![NISSAN TEANA 2014 Service Manual
HAC-96
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
DescriptionINFOID:0000000009463167
Symptom
• Insufficient cooling
• No cool air comes out. (Air NISSAN TEANA 2014 Service Manual
HAC-96
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
DescriptionINFOID:0000000009463167
Symptom
• Insufficient cooling
• No cool air comes out. (Air](/manual-img/5/57390/w960_57390-2744.png)
HAC-96
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
DescriptionINFOID:0000000009463167
Symptom
• Insufficient cooling
• No cool air comes out. (Air flow volume is normal.)
Diagnosis ProcedureINFOID:0000000009463168
NOTE:
Perform self-diagnoses with CONSULT before performi ng symptom diagnosis. If any DTC is detected, per-
form the corresponding diagnosis.
1.CHECK MAGNET CLUTCH OPERATION
1. Turn ignition switch ON.
2. Operate fan switch.
3. Press A/C switch.
4. Check that A/C indicator turns ON. Check visually and by sound that compressor operates.
5. Press A/C switch again.
6. Check that A/C indicator turns OFF. Check that compressor stops.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform diagnosis of “COMPRESSOR DOES NOT OPERATE” in “SYMPTOM DIAGNOSIS”.
Refer to HAC-99, "Diagnosis Procedure"
.
2.CHECK DRIVE BELT
Check tension of drive belt. Refer to EM-19, "Checking Drive Belts"
(QR25DE) or EM-134, "Checking Drive
Belts" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Adjust or replace drive belt depending on the inspection results.
3.CHECK REFRIGERANT CYCLE
Connect recovery/recycling recharging equipment to the vehicle and perform pressure inspection with gauge.
Refer to HA-18, "Symptom Table"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace parts depending on the inspection results.
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of the fr ont air conditioning system for leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK AMBIENT TEMPERATURE DISPLAY
Check that there is not much difference between act ual ambient temperature and indicated temperature on
information display in combination meter.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform diagnosis for the A/C auto amp. connection recognition signal circuit. Refer to HAC-60,
"Diagnosis Procedure".
6.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-50, "Temperature Setting Trim-
mer".
2. Check that temperature setting trimme r (front) is set to “+ direction”.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2746 of 4801
INSUFFICIENT COOLINGHAC-97
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
NOTE:
The control temperature can be set with the setti ng of the temperature setting trimmer (front).
3. Set difference between set temperature and control temperature to “0”.
Is inspection result normal?
YES >> Inspection End.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2747 of 4801
![NISSAN TEANA 2014 Service Manual
HAC-98
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
DescriptionINFOID:0000000009463169
Symptom
• Insufficient heating
• No warm air comes out. (Air NISSAN TEANA 2014 Service Manual
HAC-98
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
DescriptionINFOID:0000000009463169
Symptom
• Insufficient heating
• No warm air comes out. (Air](/manual-img/5/57390/w960_57390-2746.png)
HAC-98
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
DescriptionINFOID:0000000009463169
Symptom
• Insufficient heating
• No warm air comes out. (Air flow volume is normal.)
Diagnosis ProcedureINFOID:0000000009463170
NOTE:
Perform self-diagnosis with CONSULT before performing symptom diagnosis. If DTC is detected, perform the
corresponding diagnosis.
1.CHECK COOLING SYSTEM
1. Check engine coolant level and check leakage. Refer to CO-11, "System Inspection"
(QR25DE) or CO-
35, "System Inspection" (VQ35DE).
2. Check reservoir tank cap. Refer to CO-11, "System Inspection"
(QR25DE) or CO-35, "System Inspection"
(VQ35DE).
3. Check water flow sounds of the engine coolant. Refer to CO-11, "System Inspection"
(QR25DE) or CO-
35, "System Inspection" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill engine coolant and repair or repl ace parts depending on the inspection results.
2.CHECK HEATER HOSE
Check installation of heater hose visually or by touching.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace parts depending on the inspection results.
3.CHECK HEATER CORE
1. Check temperature of inlet hose and outlet hose of front heater core.
2. Check that inlet side of heater core is hot and the outle t side is slightly lower than/almost equal to the inlet
side.
CAUTION:
Always perform the temperature in spection in a short period of time because the engine coolant
temperature is very hot.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace heater core. Refer to HA-42, "HEATER CORE : Removal and Installation"
.
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of front air conditioning system for air leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-50, "Temperature Setting Trim-
mer".
2. Check that temperature setting trimmer (front) is set to “ − direction”.
NOTE:
The control temperature can be set by t he temperature setting trimmer (front).
3. Set difference between the set temperature and control temperature to “0”.
Are the symptoms solved?
YES >> Inspection End.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2748 of 4801
![NISSAN TEANA 2014 Service Manual
COMPRESSOR DOES NOT OPERATEHAC-99
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
COMPRESSOR DOES NOT OPERATE
DescriptionINFOID:0000000009463171
Symptom: Compres NISSAN TEANA 2014 Service Manual
COMPRESSOR DOES NOT OPERATEHAC-99
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
COMPRESSOR DOES NOT OPERATE
DescriptionINFOID:0000000009463171
Symptom: Compres](/manual-img/5/57390/w960_57390-2747.png)
COMPRESSOR DOES NOT OPERATEHAC-99
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
COMPRESSOR DOES NOT OPERATE
DescriptionINFOID:0000000009463171
Symptom: Compressor does not operate.
Diagnosis ProcedureINFOID:0000000009463172
NOTE:
• Perform self-diagnoses with CONSULT before perform ing symptom diagnosis. If DTC is detected, perform
the corresponding diagnosis.
• Check that refrigerant system is properly charged. If refrigerant amount is below the proper amount, perform
inspection of refrigerant leakage.
1.CHECK MAGNET CLUTCH OPERATION
Check magnet clutch. Refer to HAC-87, "Component Function Check"
.
Does it operate normally?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK REFRIGERANT PRESSURE SENSOR
Check refrigerant pressure sensor. Refer to EC-523, "Component Function Check"
(QR25DE) or EC-979,
"Component Function Check" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK A/C AUTO AMP. OUTPUT SIGNAL
With CONSULT
Check “COMP REQ SIG” and “FAN REQ SIG” in “D ATA MONITOR” mode of “HVAC” using CONSULT.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
4.CHECK ECM INPUT SIGNAL
With CONSULT
Check “AIR COND SIG” and “HEATER FAN SW” in “DATA MONITOR” mode of “ECM” using CONSULT.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check CAN communication system. Refer to LAN-18, "Trouble Diagnosis Flow Chart"
.
5.CHECK IPDM E/R INPUT SIGNAL
With CONSULT
Monitor item Condition Status
COMP REQ SIG A/C switch ON On
OFF Off
FAN REQ SIG Blower motor ON On
OFF Off
Monitor item Condition Status
AIR COND SIG A/C switch ON On
OFF Off
HEATER FAN SW Blower motor ON On
OFF Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2749 of 4801
HAC-100
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
COMPRESSOR DOES NOT OPERATE
1. Start engine.
2. Check “AC COMP REQ” in “DATA MONITO R” mode of “IPDM E/R” using CONSULT.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check CAN communication system. Refer to LAN-18, "Trouble Diagnosis Flow Chart"
.
Monitor item Condition Status
AC COMP REQ A/C switch ON On
OFF Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2750 of 4801
A/C SWITCH ASSEMBLYHAC-101
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
REMOVAL AND INSTALLATION
A/C SWITCH ASSEMBLY
Removal and InstallationINFOID:0000000009463173
REMOVAL
1. Remove the center stack side finishers. Refer to IP-14, "Exploded View".
2. Remove the A/C switch assembly screws (A).
3. Disconnect the harness connector from the A/C switch assembly and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALIIA0635ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2751 of 4801
HAC-102
< REMOVAL AND INSTALLATION >[AUTOMATIC AIR CONDITIONER]
A/C AUTO AMP.
A/C AUTO AMP.
Exploded ViewINFOID:0000000009463174
Removal and InstallationINFOID:0000000009463175
REMOVAL
1. Remove the audio unit. Refer to
AV-47, "Removal and Installation" (BASE AUDIO), AV-108, "Removal and
Installation" (DISPLAY AUDIO WITHOUT BOSE) or AV-198, "Removal and Installation" (DISPLAY AUDIO
WITH BOSE).
2. Remove the AV control unit. Refer to AV-298, "Removal and Installation"
( N AV I G AT I O N W I T H O U T
BOSE) or AV-418, "Removal and Installation"
( N AV I G AT I O N W I T H B O S E ) .
3. Remove the audio unit bracket screws and audio unit brackets (LH/RH).
4. Remove the A/C auto amp.
INSTALLATION
Installation is in the reverse order of removal.
1. Audio unit 2. Audio unit bracket (LH) 3. A/C auto amp.
4. Audio unit bracket (RH)
AWNIA2551ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2752 of 4801
AMBIENT SENSORHAC-103
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000009463176
REMOVAL
1. Remove the core support cover clips (A), then remove the core support cover (1).
2. Disconnect the harness connector from the ambient sensor.
3. Release the ambient sensor clip, then remove the ambient sen- sor (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2602ZZ
ALIIA0314ZZ
