LAN-116
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 4)]
MAIN LINE BETWEEN M&A AND
A-BAG CIRCUIT (WITH AUTO A/C)
MAIN LINE BETWEEN M&A AND A- BAG CIRCUIT (WITH AUTO A/C)
Diagnosis ProcedureINFOID:0000000009461487
1.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the following harness connectors.
- Combination meter
- A/C auto amp.
-ECM
4. Check the continuity between the combination meter harness connector and the A/C auto amp. harness
connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the combination meter and the air bag diag-
nosis sensor unit.
NO >> Repair the main line between the air bag diagnosis sensor unit and the air bag diagnosis sensor
unit.
Combination meter harness connector A/C auto amp. harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M24 39
M152 1 Existed
38 21 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
