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
YES >> GO TO 6.
NO >> Check harness and connectors based on the information obtained by interview.
6.REPAIR OR REPLACE THE MALFUNCTIONING COMPONENTS.
• Repair or replace the malfunctioning components.
• Reconnect part or connector after repairing or replacing.
• When DTC is detected, erase self-diagnostic results for “EPS”.
>> GO TO 8.
7.IDENTIFY THE MALFUNCTIONING SYSTEM BY SYMPTOM DIAGNOSIS
Estimate the malfunctioning system based on symptom diagnosis and perform inspection.
Can the malfunctioning system be identified?
YES >> GO TO 8.
NO >> Check harness and connectors based on the information obtained by interview.
8.FINAL CHECK
With CONSULT
1. Check the reference value for power steering control module.
2. Recheck the symptom and check that sympto m is not reproduced on the same conditions.
Is the symptom reproduced?
YES >> GO TO 3.
NO >> Inspection End.
Diagnostic Work SheetINFOID:0000000009460355
Description
• In general, customers have their own criteria for a pr oblem. Therefore, it is important to understand the
symptom and status well enough by asking the customer about his/her concerns carefully. To systemize all
the information for the diagnosis, prepare the interview sheet referring to the interview points.
• In some cases, multiple conditions that appear simultaneously may cause a DTC to be detected.
Interview sheet sample
Interview sheet
Customer
name MR/MSRegistration
number Initial year
registration
Vehicle type VIN
Storage date Engine Mileage km (Mile)
Symptom †
The steering wheel position (center) is in the wrong position.
† Warning lamp turns on.
† Noise †Vibration
† Others
( )
First occurrence †Recently †Others ( )
Frequency of occurrence †Always †Under a certain conditions of †Sometimes (time(s)/day)
Climate con-
ditions †
Irrelevant
Weather †Fine †Cloud †Rain †Snow †Others ( )
Temperature †Hot †Warm †Cool †Cold †Temperature [Approx. °C ( °F)]
Relative humidity †High †Moderate †Low
Road conditions †
Urban area †Suburb area †High way
† Mountain road (uphill or down hill) †Rough road
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4172 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS AND REPAIR WORK FLOWSTC-21
< BASIC INSPECTION >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
Operation conditions, etc. �†
Irrelevant
�† When engine starts �†During idling
�† During driving

Page 4173 of 4801

NISSAN TEANA 2014 Service Manual
STC-22
< DTC/CIRCUIT DIAGNOSIS >
C1143 STEERING ANGLE SENSOR
DTC/CIRCUIT DIAGNOSIS
C1143 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009460356
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECO

Page 4174 of 4801

NISSAN TEANA 2014 Service Manual
C1601 BATTERY POWER SUPPLYSTC-23
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
C1601 BATTERY POWER SUPPLY
DTC LogicINFOID:0000000009460358
DTC DETECTION LOGIC
DTC CONFIRMATION PROCED

C1601 BATTERY POWER SUPPLYSTC-23
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
C1601 BATTERY POWER SUPPLY
DTC LogicINFOID:0000000009460358
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC CONFIRMATION PROCEDURE has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform EPS self-diagnosis.
Is DTC
“C1601” detected?
YES >> Proceed to diagnosis procedure. Refer to STC-23, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009460359
Regarding Wiring Diagram information, refer to STC-14, "Wiring Diagram".
1.CHECK POWER STEERING CONTROL MODULE GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power steering control module harness connector.
3. Check continuity between power steering control module harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit or short to ground or short to power in harness or connectors, and repair or
replace the malfunctioning component.
2.CHECK POWER STEERING CONTROL MO DULE POWER SUPPLY CIRCUIT (1)
1. Check voltage between power steering control module harness connector terminals and ground.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Check voltage between power steering control module harness connector terminals and ground.
DTC Display item Malfunction detected condition Possible cause
C1601 BATTERY VOLT When a power supply voltage to the power steer-
ing control module is maintained at 18.5 V or more
or at less than 8.5 V continuously for 0.5 seconds
or more. • Harness or connector
• Power steering control mod-
ule
•Fuse
• Battery power supply circuit
•Battery
Power steering control module
—Continuity
Connector Terminal
E60 2 Ground Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4175 of 4801

NISSAN TEANA 2014 Service Manual
STC-24
< DTC/CIRCUIT DIAGNOSIS >
C1601 BATTERY POWER SUPPLY
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK POWER STEERING CONTROL MODULE POWER SUPPLY CIRCUIT (2)
1. Turn ig

STC-24
< DTC/CIRCUIT DIAGNOSIS >
C1601 BATTERY POWER SUPPLY
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK POWER STEERING CONTROL MODULE POWER SUPPLY CIRCUIT (2)
1. Turn ignition switch OFF.
2. Check the 100A fusible link (D).
3. Disconnect battery terminal with fusible link harness connector.
4. Check continuity between power steering contro l module harness connector terminal and battery terminal
with fusible link harness connector terminal.
5. Check continuity between power steering c ontrol module harness connector terminal and ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for battery power supply circuit. Refer to PG-8, "Wiring Diagram —
Battery Power Supply —".
NO >> Repair or replace the malfunctioning component.
4.CHECK POWER STEERING CONTROL MODULE POWER SUPPLY CIRCUIT (3)
1. Check voltage between power steering control module harness connector terminals and ground.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Check voltage between power steering control module harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK POWER STEERING CONTROL MODULE POWER SUPPLY CIRCUIT (4)
1. Turn ignition switch OFF.
2. Check the 10A fuse No. 49 in the IPDM E/R.
3. Disconnect IPDM E/R harness connector E63.
4. Check continuity between power steering control module harness connector terminal and IPDM E/R har-
ness connector terminal.
Power steering control module — Ignition Voltage
Connector Terminal
E60 1 Ground ON Battery voltage
Power steering control module Batte ry terminal with fusible link
Continuity
Connector Terminal Connector Terminal
E60 1 E5 3 Yes
Power steering control module — Ignition Continuity
Connector Terminal
E60 1 Ground ON No
Power steering control module —Voltage
Connector Terminal
E59 5 Ground 0 V
Power steering control module —Voltage
Connector Terminal
E59 5 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4176 of 4801

NISSAN TEANA 2014 Service Manual
C1601 BATTERY POWER SUPPLYSTC-25
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
5. Check continuity between power steering control module harness connector terminal and ground.
Is the
