NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-561
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
The mass air flow sensor (1) is plac
ed in the stream of intake air. It
measures the intake flow rate by measuri

COMPONENT PARTSEC-561
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
The mass air flow sensor (1) is plac
ed in the stream of intake air. It
measures the intake flow rate by measuring a part of the entire
intake flow. The mass air flow sens or controls the temperature of the
hot wire to a certain amount. The heat generated by the hot wire is
reduced as the intake air flows around it. The more air, the greater
the heat loss.
Therefore, the electric current supplied to hot wire is changed to
maintain the temperature of the hot wire as air flow increases. The
ECM detects the air flow by means of this current change.
INTAKE AIR TEMPERATURE SENSOR
The intake air temperature sensor is built-into mass air flow sensor. The sensor detects intake air temperature
and transmits a signal to the ECM.
The temperature sensing unit uses a thermistor which is sensitive to the change in temperature. Electrical
resistance of the thermistor decreases in response to the temperature rise.

*: These data are reference values and are measured between ECM terminals.
Oil Pressure Warning LampINFOID:0000000009462506
Oil pressure warning lamp is located on the combination meter.
It indicates the low pressure of the engine oil and the malfunction of
the engine oil pressure system.
Combination meter turns the oil pressure warning lamp ON/OFF
according to the oil pressure warning lamp signal received from
ECM via CAN communication.
For details, refer to EC-583, "ENGINE PROTECTION CONTROL AT
LOW ENGINE OIL PRESSURE : System Description".
Power Valve Actuator 1 and 2INFOID:0000000009462507
The power valves are used to control the suction pa ssage of the variable induction air control system. They
are set in the fully closed or fully opened position by t he power valve actuators operated by the vacuum stored
in the vacuum tank. The vacuum to power valve actuat ors is controlled by the VIAS control solenoid valves.
PBIA9559J
Intake air temperature
[° C ( °F)] Voltag e* (V)
Resistance (k
Ω)
25 (77) 3.3 1.800 - 2.200
80 (176) 1.2 0.283 - 0.359
SEF012P
PBIA8559J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1562 of 4801

NISSAN TEANA 2014 Service Manual
EC-562
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
Refrigerant Pressure Sensor
INFOID:0000000009462508
The refrigerant pressure sensor is installed at the c ondenser of the air conditioner system.

Page 1563 of 4801

NISSAN TEANA 2014 Service Manual
STRUCTURE AND OPERATIONEC-563
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
STRUCTURE AND OPERATION
Positive Crankcase Ventilation (PCV)INFOID:0000000009462511
This system returns

Page 1564 of 4801

NISSAN TEANA 2014 Service Manual
EC-564
< SYSTEM DESCRIPTION >[VQ35DE]
STRUCTURE AND OPERATION
On Board Refueling V apor Recovery (ORVR)
INFOID:0000000009462512
From the beginning of refueling, the air and vapor insi de the fuel tan

Page 1565 of 4801

NISSAN TEANA 2014 Service Manual
SYSTEMEC-565
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
SYSTEM
ENGINE CONTROL SYSTEM
ENGINE CONTROL SYSTEM : System DescriptionINFOID:0000000009462513
SYSTEM DIAGRAM
SYSTEM DES

Page 1566 of 4801

NISSAN TEANA 2014 Service Manual
EC-566
< SYSTEM DESCRIPTION >[VQ35DE]
SYSTEM
ECM controls the engine by various functions.
ENGINE CONTROL SYSTEM : Fail-safeINFOID:0000000009462514
NON DTC RELATED ITEM
DTC RELATED ITEM
Function Ref

EC-566
< SYSTEM DESCRIPTION >[VQ35DE]
SYSTEM
ECM controls the engine by various functions.
ENGINE CONTROL SYSTEM : Fail-safeINFOID:0000000009462514
NON DTC RELATED ITEM
DTC RELATED ITEM
Function Reference
Multiport fuel injection system EC-568, "MULTIPORT FUEL INJE
CTION SYSTEM : System De-
scription"
Electric ignition system EC-571, "ELECTRIC IGNITION SYSTEM : System Description"
Air conditioning cut control EC-573, "AIR CONDITIONING CUT
CONTROL : System Descrip-tion"
Automatic speed control device (ASCD) EC-574, "AUTOMATIC SPEED CONTROL DEVICE (ASCD) : System Description"
Cooling fan control
EC-575, "COOLING FAN CONTROL : System Description"
Electronic controlled engine mount EC-577, "ELECTRONIC CONTROLLED ENGINE MOUNT : Sys-tem Description"
Evaporative emission systemEC-580, "EVAPORATIVE EMISSI
ON SYSTEM : System Descrip-tion"
Throttle control EC-581, "THROTTLE CONTROL : System Description"
Intake valve timing control EC-583, "INTAKE VALVE TIMING
CONTROL : System Descrip-tion"
Engine protection control at low engine oil pressure EC-583, "ENGINE PROTECTION
CONTROL AT LOW ENGINE OIL PRESSURE : System Description"
Fuel filler cap warning system EC-585, "FUEL FILLER CAP WARNING SYSTEM : System De-scription"
Variable induction air systemEC-586, "VARIABLE INDUCTION AI
R SYSTEM : System Descrip-tion"
Integrated control of engine, CVT, and ABS EC-588, "INTEGRATED CONTROL OF ENGINE, CVT, AND ABS : System Description"
Alternator power generation voltage variable control systemEC-588, "ALTERNATOR POWER GENERATION VOLTAGE VARIABLE CONTROL SYSTEM
: System Description"
CAN communication EC-588, "CAN COMMUNICATION : System Description"
Engine operating condi-
tion in fail-safe mode Detected items Remarks Reference
page
Engine speed will not
rise more than 2,500 rpm
due to the fuel cut Malfunction indicator
lamp circuit When there is an open circuit on MIL circuit, the ECM cannot warn the
driver by illuminating MIL when there is malfunction on engine control
system.
Therefore, when electrical controlled throttle and part of ECM related
diagnoses are continuously detected as NG for 5 trips, ECM warns the
driver that engine control system malfunctions and MIL circuit is open
by means of operating the fail-safe function.
The fail-safe function also operates when above diagnoses except MIL
circuit are detected and demands the driver to repair the malfunction. EC-973
DTC No. Detected items Engine operating condition in fail-safe mode
P0011
P0021 Intake valve timing control The signal is not energized to the intake valve timing control solenoid valve and the valve
control does not function.
P0101
P0102
P0103 Mass air flow sensor circuit Engine speed will not rise more than 2,400 rpm due to the fuel cut.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1567 of 4801

NISSAN TEANA 2014 Service Manual
SYSTEMEC-567
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0117
P0118 Engine coolant tempera-
ture sensor circuit Engine coolant temperature will be determined by ECM based on th

SYSTEMEC-567
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0117
P0118 Engine coolant tempera-
ture sensor circuit Engine coolant temperature will be determined by ECM based on the following condition.
CONSULT displays the engine coolant temperature decided by ECM.
Condition Engine coolant temperature decided
(CONSULT display)
Just as ignition switch is turned ON
or START 40
°C (104 °F)
Approx 4 minutes or more after en-
gine starting 80
°C (176 °F)
Except as shown above 40 - 80
°C (104 - 176 °F)
(Depends on the time)
When the fail-safe system for engine coolant temperature sensor is activated, the cooling
fan operates while engine is running.
P0122
P0123
P0222
P0223
P2135 Throttle position sensor The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
Therefore, the acceleration will be poor.
P0196
P0197
P0198 Engine oil temperature
sensor Intake valve timing control does not function.
P0500 Vehicle speed sensor The cooling fan operates (Highest) while engine is running.
P0524 Engine oil pressure • ECM illuminates oil pressure warning lamp on the combination meter.
• Engine speed will not rise more than 4,000 rpm due to the fuel cut.
• Fail-safe is canceled when ignition switch OFF → ON.
P0605 ECM (When ECM calculation function is malfunctioning:) ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
ECM deactivates ASCD operation.
P0643 Sensor power supply ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
P1805 Brake switch ECM controls the electric throttle control actuator by regulating the throttle opening to a small range.
Therefore, acceleration will be poor.
Vehicle condition Driving condition
When engine is idling Normal
When accelerating Poor acceleration
P2100
P2103 Throttle control motor relay ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2101 Electric th rottle control
function ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2118 Throttle control motor ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
DTC No. Detected items Engine operating condition in fail-safe mode
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1568 of 4801

NISSAN TEANA 2014 Service Manual
EC-568
< SYSTEM DESCRIPTION >[VQ35DE]
SYSTEM
MULTIPORT FUEL INJECTION SYSTEM
MULTIPORT FUEL INJECTION SY
STEM : System DescriptionINFOID:0000000009462515
SYSTEM DIAGRAM
*1: Automatic air conditioning
