NISSAN TEANA 2014 Service Manual
PWC-102
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Rear Power Window Switch Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
Check voltage between rea

PWC-102
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Rear Power Window Switch Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
Check voltage between rear power window switch connector and ground.
Is the inspection result normal?
YES >> GO TO 2 (Rear power window switch LH).
YES >> GO TO 3 (Rear power window switch RH).
NO >> GO TO 4.
2. CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unloc k switch and rear power window switch LH.
3. Check continuity between main power window and door lock/unlock switch connector D7 and rear power window switch LH connector D203.
4. Check continuity between main power window and door lock/unlock switch connector D7 and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
3. CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and rear power window switch RH.
3. Check continuity between main power window and door lock/unlock switch connector D7 and rear power window switch RH connector D303.
4. Check continuity between main power window and door lock/unlock switch connector D7 and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
Te r m i n a l
ConditionVo l ta g e
(Approx.)
(+)
(–)
Rear power window
switch connector Te r m i n a l
LH D203 4 Ground Ignition switch ON Battery voltage
RH D303
Main power window and door lock/
unlock switch connector Te r m i n a lRear power window switch LH
connector Terminal Continuity
D7 8
D203 7
Ye s
98
Main power window and door lock/unlock switch connector Terminal GroundContinuity
D7 8
No
9
Main power window and door lock/
unlock switch connector Te r m i n a lRear power window switch RH
connector Terminal Continuity
D7 6
D303 7
Ye s
78
Main power window and door lock/unlock switch con- nector Te r m i n a l
Ground Continuity
D7 6
No
7
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3610 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-103
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
4. CHECK HARNESS CONTINUITY
1. Disconnect BCM and rear power window swi

Page 3611 of 4801

NISSAN TEANA 2014 Service Manual
PWC-104
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
YES >> Rear power window switch RH is OK.
NO >> Replace rear power window switch. Refer to PWC-144, "Remo

Page 3612 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-105
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW MOTOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000009460926
Door

Page 3613 of 4801

NISSAN TEANA 2014 Service Manual
PWC-106
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to
PWC-142, "Remov

PWC-106
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to
PWC-142, "Removal and
Installation". After that, refer to PWC-106, "DRIVER SIDE : Special Repair Requirement".
NO >> Repair or replace the harness or connectors.
3. CHECK POWER WINDOW MOTOR
Check front power window motor LH.
Refer to PWC-106, "DRIVER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace power window motor LH. Refer to GW-16, "Removal and Installation - Front Regulator"
.
After that, refer to PWC-106, "DRIVER SIDE : Special Repair Requirement"
.
DRIVER SIDE : Comp onent InspectionINFOID:0000000009460929
COMPONENT INSPECTION
1. CHECK FRONT POWER WINDOW MOTOR LH
Check motor operation by connecti ng the battery voltage directly to power window motor D9.
Is the inspection result normal?
YES >> Front power window motor LH is OK.
NO >> Replace front power window motor LH. Refer to GW-16, "Removal and Installation - Front Regula-
tor". After that, refer to PWC-106, "DRIVER SIDE : Special Repair Requirement".
DRIVER SIDE : Specia l Repair RequirementINFOID:0000000009460930
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-113, "DRIVER SIDE : Component Function Check"
.
PASSENGER SIDE
Main power window and door lock/unlock switch
connector Te r m i n a l
GroundContinuity
D8 17
No
19
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3614 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-107
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
PASSENGER SIDE : DescriptionINFOID:0000000009460931
Door glass moves UP/DOWN by rece

POWER WINDOW MOTORPWC-107
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
PASSENGER SIDE : DescriptionINFOID:0000000009460931
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
power window and door lock/unlock switch RH.
PASSENGER SIDE : Comp onent Function CheckINFOID:0000000009460932
1. CHECK POWER WINDOW MOTOR CIRCUIT
Check power window motor operation with operating main power window and door lock/unlock switch or
power window and door lock/unlock switch RH.
Is the inspection result normal?
YES >> Front power window motor RH is OK.
NO >> Refer to PWC-107, "PASSENGER SIDE : Diagnosis Procedure"
.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000009460933
Regarding Wiring Diagram information, refer to PWC-83, "Wiring Diagram - With Left And Right Front Power
Window Anti-Pinch".
Front Power Window Motor RH Circuit Check
1. CHECK FRONT POWER WINDOW SWITCH RH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH.
3. Turn ignition switch ON.
4. Check voltage between front power window motor RH connector D104 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between power window and door lock/unlock switch RH connector D105 and front power window motor RH connector D104.
4. Check continuity between power window and door lock/unlock switch RH connector D105 and ground.
Te r m i n a l
Front power window motor RH condition Vo l ta g e
(Approx.)
(+)
(–)
Front power window motor RH
connector Te r m i n a l
D104 1
Ground UP Battery voltage
DOWN 0
3 UP 0
DOWN Battery voltage
Power window and door lock/un- lock switch RH connector Te r m i n a l
Front power window motor RH
connector Terminal Continuity
D105 11
D104 1
Ye s
12 3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3615 of 4801

NISSAN TEANA 2014 Service Manual
PWC-108
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to
PWC-143, "Removal

PWC-108
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER WINDOW MOTOR
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to
PWC-143, "Removal and Instal-
lation". After that, refer to PWC-108, "PASSENGER SIDE : Special Repair Requirement".
NO >> Repair or replace harness or connectors.
3. CHECK FRONT POWER WINDOW MOTOR RH
Check front power window motor RH.
Refer to PWC-108, "PASSENGER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator". After that, refer to PWC-108, "PASSENGER SIDE : S pecial Repair Requirement".
PASSENGER SIDE : Component InspectionINFOID:0000000009460934
COMPONENT INSPECTION
1. CHECK FRONT POWER WINDOW MOTOR RH
Check motor operation by connecting the battery voltage directly to front power window motor RH D104.
Is the inspection result normal?
YES >> Front power window motor RH is OK.
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator". After that, refer to PWC-108, "PASSENGER SIDE : S pecial Repair Requirement".
PASSENGER SIDE : Special Repair RequirementINFOID:0000000009460935
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-115, "PASSENGER SIDE : Component Function Check"
.
REAR LH
Power window and door lock/unlock switch RH
connector Te r m i n a l
Ground Continuity
D105 11
No
12
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3616 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-109
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR LH : DescriptionINFOID:0000000009460936
Door glass moves UP/DOWN by receiving t
