P0340 CMP SENSOR (PHASE)EC-329
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0340 CMP SENSOR (PHASE)
DTC LogicINFOID:0000000009462263
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the follo wing procedure, confirm that battery vo ltage is more than 10.5 V with igni-
tion switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-1
1. Start engine and let it idle for at least 5 seconds. If engine does not start, crank engine for at least 2 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-329, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-2
1. Maintaining engine speed at more than 800 rpm for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-329, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462264
1.CHECK STARTING SYSTEM
Turn ignition switch to START position.
Does the engine turn over? Does the starter motor operate?
YES >> GO TO 2.
NO >> Check starting system (Refer to STR-12, "Work Flow (With GR8-1200 NI)"
or STR-16, "Work Flow
(Without GR8-1200 NI)".).
2.CHECK CAMSHAFT POSITION (CMP ) SENSOR (PHASE) POWER SUPPLY
1. Turn ignition switch OFF.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0340 CMP SEN/CIRC-B1
(Camshaft position sensor
″ A ″ circuit bank 1 or single
sensor) • The cylinder No. signal is not sent to ECM
for the first few seconds during engine
cranking.
• The cylinder No. signal is not sent to ECM during engine running.
• The cylinder No. signal is not in the nor- mal pattern during engine running. • Harness or connectors
(Camshaft position sensor circuit is open
or shorted)
• Camshaft position sensor
• Camshaft (Intake)
•Starter motor
• Starting system circuit
• Dead (Weak) battery
• Sensor power supply 2 circuit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1330 of 4801
![NISSAN TEANA 2014 Service Manual
EC-330
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0340 CMP SENSOR (PHASE)
2. Disconnect camshaft position (CMP)
sensor (PHASE) harness connector.
3. Turn ignition switch ON.
4. Check the voltage between CM NISSAN TEANA 2014 Service Manual
EC-330
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0340 CMP SENSOR (PHASE)
2. Disconnect camshaft position (CMP)
sensor (PHASE) harness connector.
3. Turn ignition switch ON.
4. Check the voltage between CM](/manual-img/5/57390/w960_57390-1329.png)
EC-330
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0340 CMP SENSOR (PHASE)
2. Disconnect camshaft position (CMP)
sensor (PHASE) harness connector.
3. Turn ignition switch ON.
4. Check the voltage between CMP sensor (PHASE) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY 2 CIRCUIT
Perform EC-525, "Diagnosis Procedure"
.
Is inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
4.CHECK CMP SENSOR (PHASE) GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between CMP sensor (PHASE) harness connector and ECM harness connector.
*1: Except for California
*2: For California
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK CMP SENSOR (PHASE) INPUT SIGNAL CIRCUIT
1. Disconnect ECM harness connector.
2. Check the continuity between CMP sensor (PHASE) harness connector and ECM harness connector.
*1: Except for California
*2: For California
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace error-detected parts.
6.CHECK CAMSHAFT POSITION SENSOR (PHASE)
+
−Voltag e
(Approx.)
CMP sensor (PHASE)
Connector Terminal F55 1 Ground 5 V
+ −
Continuity
CMP sensor (PHASE) ECM
Connector Terminal Connector Terminal
F55 2 F14
*1
F91*230 Existed
+
−
Continuity
CMP sensor (PHASE) ECM
Connector Terminal Connector Terminal
F55 3 F14
*1
F91*231 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1331 of 4801
![NISSAN TEANA 2014 Service Manual
P0340 CMP SENSOR (PHASE)EC-331
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Check the camshaft position sensor (PHASE). Refer to
EC-331, "Component Inspection (Camshaft positi NISSAN TEANA 2014 Service Manual
P0340 CMP SENSOR (PHASE)EC-331
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Check the camshaft position sensor (PHASE). Refer to
EC-331, "Component Inspection (Camshaft positi](/manual-img/5/57390/w960_57390-1330.png)
P0340 CMP SENSOR (PHASE)EC-331
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Check the camshaft position sensor (PHASE). Refer to
EC-331, "Component Inspection (Camshaft position
sensor)".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace camshaft position sensor (PHASE). Refer to EM-47, "Removal and Installation"
.
7.CHECK CAMSHAFT (INT)
Check the following.
• Accumulation of debris to the signal plate of camshaft rear end
• Chipping signal plate of camshaft rear end
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent
Incident".
NO >> Remove debris and clean the signal plate of camshaft rear end or replace camshaft. Refer to EM-47, "Removal
and Installation".
Component Inspection (Camshaft position sensor)INFOID:0000000009462265
1.CHECK CAMSHAFT POSITI ON SENSOR (PHASE)-1
1. Turn ignition switch OFF.
2. Loosen the fixing bolt of the sensor.
3. Disconnect camshaft position s ensor (PHASE) harness connector.
4. Remove the sensor.
5. Visually check the sensor for chipping.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace camshaft position sensor (PHASE).
2.CHECK CAMSHAFT POSITI ON SENSOR (PHASE)-2
Check the resistance camshaft position sens or (PHASE) terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace camshaft position sensor (PHASE). Refer to EM-47, "Removal and Installation"
.
JPBIA5855ZZ
PBIA9876J
Camshaft position sensor (PHASE)
Resistance [Ω at 25 °C (77 °F)]
+ −
Terminals (Polarity)
1 2
Except 0 or ∞
3
23
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1332 of 4801
![NISSAN TEANA 2014 Service Manual
EC-332
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
P0420 THREE WAY CATALYST FUNCTION
DTC LogicINFOID:0000000009462266
DTC DETECTION LOGIC
The ECM monitors the switching freque NISSAN TEANA 2014 Service Manual
EC-332
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
P0420 THREE WAY CATALYST FUNCTION
DTC LogicINFOID:0000000009462266
DTC DETECTION LOGIC
The ECM monitors the switching freque](/manual-img/5/57390/w960_57390-1331.png)
EC-332
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
P0420 THREE WAY CATALYST FUNCTION
DTC LogicINFOID:0000000009462266
DTC DETECTION LOGIC
The ECM monitors the switching frequency ratio of air fuel ratio (A/F)
sensor 1 and heated oxygen sensor 2.
A three way catalyst (manifold) with high oxygen storage capacity
will indicate a low switching frequency of heated oxygen sensor 2.
As oxygen storage capacity decr eases, the heated oxygen sensor 2
switching frequency will increase.
When the frequency ratio of air fuel ratio (A/F) sensor 1 and heated
oxygen sensor 2 approaches a specif ied limit value, the three way
catalyst (manifold) malfunction is diagnosed.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
Will CONSULT be used?
YES >> GO TO 2.
NO >> GO TO 6.
2.PERFORM DTC CONFIRMATION PROCEDURE-1
With CONSULT
TESTING CONDITION:
Do not hold engine speed for more than the specified minutes below.
1. Start engine and warm it up to the normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and keep the engine speed between 3,500 and 4,000 rpm for at least 1 minute under no load.
6. Let engine idle for 1 minute.
7. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
8. Check that “COOLAN TEMP/S” indicates more than 70 °C (158 °F).
If not, warm up engine and go to next step when “C OOLAN TEMP/S” indication reaches to 70°C (158 °F).
9. Open engine hood.
10. Select “DTC & SRT CONFIRMATION” then “SRT WORK SUPPORT” mode of “ENGINE” using CON-
SULT.
11. Rev engine up to 2,500 to 3,000 rpm and hold it for 3 consecutive minutes then release the accelerator pedal completely.
12. Check the indication of “CATALYST”.
SEF484YB
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0420 TW CATALYST SYS-B1
(Catalyst system efficiency be-
low threshold bank 1) • Three way catalyst (manifold) does not operate
properly.
• Three way catalyst (manifold) does not have enough oxygen storage capacity. • Three way catalyst (manifold)
• Exhaust tube
• Intake air leaks
• Fuel injector
• Fuel injector leaks
• Spark plug
• Improper ignition timing
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1333 of 4801
![NISSAN TEANA 2014 Service Manual
P0420 THREE WAY CATALYST FUNCTIONEC-333
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Which is displayed on CONSULT screen?
CMPLT >> GO TO 5.
INCMP >> GO TO 3.
3.PERFORM DTC CO NISSAN TEANA 2014 Service Manual
P0420 THREE WAY CATALYST FUNCTIONEC-333
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Which is displayed on CONSULT screen?
CMPLT >> GO TO 5.
INCMP >> GO TO 3.
3.PERFORM DTC CO](/manual-img/5/57390/w960_57390-1332.png)
P0420 THREE WAY CATALYST FUNCTIONEC-333
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Which is displayed on CONSULT screen?
CMPLT >> GO TO 5.
INCMP >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-2
1. Wait 5 seconds at idle.
2. Rev engine up to 2,500 to 3,000 rpm and maintain it unt il “INCMP” of “CATALYST” changes to “CMPLT” (It
will take approximately 5 minutes).
Does the indication change to
“CMPLT”?
YES >> GO TO 5.
NO >> GO TO 4.
4.PERFORM DTC CONFIRMATION PROCEDURE AGAIN
1. Stop engine and cool it down to less than 70 °C (158 °F).
2. Perform DTC confirmation procedure again.
>> GO TO 2.
5.PERFORM DTC CONFIRMATION PROCEDURE-3
Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-334, "Diagnosis Procedure".
NO >> INSPECTION END
6.PERFORM COMPONENT FUNCTION CHECK
Perform component function check. Refer to EC-333, "Component Function Check"
.
NOTE:
Use component function check to check the overall function of the three way catalyst (manifold). During this
check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-334, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462267
1.PERFORM COMPONENT FUNCTION CHECK
Without CONSULT
1. Start engine and warm it up to the normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Restart engine and keep the engine speed between 3,500 and 4,000 rpm for at least 1 minute under no
load.
4. Let engine idle for 1 minute.
5. Open engine hood.
6. Check the voltage between ECM harness connector terminals as per the following condition.
*1: Except for California
*2: For California
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-334, "Diagnosis Procedure"
.
ECM
Condition Voltage (V)
Connector +–
Te r m i n a l
F14
*1
F91*222 23 Keeping engine speed at 2500 rpm
constant under no load The voltage fluctuation cycle takes more
than 5 seconds.
• 1 cycle: 0.6 - 1.0 → 0 - 0.3 → 0.6 - 1.0
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1334 of 4801
![NISSAN TEANA 2014 Service Manual
EC-334
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
Diagnosis Procedure
INFOID:0000000009462268
1.CHECK EXHAUST SYSTEM
Visually check exhaust tubes and muffler for dent.
Is th NISSAN TEANA 2014 Service Manual
EC-334
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
Diagnosis Procedure
INFOID:0000000009462268
1.CHECK EXHAUST SYSTEM
Visually check exhaust tubes and muffler for dent.
Is th](/manual-img/5/57390/w960_57390-1333.png)
EC-334
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
Diagnosis Procedure
INFOID:0000000009462268
1.CHECK EXHAUST SYSTEM
Visually check exhaust tubes and muffler for dent.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-detected parts.
2.CHECK EXHAUST GAS LEAK
1. Start engine and run it at idle.
2. Listen for an exhaust gas leak before the three way catalyst (manifold).
Is exhaust gas leak detected?
YES >> Repair or replace error-detected parts.
NO >> GO TO 3.
3.CHECK INTAKE AIR LEAK
Listen for an intake air leak after the mass air flow sensor.
Is intake air leak detected?
YES >> Repair or replace error-detected parts.
NO >> GO TO 4.
4.CHECK IGNITION TIMING AND IDLE SPEED
Check the following items. Refer to EC-170, "Work Procedure"
.
For specification, refer to EC-541, "Ignition Timing"
For specification, refer to EC-541, "Idle Speed".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Follow the EC-170, "Work Procedure"
.
5.CHECK FUEL INJECTOR
Check the fuel injector. Refer to EC-505, "Component Function Check"
.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform EC-505, "Diagnosis Procedure"
.
6.CHECK FUNCTION OF IGNITION COIL-1
CAUTION:
Do the following procedure in the place where ventilation is good without the combustible.
1. Turn ignition switch OFF.
2. Remove fuel pump fuse in IPDM E/R to release fuel pressure. NOTE:
Do not use CONSULT to release fuel pressure, or fuel pressure applies again during the following proce-
dure.
3. Start engine.
4. After engine stalls, crank it two or three times to release all fuel pressure.
5. Turn ignition switch OFF.
6. Remove all ignition coil harness connectors to avoi d the electrical discharge from the ignition coils.
7. Remove ignition coil and spark plug of the cylinder to be checked.
PBIB1216E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1335 of 4801
![NISSAN TEANA 2014 Service Manual
P0420 THREE WAY CATALYST FUNCTIONEC-335
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect NISSAN TEANA 2014 Service Manual
P0420 THREE WAY CATALYST FUNCTIONEC-335
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect](/manual-img/5/57390/w960_57390-1334.png)
P0420 THREE WAY CATALYST FUNCTIONEC-335
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect spark plug and harness connector to ignition coil.
10. Fix ignition coil using a rope etc. with gap of 13 - 17 mm (0.52 -
0.66 in) between the edge of the spark plug and grounded metal
portion as shown in the figure.
11. Crank engine for about 3 seconds, and check whether spark is
generated between the spark plug and the grounded metal por-
tion.
CAUTION:
• Do not approach to the spar k plug and the ignition coil
within 50 cm (19.7 in). Be car eful not to get an electrical
shock while checking, becau se the electrical discharge
voltage becomes 20 kV or more.
• It might cause to damage the igni tion coil if the gap of more than 17 mm (0.66 in) is taken.
NOTE:
When the gap is less than 13 mm (0.52 in), the sp ark might be generated even if the coil is mal-
functioning.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 7.
7.CHECK FUNCTION OF IGNITION COIL-2
1. Turn ignition switch OFF.
2. Disconnect spark plug and connect a known-good spark plug.
3. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and the grounded metal portion.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Check ignition coil, power transistor and their circuits. Refer to EC-511, "Diagnosis Procedure"
.
8.CHECK SPARK PLUG
Check the initial spark plug for fouling, etc. Refer to EM-16,
"Removal and Installation".
Is the inspection result normal?
YES >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to EM-111, "Standard and Limit"
.
NO >> Repair or clean spark plug. Refer to EM-16, "Removal
and Installation". Then GO TO 9
9.CHECK FUNCTION OF IGNITION COIL-3
1. Reconnect the initial spark plugs.
2. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and
the grounded portion.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to EM-111, "Standard
and Limit".
Spark should be generated.
JMBIA0066GB
Spark should be generated.
SEF156I
Spark should be generated.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1336 of 4801
EC-336
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0420 THREE WAY CATALYST FUNCTION
10.CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Remove fuel injector assembly.
Refer to EM-41, "Exploded View"
.
Keep fuel hose and all fuel injectors connected to fuel tube.
3. Disconnect all ignition coil harness connectors.
4. Reconnect all fuel injector harness connectors disconnected.
5. Turn ignition switch ON.
Does fuel drip from fuel injector?
YES >> GO TO 11.
NO >> Replace the fuel injector(s) from which fuel is dripping. Refer to EM-41, "Exploded View"
.
11 .CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
Is the trouble fixed?
YES >> INSPECTION END
NO >> Replace three way catalyst assembly. Refer to EM-33, "Exploded View"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
