Page 49 of 4801

NISSAN TEANA 2014 Service Manual
BCS-34
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
PRBT ENG STRTWhen the engine start is prohibited Reset
When the engine start is permitted Set
PRMT ENG STRT When the engine start

BCS-34
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
PRBT ENG STRTWhen the engine start is prohibited Reset
When the engine start is permitted Set
PRMT ENG STRT When the engine start is prohibited Reset
When the engine start is permitted Set
PRMT RKE STRT When the engine start is prohibited Reset
When the engine start is permitted Set
PUSH SW Return ignition switch to LOCK position Off
Press ignition switch On
PUSH SW-IPDM When engine switch (push switch) is not pressed Off
When engine switch (push switch) is pressed On
REAR DEF SW Rear window defogger switch OFF Off
Rear window defogger switch ON On
REQ SW-AS When passenger door request switch is not pressed Off
When passenger door request switch is pressed On
REQ SW-DR When driver door request switch is not pressed Off
When driver door request switch is pressed On
REQ SW-BD/TR When trunk opener request switch is not pressed Off
When trunk opener request switch is pressed On
RKE-LOCK When LOCK button of Intelligent Key is not pressed Off
When LOCK button of Intelligent Key is pressed On
RKE-MODE CHG When LOCK/UNLOCK button of Intelligent Key is not pressed and
held simultaneously Off
When LOCK/UNLOCK button of Intelligent Key is pressed and held
simultaneously On
RKE OPE COUN1 Operation frequency of Intelligent Key 0-19
RKE OPE COUN2 Operation frequency of Intelligent Key 0-19
RKE-PANIC When PANIC button of Intelligent Key is not pressed Off
When PANIC button of Intelligent Key is pressed On
RKE-P/W OPEN When UNLOCK button of Intelligent Key is not pressed and held Off
When UNLOCK button of Intelligent Key is pressed and held On
RKE-TR/BD When TRUNK OPEN button of Intelligent Key is not pressed Off
When TRUNK OPEN button of Intelligent Key is pressed On
RKE-UNLOCK When UNLOCK button of Intelligent Key is not pressed Off
When UNLOCK button of Intelligent Key is pressed On
SFT N-MET When selector lever is in any position other than N Off
When selector lever is in N position On
SFT P-MET When selector lever is in any position other than P Off
When selector lever is in P position On
SFT PN -IPDM When selector lever is in any position other than P or N Off
When selector lever is in P or N position On
SFT PN/N SW When selector lever is in any position other than P or N Off
When selector lever is in P or N position On
SHFTLCK SLNID PER SPLY When BCM is not supplying power to shiftlock. Off
When BCM is supplying power to shiftlock. On
Monitor Item Condition Value/Status
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 50 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-35
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
TAIL LAMP SW
Other than lighting switch 1ST and 2ND Off
Lighting switch 1ST or 2ND On
TP 4 The

Page 51 of 4801

NISSAN TEANA 2014 Service Manual
BCS-36
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
TERMINAL LAYOUT
PHYSICAL VALUES
AWMIA1310ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 52 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-37
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/

Page 53 of 4801

NISSAN TEANA 2014 Service Manual
BCS-38
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
14
(P) Ground Combination switch
input 1 InputCombination
switch
(Wiper intermit-
tent dial 4) OFF 0V
FR WIPER HI
1.0V
INT VO

Page 54 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-39
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N30
(P) Ground Driver door lock sta-
tus Input Front door LH LOCK status
11 . 8 V
UNLOCK status

Page 55 of 4801

NISSAN TEANA 2014 Service Manual
BCS-40
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
60
(L) Ground CAN high Input/
Output ——
61
(Y) Ground Rear defogger relay
output OutputRear window de-
fogger Active Battery

Page 56 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-41
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
74
(P) Ground Front door lock as-
sembly LH (key cylin-
der switch) (lock) InputFront door loc

Load next 8 pages
