PWC-142
< REMOVAL AND INSTALLATION >[LH & RH FRONT ANTI-PINCH]
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
REMOVAL AND INSTALLATION
MAIN POWER WINDOW AND
DOOR LOCK/UNLOCK SWITCH
Removal and InstallationINFOID:0000000009460982
REMOVAL
1. Remove the front door pull handle outer finisher using a suitable tool.
2. Release the pawls using a suitable tool and lift the main power window and door lock/unlock switch and
finisher as an assembly by starting at the rear, then pull upward and remove.
3. Disconnect the harness connector from the main power window and door lock/unlock switch.
4. Release the four pawls (two on each side) using a suitable tool, then separate the main power window and door lock/unlock
switch (1) from the main power window and door lock switch fin-
isher (2).
: Pawl
CAUTION:
Do not bend back the pawls on the switch finisher too far or
breakage may occur.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
When the main power window and door lock/unlock swit ch is disconnected from the harness connector it is
necessary to perform the initialization procedure. Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOV-
ING BATTERY NEGATIVE TERMINAL : Special Repair Requirement".
ALKIA2630ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3650 of 4801
![NISSAN TEANA 2014 Service Manual
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RHPWC-143
< REMOVAL AND INSTALLATION > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Removal and NISSAN TEANA 2014 Service Manual
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RHPWC-143
< REMOVAL AND INSTALLATION > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Removal and](/manual-img/5/57390/w960_57390-3649.png)
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RHPWC-143
< REMOVAL AND INSTALLATION > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Removal and InstallationINFOID:0000000009460983
REMOVAL
1. Remove the front door pull handle outer finisher using a suitable tool.
2. Release the pawls using a suitable tool and lift the power window and door lock/unlock switch RH and fin- isher as an assembly by starting at the rear, then pull upward and remove.
3. Disconnect the harness connector from the pow er window and door lock/unlock switch RH.
4. Release the four pawls (two on each side) using a suitable tool, then separate the power window and door lock/unlock switch
RH (1) from the power window and door lock switch RH finisher
(2).
: Pawl
CAUTION:
Do not bend back the pawls on th e switch finisher too far or
breakage may occur.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2630ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3651 of 4801
PWC-144
< REMOVAL AND INSTALLATION >[LH & RH FRONT ANTI-PINCH]
REAR POWER WINDOW SWITCH
REAR POWER WINDOW SWITCH
Removal and Installation INFOID:0000000009460984
REMOVAL
1. Release the pawls using a suitable tool and lift the rear power window switch and finisher as an assembly
by starting at the rear, then pull upward and remove
2. Disconnect the harness connector from the rear power window switch.
3. Release the pawl (one on each side) using a suitable tool, then separate the rear power window switch (1) from the rear power
switch finisher (2).
: Pawl
CAUTION:
Do not bend back the pawls on the switch finisher too far or
breakage may occur.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2631ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3652 of 4801

PWO
PWO-1
ELECTRICAL & POWER CONTROL
C
D E
F
G H
I
J
K L
B
SECTION PWO
A
O P
N
CONTENTS
POWER OUTLET
PRECAUTION ................
...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tool ........................................... ......3
WIRING DIAGRAM .......................................4
POWER SOCKET ..............................................4
Wiring Diagram .................................................... .....4
REMOVAL AND INSTALLATION ................6
POWER SOCKET ..............................................6
Removal and Installation ..................................... .....6
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3653 of 4801

PWO-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951594
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3654 of 4801
PWO
PREPARATIONPWO-3
< PREPARATION >
C
D E
F
G H
I
J
K L
B
A
O P
N
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009460696
The actual shapes of the tools may differ from those illustrated here.
Tool number
(TechMate No.)
Tool name Description
—
(J-42059)
Power socket removal tool Removing power sockets
AWMIA1148GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3655 of 4801
PWO-4
< WIRING DIAGRAM >
POWER SOCKET
WIRING DIAGRAM
POWER SOCKET
Wiring DiagramINFOID:0000000009460697
ABMWA2168GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3656 of 4801
PWO
POWER SOCKETPWO-5
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMIA5108GB
