NISSAN TEANA 2014 Service Manual
TM-10
< PRECAUTION >[CVT: RE0F10D]
PRECAUTIONS
General Precautions
INFOID:0000000009463957
• Turn ignition switch OFF an d disconnect the battery cable
from the negative terminal before connecting

Page 4226 of 4801

NISSAN TEANA 2014 Service Manual
PRECAUTIONSTM-11
< PRECAUTION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
On Board Diagnosis (OBD) System of CVT and EngineINFOID:0000000009463958
The TCM and ECM have an on board diagnostic s

PRECAUTIONSTM-11
< PRECAUTION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
On Board Diagnosis (OBD) System of CVT and EngineINFOID:0000000009463958
The TCM and ECM have an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to
warn the driver of a malfunction causing emission deterioration.
CAUTION:
• Be sure to turn the ignition switch OFF and di sconnect the battery cable from the negative terminal
before any repair or inspection work. The open/s hort circuit of related switches, sensors, solenoid
valves, etc. will cause the MIL to light up.
• Be sure to connect and lock the connectors secure ly after work. A loose (unlocked) connector will
cause the MIL to light up due to an open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
• Be sure to route and secure the harnesses properly after work. Interference of the harness with a
bracket, etc. may cause the MIL to light up due to a short circuit.
• Be sure to connect rubber tubes properly afte r work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to a malfunction of the EGR system or fuel injection system, etc.
• Be sure to erase the unnecessary malfunction informa tion (repairs completed) from the TCM and
ECM before returning the vehicle to the customer.
Removal and Installation Proc edure for CVT Unit ConnectorINFOID:0000000009463959
REMOVAL
• Rotate bayonet ring (1) counterclockwise. Pull out CVT unit har-
ness connector (2) upward and remove it.
INSTALLATION
1. Align marking (A) on CVT unit harness connector terminal with
marking (B) on bayonet ring. Insert CVT unit harness connector.
2. Rotate bayonet ring clockwise.
3. Rotate bayonet ring clockwise until marking (A) on CVT unit har- ness connector terminal body is aligned with the slit (B) on bayo-
net ring as shown in the figure (correctly fitting condition).
CAUTION:
SCIA6685J
JPDIA0294ZZ
JPDIA0295ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4227 of 4801

NISSAN TEANA 2014 Service Manual
TM-12
< PRECAUTION >[CVT: RE0F10D]
PRECAUTIONS
• Securely align marking (A) on CVT unit harness connec-
tor terminal body with bayonet ri ng slit (B). Then, be care-
ful not to make a half fit cond

Page 4228 of 4801

NISSAN TEANA 2014 Service Manual
PREPARATIONTM-13
< PREPARATION > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000009463960
The actual shape of the tools may di ffer from th

Page 4229 of 4801

NISSAN TEANA 2014 Service Manual
TM-14
< SYSTEM DESCRIPTION >[CVT: RE0F10D]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
CVT CONTROL SYSTEM
