Page 4785 of 4801

NISSAN TEANA 2014 Service Manual WW-50 < SYMPTOM DIAGNOSIS > NORMAL OPERATING CONDITION NORMAL OPERATING CONDITION DescriptionINFOID:0000000009464627 FRONT WIPER MOTOR PROTECTION FUNCTION • IPDM E/R may stop the front wiper to pro

Page 4786 of 4801

NISSAN TEANA 2014 Service Manual WASHER TANKWW-51 < REMOVAL AND INSTALLATION > C D E F G H I J K M A B WW N O P REMOVAL AND INSTALLATION WASHER TANK Exploded ViewINFOID:0000000009464628 Removal and InstallationINFOID:0000000009464

Page 4787 of 4801

NISSAN TEANA 2014 Service Manual WW-52 < REMOVAL AND INSTALLATION > WASHER PUMP WASHER PUMP Exploded ViewINFOID:0000000009464630 Removal and InstallationINFOID:0000000009464631 REMOVAL 1. Drain the washer fluid. 2. Remove the front

Page 4788 of 4801

NISSAN TEANA 2014 Service Manual WASHER LEVEL SWITCHWW-53 < REMOVAL AND INSTALLATION > C D E F G H I J K M A B WW N O P WASHER LEVEL SWITCH Exploded ViewINFOID:0000000009464632 Removal and InstallationINFOID:0000000009464633 REMOV

Page 4789 of 4801

NISSAN TEANA 2014 Service Manual WW-54 < REMOVAL AND INSTALLATION > WASHER NOZZLE & TUBE WASHER NOZZLE & TUBE Exploded ViewINFOID:0000000009464634 FRONT REAR (IF EQUIPPED) ALLIA1162ZZ 1. Front washer tube 2. Washer tank 3. Washer pu

Page 4790 of 4801

NISSAN TEANA 2014 Service Manual WASHER NOZZLE & TUBEWW-55 < REMOVAL AND INSTALLATION > C D E F G H I J K M A B WW N O P WASHER NOZZLE WASHER NOZZLE : Removal and InstallationINFOID:0000000009464635 REMOVAL 1. Disconnect the washe

Page 4791 of 4801

NISSAN TEANA 2014 Service Manual WW-56 < REMOVAL AND INSTALLATION > WASHER NOZZLE & TUBE NOTE: Spray positions for LH shown; RH is symmetrical. Insert a suitable tool (A) into the nozzle hole (B) and move up/down and left/right t

Page 4792 of 4801

NISSAN TEANA 2014 Service Manual WASHER NOZZLE & TUBEWW-57 < REMOVAL AND INSTALLATION > C D E F G H I J K M A B WW N O P 3. Remove the hood insulator. Refer to DLK-170, "HOOD ASSEMBLY : Exploded View". 4. Disconnect the washer tu
