Page 3569 of 4801

NISSAN TEANA 2014 Service Manual
PWC-62
< SYMPTOM DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
DOOR KEY CYLINDER SWITCH DOES
NOT OPERATE POWER WINDOWS
DOOR KEY CYLINDER SWITCH DOES NOT OPERATE POWER WIN-
DOWS
Diagnosis ProcedureINFOID:000

Page 3570 of 4801

NISSAN TEANA 2014 Service Manual
KEYLESS POWER WINDOW DOWN DOES NOT OPERATEPWC-63
< SYMPTOM DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
Diagnosis ProcedureIN

Page 3571 of 4801

NISSAN TEANA 2014 Service Manual
PWC-64
< PERIODIC MAINTENANCE >[LH FRONT ONLY ANTI-PINCH]
PRE-INSPECTION FOR DIAGNOSTIC
PERIODIC MAINTENANCE
PRE-INSPECTION
FOR DIAGNOSTIC
Basic InspectionINFOID:0000000009460887
BASIC INSPECTION
1.

Page 3572 of 4801

NISSAN TEANA 2014 Service Manual
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCHPWC-65
< REMOVAL AND INSTALLATION > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REMOVAL AND INSTALLATION
MAIN POWER WINDOW AND DOOR LO

Page 3573 of 4801

NISSAN TEANA 2014 Service Manual
PWC-66
< REMOVAL AND INSTALLATION >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
POWER WINDOW AND DOOR
LOCK/UNLOCK SWITCH RH
Removal and InstallationINFOID:0000000009460889

Page 3574 of 4801

NISSAN TEANA 2014 Service Manual
REAR POWER WINDOW SWITCHPWC-67
< REMOVAL AND INSTALLATION > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR POWER WINDOW SWITCH
Removal and Installation INFOID:0000000009460890
R

Page 3575 of 4801

NISSAN TEANA 2014 Service Manual
PWC-68
< PRECAUTION >[LH & RH FRONT ANTI-PINCH]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951562

PWC-68
< PRECAUTION >[LH & RH FRONT ANTI-PINCH]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951562
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000009460892
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3576 of 4801

NISSAN TEANA 2014 Service Manual
PREPARATIONPWC-69
< PREPARATION > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009460893
The actual shapes of the tools may
