Page 1113 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-113
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
VVT
SYSTEM 35H VVT Monitor (Bank1)
P0011 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0

ECM
EC-113
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
VVT
SYSTEM 35H VVT Monitor (Bank1)
P0011 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0014 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0011 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0014 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100A 84H 10H VEL slow response diagnosis P1090 85H 10H VEL servo system diagnosis
P0011 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052A Retarded: P052B 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
36H VVT Monitor (Bank2) P0021 80H 9DH
VTC intake function diagnosis (VTC
alignment check diagnosis)
P0024 81H 9DH VTC exhaust function diagnosis (VTC
alignment check diagnosis)
P0021 82H 9DH VTC intake function diagnosis (VTC
drive failure diagnosis)
P0024 83H 9DH VTC exhaust function diagnosis (VTC
drive failure diagnosis)
P100B 84H 10H VEL slow response diagnosis P1093 85H 10H VEL servo system diagnosis
P0021 86H 9DH VTC intake intermediate lock function
diagnosis (VTC intermediate position
alignment check diagnosis)
Advanced: P052C Retarded: P052D 87H 9DHVTC intake intermediate lock system
diagnosis (VTC intermediate lock posi-
tion check diagnosis)
EVAP
SYSTEM 39H
EVAP control system leak
(Cap Off) P0455 80H 0CHDifference in pressure sensor output
voltage before and after pull down
3BH EVAP control system leak
(Small leak) P0442 80H 05H
Leak area index (for more than 0.04
inch)
3CH EVAP control system leak
(Very small leak) P0456 80H 05H
Leak area index (for more than 0.02
inch)
P0456 81H FDH Maximum internal pressure of EVAP
system during monitoring
P0456 82H FDH Internal pressure of EVAP system at
the end of monitoring
3DH Purge flow system P0441 83H 0CH Difference in pressure sensor output
voltage before and after vent control
valve close
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1114 of 4801

NISSAN TEANA 2014 Service Manual
EC-114
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
O2 SEN-
SOR
HEATER 41H A/F sensor 1 heater (Bank 1)
Low Input: P0031
High Input: P0032 81H 0BHConverted value of heater electric cur-
rent to volta

EC-114
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
O2 SEN-
SOR
HEATER 41H A/F sensor 1 heater (Bank 1)
Low Input: P0031
High Input: P0032 81H 0BHConverted value of heater electric cur-
rent to voltage
42H Heated oxygen sensor 2 heat-
er (Bank 1) Low Input: P0037
High Input: P0038 80H 0CH
Converted value of heater electric cur-
rent to voltage
43H Heated oxygen sensor 3 heat-
er (Bank 1) P0043 80H 0CHConverted value of heater electric cur-
rent to voltage
45H A/F sensor 1 heater (Bank 2) Low Input: P0051
High Input: P0052 81H 0BHConverted value of heater electric cur-
rent to voltage
46H Heated oxygen sensor 2 heat-
er (Bank 2) Low Input: P0057
High Input: P0058 80H 0CH
Converted value of heater electric cur-
rent to voltage
47H Heated oxygen sensor 3 heat-
er (Bank 2) P0063 80H 0CHConverted value of heater electric cur-
rent to voltage
SEC-
OND-
ARY AIR 71H Secondary air system P0411 80H 01H
Secondary air injection system incor-
rect flow detected
Bank1: P0491
Bank2: P0492 81H 01H
Secondary air injection system insuffi-
cient flow
P2445 82H 01H Secondary air injection system pump
stuck off
P2448 83H 01H Secondary air injection system high
airflow
Bank1: P2440
Bank2: P2442 84H 01H
Secondary air injection system switch-
ing valve stuck open
P2440 85H 01H Secondary air injection system switch-
ing valve stuck open
P2444 86H 01H Secondary air injection system pump
stuck on
FUEL
SYSTEM 81H
Fuel injection system function
(Bank 1) P0171 or P0172 80H 2FH Long term fuel trim
P0171 or P0172 81H 24H The number of lambda control
clamped
P117A 82H 03H Cylinder A/F imbalance monitoring
82H Fuel injection system function
(Bank 2) P0174 or P0175 80H 2FH Long term fuel trim
P0174 or P0175 81H 24H The number of lambda control
clamped
P117B 82H 03H Cylinder A/F imbalance monitoring
Item
OBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1115 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-115
< ECU DIAGNOSIS INFORMATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
MISFIRE A1H Multiple cylinder misfires P0301 80H 24H
Misfiring counter at 1000 revolution of
the first cylinder
P0

Page 1116 of 4801

NISSAN TEANA 2014 Service Manual
EC-116
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
MISFIREA2H No. 1 cylinder misfire
P0301 0BH 24H
EWMA (Exponential Weighted Moving
Average) misfire counts for last 10 driv-
ing cycles
P0301 0CH 24H

Page 1117 of 4801

NISSAN TEANA 2014 Service Manual
ENGINE CONTROL SYSTEMEC-117
< WIRING DIAGRAM > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
WIRING DIAGRAM
ENGINE CONTROL SYSTEM
Wiring DiagramINFOID:0000000009462126
FOR CALIFORNIA
ABBWA1118GB
Revision

Page 1118 of 4801

NISSAN TEANA 2014 Service Manual
EC-118
< WIRING DIAGRAM >[QR25DE]
ENGINE CONTROL SYSTEM
ABBWA0994GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1119 of 4801

NISSAN TEANA 2014 Service Manual
ENGINE CONTROL SYSTEMEC-119
< WIRING DIAGRAM > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ABBWA0879GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1120 of 4801

NISSAN TEANA 2014 Service Manual
EC-120
< WIRING DIAGRAM >[QR25DE]
ENGINE CONTROL SYSTEM
ABBWA0880GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
