PWC-30
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
POWER WINDOW MAIN SWITCH : Component Function Check
INFOID:0000000009460836
Main Power Window And Door Lock/

PWC-30
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
POWER WINDOW MAIN SWITCH : Component Function Check
INFOID:0000000009460836
Main Power Window And Door Lock/unlock Switch
1. CHECK MAIN POWER WINDOW AND DO OR LOCK/UNLOCK SWITCH FUNCTION
Check power window motor operation with main power window and door lock/unlock switch.
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch power supply and ground circuit are OK.
NO >> Refer to PWC-30, "POWER WI NDOW MAIN SWITCH : Diagnosis Procedure"
.
POWER WINDOW MAIN SWITCH : Diagnosis ProcedureINFOID:0000000009460837
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Main Power Window And Door Lock/unlock Switch Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between main power window and door lock/unlock switch connectors D8, D12 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM, main power window and door lock/ unlock switch, power window and door lock/unlock
switch RH, rear power window switch LH and rear power window switch RH.
3. Check continuity between BCM connector and main power window and door lock/unlock switch connec- tors.
4. Check continuity between BCM connector M21 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch.
Te r m i n a l
Vo l ta g e
(Approx.)
(+)
(–)
Main power window and door lock/unlock switch
Te r m i n a l
D12 10 Ground Battery voltage
D8 18
BCM
connector Te r m i n a l
Main power window and door lock/unlock switch
connector Terminal Continuity
M21 140 D12 10
Ye s
141 D8 18
BCM connector Terminal GroundContinuity
M21 140
No
141
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3538 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-31
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
3. Check continuity between main power window and door lock/unlock switc

POWER SUPPLY AND GROUND CIRCUITPWC-31
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
3. Check continuity between main power window and door lock/unlock switch connector D8 and ground.
Is the inspection result normal?
YES >> Check main power window and door lock/unlock switch output signal (rear power window switch
LH) GO TO 5.
YES >> Check main power window and door lock/unlock switch output signal (rear power window switch
RH) GO TO 6.
YES >> Check main power window and door lock/unlock s witch output signal (front power window switch
LH) GO TO 7.
YES >> Check main power window and door lock/unlock s witch output signal (front power window switch
RH) GO TO 8.
NO >> Repair or replace the harness or connectors.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M21 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5. CHECK MAIN POWER WINDOW AND DOOR LOCK /UNLOCK SWITCH OUTPUT SIGNAL (REAR POW-
ER WINDOW SWITCH LH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch D12 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL
UNIT : Special Repair Requirement".
6. CHECK MAIN POWER WINDOW AND DOOR LOCK /UNLOCK SWITCH OUTPUT SIGNAL (REAR POW-
ER WINDOW SWITCH RH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch D12 and ground.
Main power window and door lock/unlock switch connector Terminal GroundContinuity
D8 1 Yes
Te r m i n a l s Vo l ta g e
(Approx.)
(+)
(–)
BCM connector Terminal
M21 140
Ground Battery voltage
141
Te r m i n a l
Window switch
position (rear LH) Vol tag e
(Approx.)
(+)
(–)
Main power window and door lock/
unlock switch connector Te r m i n a l
D12 8
Ground UP Battery voltage
DOWN 0
9 UP 0
DOWN Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3539 of 4801

NISSAN TEANA 2014 Service Manual
PWC-32
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident

PWC-32
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident".
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL
UNIT : Special Repair Requirement".
7. CHECK MAIN POWER WINDOW AND DOOR LO CK/UNLOCK SWITCH OUTPUT SIGNAL (FRONT
POWER WINDOW SWITCH LH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch D8 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL
UNIT : Special Repair Requirement".
8. CHECK MAIN POWER WINDOW AND DOOR LO CK/UNLOCK SWITCH OUTPUT SIGNAL (FRONT
POWER WINDOW SWITCH RH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch D12 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
Te r m i n a l
Window switch
position (rear RH) Vo l ta g e
(Approx.)
(+)
(–)
Main power window and door
lock/unlock switch connector Te r m i n a l
D12 6
Ground UP Battery voltage
DOWN 0
7 UP 0
DOWN Battery voltage
Te r m i n a l Window switch
position (front LH) Vo l ta g e
(Approx.)
(+)
(–)
Main power window and door lock/
unlock switch connector Te r m i n a l
D8 17
Ground UP Battery voltage
DOWN 0
19 UP 0
DOWN Battery voltage
Te r m i n a l Window switch
position (front RH) Vo l ta g e
(Approx.)
(+)
(–)
Main power window and door
lock/unlock switch connector Te r m i n a l
D12 2
Ground UP Battery voltage
DOWN 0
16 UP 0
DOWN Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3540 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-33
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
NO >> Replace main power window and door lock/unlock switch. Refer to P

Page 3541 of 4801

NISSAN TEANA 2014 Service Manual
PWC-34
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace

PWC-34
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL
UNIT : Special Repair Requirement".
POWER WINDOW MAIN SWITCH : S pecial Repair RequirementINFOID:0000000009460839
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to PWC-30, "POWER WINDO W MAIN SWITCH : Component Function Check"
.
FRONT POWER WINDOW SWITCH
FRONT POWER WINDOW SWITCH : DescriptionINFOID:0000000009460840
• BCM supplies power.
• Front power window motor RH will be operated if power window and door lock/unlock switch RH is operated.
FRONT POWER WINDOW SWITCH : Component Function CheckINFOID:0000000009460841
Power Window And Door Lock/unlock Switch RH
1. CHECK POWER WINDOW MOTOR FUNCTION
Check front power window motor operation with power window and door lock/unlock switch RH.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch RH power supply and ground circuit are OK.
NO >> Refer to PWC-35, "FRONT POWER WINDOW SWITCH : Diagnosis Procedure"
.
Terminal Main power window and door lock/unlock switch condition Continuity
9
1 Rear LH
UP
Ye s
7Rear RH
16 Front RH 8 Rear LH
NEUTRAL
9
7 Rear RH
6
2 Front RH
16
8Rear LH DOWN
6Rear RH
2Front RH
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3542 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-35
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT POWER WINDOW SWIT CH : Diagnosis ProcedureINFOID:0000000009460842

POWER SUPPLY AND GROUND CIRCUITPWC-35
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT POWER WINDOW SWIT CH : Diagnosis ProcedureINFOID:0000000009460842
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Power Window And Door Lock/Unlock Switch RH Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT (POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH)
1. Turn ignition switch ON.
2. Check voltage between power window and door lock/unlock switch RH connector D110 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM, power window and door lock/unlock switch RH, rear power window switch LH and rear power window switch RH.
3. Check continuity between BCM connector M21 and power window and door lock/unlock switch RH con-
nector D110.
4. Check continuity between BCM connector M21 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
3. CHECK HARNESS CONTINUI TY (POWER WINDOW AND DO OR LOCK/UNLOCK SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and power window and door lock/unlock
switch RH.
3. Check continuity between main power window and door lock/unlock switch connector D12 and power win-
dow and door lock/unlock switch RH connector D110.
4. Check continuity between main power window and door lock/unlock switch connector D12 and ground.
Te r m i n a l Vo l ta g e
(Approx.)
(+)
(–)
Power window and door lock/unlock
switch RH connector Te r m i n a l
D110 8 Ground Battery voltage
BCM connector Terminal Power window and door lock/unlock
switch RH connector Terminal Continuity
M21 140 D110 8 Yes
BCM connector Terminal GroundContinuity
M21 140 No
Main power window and door lock/unlock switch connector Te r m i n a lPower window and door lock/
unlock switch RH connector Terminal Continuity
D12 2
D110 11
Ye s
16 12
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3543 of 4801

NISSAN TEANA 2014 Service Manual
PWC-36
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair or replace the harness or connectors.
4. CHECK

Page 3544 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-37
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
• Rear power window motor will be operated if rear power window switch

POWER SUPPLY AND GROUND CIRCUITPWC-37
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
• Rear power window motor will be operated if rear power window switch is operated. Rear power window switch.
REAR POWER WINDOW SWITCH : Component Function CheckINFOID:0000000009460845
Rear Power Window Switch
1. CHECK REAR POWER WINDOW MOTOR FUNCTION
Check rear power window motor operation with rear power window switch.
Is the inspection result normal?
YES >> Rear power window switch power supply and ground circuit are OK.
NO >> Refer to PWC-37, "REAR POWER WINDOW SWITCH : Diagnosis Procedure"
.
REAR POWER WINDOW SWITCH : Diagnosis ProcedureINFOID:0000000009460846
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Rear Power Window Switch Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between rear power window switch connector and ground.
Is the inspection result normal?
YES >> GO TO 2 (Rear power window switch LH).
YES >> GO TO 3 (Rear power window switch RH).
NO >> GO TO 4.
2. CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unloc k switch and rear power window switch LH.
3. Check continuity between main power window and door lock/unlock switch connector and rear power win- dow switch LH connector.
4. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
Te r m i n a l
ConditionVo l ta g e
(Approx.)
(+)
(–)
Rear power window
switch connector Te r m i n a l
LH D203 4 Ground Ignition switch ON Battery voltage
RH D303
Main power window and door lock/
unlock switch connector Te r m i n a lRear power window switch
LH connector Terminal Continuity
D12 8
D203 7
Ye s
98
Main power window and door lock/unlock switch connector Te r m i n a l
GroundContinuity
D12 8
No
9
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Load next 8 pages

Page: < prev 1-10 ... 3505-3512 3513-3520 3521-3528 3529-3536 3537-3544 3545-3552 3553-3560 3561-3568 3569-3576 ... 4808 next >

CD changer lumbar support MPG navigation system towing capacity gearbox
