Page 2361 of 4801

HEADLAMP (LO) CIRCUITEXL-95
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Headlamp (LO) is normal.
NO >> Refer to EXL-95, "HEADLAMP (XEN ON) : Diagnosis Procedure"
.
HEADLAMP (XENON) : Diagnosis ProcedureINFOID:0000000009463585
Regarding Wiring Diagram information, refer to EXL-33, "Wiring Diagram - Xenon".
1.CHECK HEADLAMP (LO) FUSES
1. Turn the ignition switch OFF.
2. Check that the following fuses are not blown.
Is the fuse blown?
YES >> Replace the fuse after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK HEADLAMP (LO) OUTPUT VOLTAGE
CONSULT
1. Turn the ignition switch OFF.
2. Disconnect the front combination lamp harness connector E232 or E243 in question.
3. Turn the ignition switch ON.
4. Select EXTERNAL LAMP of IP DM E/R active test item.
5. With EXTERNAL LAMP ON, check the voltage betw een the combination lamp connector E243 or E232
terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK HEADLAMP (LO) CIRCUIT FOR OPEN
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector E200.
3. Check continuity between the IPDM E/R harness c onnector E200 and the front combination lamp harness
connector E243 or E232.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
LO : Headlamp ON
OFF : Headlamp OFF
Unit Location Fuse No. Capacity
Headlamp LO (RH) IPDM E/R 36 15A
Headlamp LO (L H) IPDM E/R 37 15A
(+)
(− )Voltage
Connector Terminal
RH E243 1 Ground Battery voltage
LH E232
IPDM E/R Front combination lamp Continuity
Connector Terminal Connector Terminal
RH E20075 E243
1Yes
LH 76 E232
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2362 of 4801
EXL-96
< DTC/CIRCUIT DIAGNOSIS >
HEADLAMP (LO) CIRCUIT
NO >> Repair or replace the harness or connector.
4.CHECK FRONT COMBINATION LAMP (LO) GROUND CIRCUIT
Check continuity between the front combination lamp harness connector terminal and ground.
Is the inspection result normal?
YES >> Perform xenon headlamp diagnosis. Refer to EXL-97, "Diagnosis Procedure".
NO >> Repair or replace the harness or connector.
Connector Terminal — Continuity
RH E243 2GroundYes
LH E232
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2363 of 4801

XENON HEADLAMPEXL-97
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
XENON HEADLAMP
DescriptionINFOID:0000000009463586
OPERATION
Refer to EXL-9, "HEADLAMP SYSTEM : System Description".
PRECAUTIONS FOR TROUBLE DIAGNOSIS
• Installation or removal of the connecto r must be done with the lighting switch OFF.
• When the lamp is illuminated (when the lighting switch is ON), do not touch the harness, HID control unit,
inside of the lamp, or the lamp metal parts.
• To check illumination, temporarily install lamp in the vehicle. Be sure to connect power at the vehicle-side
connector.
• If the malfunction can be traced directly to the electrical system, first check for items such as blown fuses
and fusible links, broken wires or loose connectors , pulled-out terminals, and improper connections.
• Do not work with wet hands.
• Using a tester for HID control unit circuit trouble diagnosis is prohibited.
• Disassembling the HID control unit or harnesses (bul b socket harness, ballast harness) is prohibited.
• Immediately after illumination, the light int ensity and color will fluctuate, this is normal.
• When the bulb has reached the end of its lifetime, the br ightness may drop significantly, it may flash repeat-
edly, or the light may turn a reddish color.
Diagnosis ProcedureINFOID:0000000009463587
1.CHECK XENON BULB
Install a known good bulb to the applicable headlamp. Check that the headlamp operates.
Is the inspection result normal?
YES >> Replace the xenon bulb.
NO >> GO TO 2.
2.CHECK HID CONTROL UNIT
Install a known good HID control unit to the appl icable headlamp. Check that the headlamp operates.
Is the inspection result normal?
YES >> Replace HID control unit.
NO >> Inspection End.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2364 of 4801

EXL-98
< DTC/CIRCUIT DIAGNOSIS >
DAYTIME LIGHT RELAY CIRCUIT
DAYTIME LIGHT RELAY CIRCUIT
DescriptionINFOID:0000000009463588
The BCM sends a daytime light request to the IPDM E/R via the CAN communication lines. The power flows
through fuse 43 located in IPDM E/R to the daytime li ght relay coil. When the IPDM E/R operates the daytime
light relay, power is sent to the daytime lamps.
Diagnosis ProcedureINFOID:0000000009463589
Regarding Wiring Diagram information, refer to EXL-39, "Wiring Diagram".
1.CHECK DAYTIME LIGHT RELAY VOLTAGE SUPPLY
1. Turn the ignition switch OFF.
2. Remove the daytime light relay.
3. Check the voltage between the daytime light relay harness connector E228 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DAYTIME LIGHT RELAY CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R harness connector E18.
3. Check continuity between the IPDM E/R harness c onnector E18 and the daytime light relay harness con-
nector E228.
4. Check continuity between the IP DM E/R harness connector E18 and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace the harness or connector.
3.CHECK DAYTIME LIGHT RELAY CONTROL CIRCUIT
1. Turn the ignition switch OFF.
2. Check continuity between the IPDM E/R harness connector E201 and the daytime light relay harness
connector E228.
Daytime light relay (− )Voltage
Connector Terminal
E228 2
Ground Battery voltage
5
Daytime light relay IPDM E/R Continuity
Connector Terminal Connector Terminal
E228 2
E18 14 Ye s
5
Connector Terminal — Continuity
E18 14 Ground No
Daytime light relay IPDM E/R Continuity
Connector Terminal Connector Terminal
E228 1 E201 85 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2365 of 4801

DAYTIME LIGHT RELAY CIRCUITEXL-99
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
3. Check continuity between the daytime light relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connector.
4.CHECK DAYTIME LIGHT RELAY
Check the daytime light relay. Refer to EXL-99, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace relay.
5.CHECK DAYTIME LIGHT CIRCUIT (OPEN OR SHORT TO GROUND)
1. Turn the ignition switch OFF.
2. Check continuity between the daytime light rela y harness connector E228 and the front fog lamp harness
connector.
3. Check continuity between the daytime light relay harness connector E228 and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the harness or connector.
6.CHECK DAYTIME LIGHT GROUND CIRCUIT FOR OPEN
1. Turn the ignition switch OFF.
2. Disconnect front fog lamp connector E234 or E237 in question.
3. Check continuity between the front fog lamp connector E234 or E237 and ground.
Is the inspection result normal?
YES >> Inspect daytime light bulb.
NO >> Repair or replace the harness or connector.
Component InspectionINFOID:0000000009463590
1. CHECK DAYTIME LIGHT RELAY
1. Turn ignition switch OFF.
2. Remove daytime light relay.
3. Check the continuity between daytime light relay terminals 3 and 5 when voltage is supplied between ter- minals 1 and 2.
Connector Terminal — Continuity
E228 1 Ground No
Daytime light relay Front fog lamp Continuity
Connector Terminal Connector Terminal
E228 3 LH E234
3Yes
RH E237
Daytime light relay (− )Continuity
Connector Terminal
E228 3 Ground No
Connector Terminal — ContinuityLH E234 4Ground Yes
RH E237
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2366 of 4801
EXL-100
< DTC/CIRCUIT DIAGNOSIS >
DAYTIME LIGHT RELAY CIRCUIT
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace daytime light relay.
Terminals Condition Continuity
3 and 5 12V direct current supply between terminals 1 and 2 Yes
No current supply No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2367 of 4801

FRONT FOG LAMP CIRCUITEXL-101
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
FRONT FOG LAMP CIRCUIT
DescriptionINFOID:0000000009463591
The IPDM E/R (intelligent power di stribution module engine room) controls the front fog lamp relay based on
inputs from the BCM over the CAN communication lines . When the front fog lamp relay is energized, power
flows from the front fog lamp relay in the IPDM E/R to the front fog lamps.
Component Function CheckINFOID:0000000009463592
1.CHECK FRONT FOG LAMP OPERATION
WITHOUT CONSULT
1. Activate IPDM E/R auto active test. Refer to PCS-9, "CONSULT Function (IPDM E/R)"
.
2. Check that the front fog lamp is turned ON.
WITH CONSULT
1. Select EXTERNAL LAMP of IP DM E/R active test item.
2. While operating the test items, check that the front fog lamp is turned ON.
Is the inspection result normal?
YES >> Front fog lamp circuit is normal.
NO >> Refer to EXL-101, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009463593
Regarding Wiring Diagram information, refer to EXL-54, "Wiring Diagram".
1.CHECK FRONT FOG LAMP FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuse is not blown.
Is the fuse blown?
YES >> Replace the fuse after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK FRONT FOG LAMP OUTPUT VOLTAGE
CONSULT
1. Turn the ignition switch OFF.
2. Disconnect the front fog lamp harness connector E214 or E227 in question.
3. Turn the ignition switch ON.
4. Turn the front fog lamps ON.
5. Check the voltage between the front fog lamp harness connector E214 or E227 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 4. FOG : Front fog lamp ON
OFF : Front fog lamp OFF
Unit Location Fuse No. Capacity
Front fog lamp IPDM E/R 42 15A
(+) (− )Voltage
Connector Terminal
LH E214 1 Ground Battery voltage
RH E227
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2368 of 4801
EXL-102
< DTC/CIRCUIT DIAGNOSIS >
FRONT FOG LAMP CIRCUIT
NO >> GO TO 3.
3.CHECK FRONT FOG LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector E200.
3. Check continuity between the IPDM E/R harness connector and the front fog lamp harness connector.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace the harness or connector.
4.CHECK FRONT FOG LAMP GROUND CIRCUIT
Check continuity between the front fog lamp harness connector terminal 2 and ground.
Is the inspection result normal?
YES >> Inspect the fog lamp bulb.
NO >> Repair or replace the harness or connector.
IPDM E/R Front fog lamp Continuity
Connector Terminal Connector Terminal
RH E20078 E227
1Yes
LH 79 E214
Connector Terminal — Continuity
RH E227 2 Ground Yes
LH E214
