Page 3161 of 4801

NISSAN TEANA 2014 Service Manual OIL FILTERLU-11 < PERIODIC MAINTENANCE > [QR25DE] C D E F G H I J K L M A LU NP O OIL FILTER Removal and InstallationINFOID:0000000009461030 REMOVAL 1. Remove fender protector side cover (RH). Refer

Page 3162 of 4801

NISSAN TEANA 2014 Service Manual LU-12 < PERIODIC MAINTENANCE >[QR25DE] OIL FILTER 4. Refill engine with new engine oil. Refer to LU-10, "Changing Engine Oil". 5. After warming up the engine, check for engine oil leaks. Repair as n

Page 3163 of 4801

NISSAN TEANA 2014 Service Manual OIL PUMPLU-13 < REMOVAL AND INSTALLATION > [QR25DE] C D E F G H I J K L M A LU NP O REMOVAL AND INSTALLATION OIL PUMP Exploded ViewINFOID:0000000009461031 CAUTION: Before assembly, apply new engine

Page 3164 of 4801

NISSAN TEANA 2014 Service Manual LU-14 < REMOVAL AND INSTALLATION >[QR25DE] OIL PUMP • Install the inner rotor and outer rotor with the punched marks on the oil pump cover side. CAUTION: Before assembly apply new engine oil to

Page 3165 of 4801

NISSAN TEANA 2014 Service Manual OIL PUMPLU-15 < REMOVAL AND INSTALLATION > [QR25DE] C D E F G H I J K L M A LU NP O - Measure the inner diameter of inner rotor (1) with inside microme- ter (A). - (Clearance) = (Inner rotor inner

Page 3166 of 4801

NISSAN TEANA 2014 Service Manual LU-16 < REMOVAL AND INSTALLATION >[QR25DE] OIL COOLER OIL COOLER Exploded ViewINFOID:0000000009461035 Removal and InstallationINFOID:0000000009461036 WARNING: Be careful not to burn yourself, as eng

Page 3167 of 4801

NISSAN TEANA 2014 Service Manual OIL COOLERLU-17 < REMOVAL AND INSTALLATION > [QR25DE] C D E F G H I J K L M A LU NP O • Tighten oil cooler bolts to specification in numerical order. • Do not reuse O-ring. InspectionINFOID:000

Page 3168 of 4801

NISSAN TEANA 2014 Service Manual LU-18 < SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) Oil PressureINFOID:00000000094
