DIAGNOSIS SYSTEM (ECM)EC-609
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: The item is indicated, but not used.
NOTE:
Any monitored item that does not match the vehicle being

DIAGNOSIS SYSTEM (ECM)EC-609
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: The item is indicated, but not used.
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
WORK SUPPORT MODE
Work Item
A/F SEN1 DIAG3(B1)ABSNT/
PRSNT Indicates DTC P014C, P014D,
P015A or P015B self-diagnosis con-
dition.
• ABSNT: The vehicle condition is not within the diagnosis range.
• PRSNT: The vehicle condition is within the diagnosis range.
HO2 S2 DIAG2(B2) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(slow responce ) condition.
• INCMP: Self-diagnosis is incom- plete.
• CMPLT: Self-diagnosis is com-
plete.
HO2 S2 DIAG2(B1) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(slow responce ) condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
EOP SENSOR mV The signal voltage of EOP sensor is
displayed.
HO2 S2 DIAG1(B1) INCMP/
CMPLT Indicates DTC P0139 self-diagnosis
(delayed responce) condition.
• INCMP: Self-diagnosis is incom-
plete.
• CMPLT: Self-diagnosis is com- plete.
A/F-S ATMSPHRC
CRCT B1 — Displays a determined value of at-
mospheric correction factor neces-
sary for correcting an A/F sensor
signal input to ECM. The signal used
for the correction is an A/F sensor
signal transmitted while driving un-
der atmospheric pressure.
A/F-S ATMSPHRC
CRCT B2 — Displays a determined value of at-
mospheric correction factor neces-
sary for correcting an A/F sensor
signal input to ECM. The signal used
for the correction is an A/F sensor
signal transmitted while driving un-
der atmospheric pressure.
A/F-S ATMSPHRC
CRCT UP B1 count Displays the number of updates of
the A/F sensor atmospheric correc-
tion factor.
A/F-S ATMSPHRC
CRCT UP B2 count Displays the number of updates of
the A/F sensor atmospheric correc-
tion factor.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1610 of 4801

NISSAN TEANA 2014 Service Manual
EC-610
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
*: This function is not necessary in the usual service procedure.
ACTIVE TEST MODE
Test Item
WORK ITEM CONDITION USAGE
IDLE AIR VOL LEA

EC-610
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
*: This function is not necessary in the usual service procedure.
ACTIVE TEST MODE
Test Item
WORK ITEM CONDITION USAGE
IDLE AIR VOL LEARN The idle air volume that keeps the engine within the specified range is memorized in ecm. When learning the idle air volume
EVAP SYSTEM CLOSE Close the EVAP canister vent control valve in order to make
EVAP system close under the following conditions.
• Ignition switch ON
• Engine not running
• Ambient temperature is above 0 °C (32 °F).
• No vacuum and no high pressure in EVAP system
• Fuel tank temperature is more than 0 °C (32 °F).
• Within 10 minutes after starting “EVAP SYSTEM CLOSE”
• When trying to execute “EVAP SYSTEM CLOSE” under
the condition except above, CONSULT will discontinue it
and display appropriate instruction.
NOTE:
When starting engine, CONSULT may display “BAT-
TERY VOLTAGE IS LOW. CHARGE BATTERY”, even in
using charged battery. When detecting EVAP vapor leak-
age in the EVAP system
FUEL PRESSURE RELEASE Fuel pu mp will stop by touching “START” during idling.
crank a few times after engine stalls. When releasing fuel pressure from
fuel line
SELF-LEARNING CONT The coefficient of self-learning control mixture ratio returns to the original coefficient. When clearing mixture ratio self-
learning value
TARGET IGN TIM ADJ* Idle condition When adjusting target ignition tim- ing
TARGET IDLE RPM ADJ* Idle condition When setting target idle speed
VIN REGISTRATION In this mode, VIN is registered in ECM When registering VIN in ECM
CLSD THL POS LEARN Ignition on and engine stopped. When learning the throttle valve
closed position
SAVING DATA FOR REPLC CPU In this mode, save data that is in ECM. When ECM replaced.
WRITING DATA FOR REPLC CPU In this mode, write data stored by “SAVING DATA FOR RE-
PLC CPU” in work support mode to ECM. When ECM replaced.
TEST ITEM CONDITION JUDGMENT CHECK ITEM (REMEDY)
FUEL INJEC-
TION • Engine: Return to the original
non-standard condition
• Change the amount of fuel injec- tion using CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. • Harness and connectors
• Fuel injector
• Air fuel ratio (A/F) sensor 1
ENG COOLANT
TEMP • Engine: Return to the original
non-standard condition
• Change the engine coolant tem- perature using CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. • Harness and connectors
• Engine coolant temperature sen-
sor
• Fuel injector
PURG VOL
CONT/V • Engine: After warming up, run en-
gine at 1,500 rpm.
• Change the EVAP canister purge volume control solenoid valve
opening percent using CON-
SULT. Engine speed changes according to
the opening percent. • Harness and connectors
• Solenoid valve
FUEL/T TEMP
SEN • Change the fuel tank temperature using CONSULT.
ALTERNATOR
DUTY •Engine: Idle
• Change duty ratio using CON-
SULT. Battery voltage changes.
• Harness and connectors
• IPDM E/R
•Alternator
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1611 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS SYSTEM (ECM)EC-611
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: Leaving cooling fan OFF with CONSULT while engine is running may cause the engine to overheat.
DTC WOR

DIAGNOSIS SYSTEM (ECM)EC-611
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*: Leaving cooling fan OFF with CONSULT while engine is running may cause the engine to overheat.
DTC WORK SUPPORT MODE
Test Item
FUEL PUMP RE-
LAY • Ignition switch: ON (Engine
stopped)
• Turn the fuel pump relay “ON” and “OFF” using CONSULT and
listen to operating sound. Fuel pump relay makes the operat-
ing sound. • Harness and connectors
• Fuel pump relay
VIAS S/V-1 • Ignition switch: ON
• Turn solenoid valve “ON” and “OFF” using CONSULT and listen
to operating sound. Solenoid valve makes the operating
sound. • Harness and connectors
• Solenoid valve
ENGINE
MOUNTING • Ignition switch: ON
• Turn electronic controlled engine mount “IDLE” and “TRVL” with
CONSULT. Electronic controlled engine mount
makes the operating sound. • Harness and connectors
• Electronic controlled engine mount
VIAS S/V-2 • Ignition switch: ON
• Turn solenoid valve “ON” and “OFF” using CONSULT and listen
to operating sound. Solenoid valve makes the operating
sound. • Harness and connectors
• Solenoid valve
IGNITION TIM-
ING • Engine: Return to the original
non-standard condition
• Timing light: Set
• Retard the ignition timing using
CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. Perform Idle Air Volume Learning.
POWER BAL-
ANCE • Engine: After warming up, idle the
engine.
• A/C switch OFF
• Selector lever: P or N position
• Cut off each injector signal one at a time using CONSULT. Engine runs rough or stops. • Harness and connectors
• Compression
• Fuel injector
• Power transistor
•Spark plug
• Ignition coil
VENT CON-
TROL/V • Ignition switch: ON (Engine
stopped)
• Turn solenoid valve “ON” and “OFF” with the CONSULT and lis-
ten to operating sound. Solenoid valve makes an operating
sound. • Harness and connectors
• Solenoid valve
V/T ASSIGN AN-
GLE • Engine: Return to the original
non-standard condition
• Change intake valve timing using
CONSULT. If malfunctioning symptom disap-
pears, see CHECK ITEM. • Harness and connectors
• Intake valve timing control sole- noid valve
COOLING FAN* • Ignition switch: ON
• Turn the cooling fan “HI”, “MID”, “LOW” and “OFF” using CON-
SULT. Cooling fan moves and stops.
• Harness and connectors
• Cooling fan motor
•IPDM E/R
TEST ITEM CONDITION JUDGMENT CHECK ITEM (REMEDY)
Test mode Test item Corresponding DTC No. Reference page
A/F SEN1 A/F SEN1(B1) P1276 P0130
EC-753
A/F SEN1(B2) P1286 P0150EC-753
EVAPORATIVE SYSTEMPURG FLOW P0441 P0441
EC-828PURG VOL CN/V P1444 P0443EC-833
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1612 of 4801

NISSAN TEANA 2014 Service Manual
EC-612
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
SRT & P-DTC MODE
