TM-402
< REMOVAL AND INSTALLATION >[CVT: RE0F10E]
CVT OIL WARMER SYSTEM
*: Refer to the illustrations for the specific position of each hose clamp tab.
• The illustrations indicate the view from the hose ends.
• When installing hose clamps the center line of each clamp tab
should be positioned as shown.
WATER HOSE : InspectionINFOID:0000000009464361
INSPECTION AFTER INSTALLATION
Start and warm up the engine. Visually check that there is no leakage of engine coolant and CVT fluid.
CVT FLUID COOLER HOSE
CVT FLUID COOLER HOSE : Exploded ViewINFOID:0000000009464362
COMPONENT PARTS LOCATION
(D): Vehicle front
(E) : Vehicle upper
JSDIA1292ZZ
CVT oil warmer Hose clamp CVT fluid cooler hose A
CVT fluid cooler hose B Transaxle assembly
: To radiator
: Always replace after every disassembly.
JSDIA3631GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4618 of 4801
![NISSAN TEANA 2014 Service Manual
CVT OIL WARMER SYSTEMTM-403
< REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CVT FLUID COOLER HOSE : Removal and InstallationINFOID:0000000009464363
REMOVAL
NOTE:
When r NISSAN TEANA 2014 Service Manual
CVT OIL WARMER SYSTEMTM-403
< REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CVT FLUID COOLER HOSE : Removal and InstallationINFOID:0000000009464363
REMOVAL
NOTE:
When r](/manual-img/5/57390/w960_57390-4617.png)
CVT OIL WARMER SYSTEMTM-403
< REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CVT FLUID COOLER HOSE : Removal and InstallationINFOID:0000000009464363
REMOVAL
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
1. Remove front under cover. Refer to EXT-28, "Removal and Installation"
.
2. Remove engine room cover. Refer to EM-28, "Removal and Installation"
.
3. Remove the front air duct and air cleaner case assembly. Refer to EM-29, "Removal and Installation"
.
4. Release hose clamp, then remove CVT fluid cool er hose A and B from CVT oil warmer and radiator.
CAUTION:
Do not reuse hose clamps.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse hose clamps.
• Insert CVT fluid cooler hoses according to dimension (A).
• Install hose clamps (1) at both ends of CVT fluid cooler hoses (2) with dimension (A) from the hose end.
• Hose clamp should not interfere with the bulge.
*: Refer to the illustrations for the specific position of each hose clamp tab. CVT fluid cooler hose (1) Insert side tube (2) Dimension (A)
CVT fluid cooler hose A Radiator tube
End reaches the 2-stage
bulge (B)
CVT oil warmer
CVT fluid cooler hose B CVT oil warmer
Radiator tube
JSDIA1289ZZ
Dimension (A) : 5 – 7 mm (0.20 – 0.28 in)
SCIA8123E
CVT fluid cooler hose Hose end Paint mark Position of hose clamp*
CVT fluid cooler hose A Radiator tube side Facing upward B
CVT oil warmer side Facing to the right of the vehicle B
CVT fluid cooler hose B CVT oil warmer side Facing downward A
Radiator tube side Facing to the front of the vehi-
cle B
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4619 of 4801
![NISSAN TEANA 2014 Service Manual
TM-404
< REMOVAL AND INSTALLATION >[CVT: RE0F10E]
CVT OIL WARMER SYSTEM
• The illustrations indicate the view from the hose ends.
• When installing hose clamps, the center line of each clamp tab NISSAN TEANA 2014 Service Manual
TM-404
< REMOVAL AND INSTALLATION >[CVT: RE0F10E]
CVT OIL WARMER SYSTEM
• The illustrations indicate the view from the hose ends.
• When installing hose clamps, the center line of each clamp tab](/manual-img/5/57390/w960_57390-4618.png)
TM-404
< REMOVAL AND INSTALLATION >[CVT: RE0F10E]
CVT OIL WARMER SYSTEM
• The illustrations indicate the view from the hose ends.
• When installing hose clamps, the center line of each clamp tab should be positioned as shown.
CVT FLUID COOLER HOSE : InspectionINFOID:0000000009464364
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage and check CVT fluid level. Refer to TM-377, "Inspection".
CVT OIL WARMER
CVT OIL WARMER : Exploded ViewINFOID:0000000009464365
CVT OIL WARMER : Removal and InstallationINFOID:0000000009464366
REMOVAL
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coolant escaping from the radiator. Wrap a thick clot h around the cap. Slowly turn it a quarter turn to
allow built-up pressure to escape. Carefully remove the cap by turning it all the way.
CAUTION:
Perform when the engine is cold.
1. Remove front under cover. Refer to EXT-28, "Removal and Installation"
.
2. Remove CVT water hose inlet and CVT water hose outlet from CVT oil warmer. Refer to TM-199,
"WATER HOSE : Exploded View".
3. Remove CVT fluid cooler hose inlet and CVT fluid cooler hose outlet from CVT oil warmer. Refer to TM-
201, "CVT FLUID COOLER HOSE : Exploded View".
(C): Front
ALDIA0366ZZ
Transaxle assembly CVT oil warmer
: N·m (kg-m, ft-lb)
JSDIA5031GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4620 of 4801
CVT OIL WARMER SYSTEMTM-405
< REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
4. Remove CVT oil warmer bolts, then remove CVT oil warmer from vehicle.
INSTALLATION
Installation is in the reverse order of removal.
CVT OIL WARMER : InspectionINFOID:0000000009464367
INSPECTION AFTER INSTALLATION
• Check for CVT fluid leakage and check CVT fluid level. Refer to TM-377, "Inspection".
• Start and warm up the engine. Visually check that there is no leakage of engine coolant and CVT fluid.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4621 of 4801
TM-406
< REMOVAL AND INSTALLATION >[CVT: RE0F10E]
PLUG
PLUG
DescriptionINFOID:0000000009464368
Replace the O-ring if oil leakage or exudes from the plug.
Exploded ViewINFOID:0000000009464369
Removal and InstallationINFOID:0000000009464370
REMOVAL
1. Remove fender protector side cover (LH). Refer to
EXT-26, "FENDER PROTECTOR : Removal and
Installation".
2. Remove the plug and O-ring.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to O-ring.
Inspection and AdjustmentINFOID:0000000009464371
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-377, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-286, "Adjustment".
Transaxle assembly O-ring Plug
: Always replace after every disassembly.
: N·m (kg-m, ft-lb)
: Apply CVT Fluid
JSDIA3622GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4622 of 4801
![NISSAN TEANA 2014 Service Manual
TRANSAXLE ASSEMBLYTM-407
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
UNIT REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000009464372
Remova NISSAN TEANA 2014 Service Manual
TRANSAXLE ASSEMBLYTM-407
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
UNIT REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000009464372
Remova](/manual-img/5/57390/w960_57390-4621.png)
TRANSAXLE ASSEMBLYTM-407
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
UNIT REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000009464372
Removal and InstallationINFOID:0000000009464373
REMOVAL
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly turn it a quarter turn to
allow built-up pressure to escap e. Carefully remove the cap by turning it all the way.
CAUTION:
• Perform when the engine is cold.
• When replacing TCM and transaxle assembly as a set, replace transaxle assembly first and then
replace TCM. Refer to TM-81, "Description"
.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
Gusset Transaxle assembly O-ring
CVT fluid charging pipe Water outlet CVT fluid charging pipe cap
: For the tightening torque, refer to TM-407, "Removal and Installation"
.
: Always replace after every disassembly.
: N·m (kg-m, ft-lb)
: N·m (kg-m, in-lb)
: Apply petroleum jelly
JSDIA3922GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4623 of 4801
![NISSAN TEANA 2014 Service Manual
TM-408
< UNIT REMOVAL AND INSTALLATION >[CVT: RE0F10E]
TRANSAXLE ASSEMBLY
1. Remove the engine and transaxle with the front suspension member as a unit. Refer to
EM-220,
"Removal and Installation".
NISSAN TEANA 2014 Service Manual
TM-408
< UNIT REMOVAL AND INSTALLATION >[CVT: RE0F10E]
TRANSAXLE ASSEMBLY
1. Remove the engine and transaxle with the front suspension member as a unit. Refer to
EM-220,
"Removal and Installation".](/manual-img/5/57390/w960_57390-4622.png)
TM-408
< UNIT REMOVAL AND INSTALLATION >[CVT: RE0F10E]
TRANSAXLE ASSEMBLY
1. Remove the engine and transaxle with the front suspension member as a unit. Refer to
EM-220,
"Removal and Installation".
2. Disconnect the transaxle harness connectors.
3. Disconnect the CVT oil warmer water hoses from engine side. Refer to TM-400, "WATER HOSE :
Removal and Installation".
4. Remove the CVT fluid charging pipe.
5. Remove the transaxle to engine and engine to transaxle bolts.
6. Separate the engine from the transaxle and remove the engine from the front suspension member. Refer to EM-220, "Removal and Installation"
.
NOTE:
Using paint, put matching marks on the drive plat e and torque converter when removing the torque con-
verter to drive plate nuts.
7. Remove transmission bracket.
8. Lift the transaxle from the front suspension member.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
Write down the serial number of the new transaxle assembly.
CAUTION:
• When replacing an engine or transaxle you must m ake sure any dowels are installed correctly during
re-assembly
• Improper alignment caused by missing dowels m ay cause vibration, oil leaks or breakage of drive
train components.
• Do not reuse O-rings or copper sealing washers.
• When turning crankshaft, turn it clockwi se as viewed from the front of the engine.
• When tightening the nuts for the torque converte r while securing the crankshaft pulley bolt, be sure
to confirm the tightening torque of the crankshaft pulley bolt. Refer to EM-174, "Removal and Instal-
lation".
• After converter is installed to drive plate, rota te crankshaft several turns to check that CVT rotates
freely without binding.
• When installing the CVT to the en gine, align the matching mark on the drive plate with the matching
mark on the torque converter.
When installing CVT assembly to th e engine assembly, attach the bolts in accordance with the follow-
ing standard.
JSDIA4208GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4624 of 4801
![NISSAN TEANA 2014 Service Manual
TRANSAXLE ASSEMBLYTM-409
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
•
• When installing the drive plate to torque converter nuts, tighten them temporarily NISSAN TEANA 2014 Service Manual
TRANSAXLE ASSEMBLYTM-409
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
•
• When installing the drive plate to torque converter nuts, tighten them temporarily](/manual-img/5/57390/w960_57390-4623.png)
TRANSAXLE ASSEMBLYTM-409
< UNIT REMOVAL AND INSTALLATION > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
•
• When installing the drive plate to torque converter nuts, tighten them temporarily. then tighten the nuts to the
specified torque.
Inspection and AdjustmentINFOID:0000000009464374
INSPECTION BEFORE INSTALLATION
After inserting a torque converter to the CVT, check dimension (A)
with in the reference value limit.
INSPECTION AFTER INSTALLATION
Check the following items:
• CVT fluid leakage, refer to TM-377, "Inspection"
.
• For CVT position, refer to TM-289, "Inspection"
.
• Start the engine and check for coolant leakage from the parts which are removed and reinstalled.
ADJUSTMENT AFTER INSTALLATION
• Adjust the CVT fluid level. Refer to TM-286, "Adjustment".
• Perform "ADDITIONAL SERVICE WHEN REPLACE TRANSAXLE ASSEMBLY". Refer to TM-283, "Descrip-
tion".
Bolt No. 12345
Number of bolts12114
Bolt length
“”mm (in) 55 (2.17) 39 (1.54) 35 (1.38) 50 (1.97) 45 (1.77)
Tightening torque
N·m (kg-m, ft-lb) 74.5 (7.6, 55) 50.0
(5.1, 37)
AWDIA1031ZZ
B: Scale
C : Straightedge
Dimension (A) : Refer to TM-413, "Torque Converter".
JPDIA0115ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
