Page 4713 of 4801

NISSAN TEANA 2014 Service Manual
WT-38
< DTC/CIRCUIT DIAGNOSIS >
C1720, C1721, C1722, C1723 TRANSMITTER
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Inspection End.
Revision: November 20132014 Altima NAMRe

Page 4714 of 4801

NISSAN TEANA 2014 Service Manual
C1724, C1725, C1726, C1727 TRANSMI TTER (BATT VOLT)
WT-39
< DTC/CIRCUIT DIAGNOSIS >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
C1724, C1725, C1726, C1727 TR ANSMITTER (BATT VOLT)
DTC LogicINFOID:000000000946

C1724, C1725, C1726, C1727 TRANSMI TTER (BATT VOLT)
WT-39
< DTC/CIRCUIT DIAGNOSIS >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
C1724, C1725, C1726, C1727 TR ANSMITTER (BATT VOLT)
DTC LogicINFOID:0000000009464504
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure repor ted by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM SELF DIAGNOSTIC RESULT
With CONSULT
1. Drive at a speed of 40 km/h (25 MPH) or more fo r 3 minutes, and then drive the vehicle at any speed for
10 minutes.
2. Perform Self Diagnostic Result.
Is DTC C1724, C1725, C1726, or C1727 detected?
YES >> Proceed to WT-39, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009464505
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure repor ted by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
1.TIRE PRESSURE SENS OR ID REGISTRATION
Perform tire pressure sensor ID registration. Refer to WT-25, "Work Procedure"
.
Can the tire pressure sensor ID registration be completed?
YES >> GO TO 2.
NO >> Replace applicable tire pressure sensor. Refer to WT-57, "Removal and Installation"
.
2.PERFORM SELF DIAGNOSTIC RESULT
With CONSULT
1. Drive at a speed of 40 km/h (25 MPH) or more fo r 3 minutes, and then drive the vehicle at any speed for
10 minutes.
2. Perform Self Diagnostic Result.
Is DTC C1724, C1725, C1726, or C1727 detected?
CONSULT Display DTC Detection Condition Possible Cause
[BATT - VOLT - LOW] - FL
[C1724] Battery voltage of front LH wheel sensor drops.
• Tire pressure sensor
•BCM
[BATT - VOLT - LOW] - FR
[C1725] Battery voltage of front RH wheel sensor drops.
[BATT - VOLT - LOW] - RR
[C1726] Battery voltage of rear RH wheel sensor drops.
[BATT - VOLT - LOW] - RL
[C1727] Battery voltage of rear LH wheel sensor drops.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4715 of 4801

NISSAN TEANA 2014 Service Manual
WT-40
< DTC/CIRCUIT DIAGNOSIS >
C1724, C1725, C1726, C1727 TRANSMITTER (BATT VOLT)
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Inspection End.
Revision: November 20132014

Page 4716 of 4801

NISSAN TEANA 2014 Service Manual
C1729 VEHICLE SPEED SIGNALWT-41
< DTC/CIRCUIT DIAGNOSIS >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
C1729 VEHICLE SPEED SIGNAL
DTC LogicINFOID:0000000009464506
NOTE:
The Signal Tech II Tool (J-50190) can b

Page 4717 of 4801

NISSAN TEANA 2014 Service Manual
WT-42
< DTC/CIRCUIT DIAGNOSIS >
C1730, C1731, C1732, C1733 FLAT TIRE
C1730, C1731, C1732, C1733 FLAT TIRE
DTC LogicINFOID:0000000009464508
NOTE:
The Signal Tech II Tool (J-50190) can be used to perf

WT-42
< DTC/CIRCUIT DIAGNOSIS >
C1730, C1731, C1732, C1733 FLAT TIRE
C1730, C1731, C1732, C1733 FLAT TIRE
DTC LogicINFOID:0000000009464508
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM SELF DIAGNOSTIC RESULT
With CONSULT
1. Drive at a speed of 40 km/h (25 MPH) or more fo r 3 minutes, and then drive the vehicle at any speed for
10 minutes.
2. Perform Self Diagnostic Result.
Is DTC C1730, C1731, C1732, or C1733 detected?
YES >> Proceed to WT-42, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009464509
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
1.TIRE PRESSURE SENSOR ID REGISTRATION
Perform tire pressure sensor ID registration. Refer to WT-25, "Work Procedure"
.
Can the tire pressure sensor ID registration be completed?
YES >> GO TO 2.
NO >> Replace applicable tire pressure sensor. Refer to WT-57, "Removal and Installation"
.
2.CHECK TIRE PRESSURE
Check the air pressure of all wheels. Refer to WT-60, "Tire"
.
Is the inspection result normal?
YES >> Perform DTC CONFIRMATION PROCEDURE again. Refer to WT-42, "DTC Logic".
NO >> GO TO 3.
CONSULT Display DTC Detectio n Condition Possible Cause
FLAT TIRE FL
[C1730] Front LH tire pressure is 70 kPa (0.7 kg/cm
2, 10
psi) or less.
• Low tire pressure
• Tire pressure sensor
FLAT TIRE FR
[C1731] Front RH tire pressure is 70 kPa (0.7 kg/cm
2, 10
psi) or less.
FLAT TIRE RR
[C1732] Rear RH tire pressure is 70 kPa (0.7 kg/cm
2, 10
psi) or less.
FLAT TIRE RL
[C1733] Rear LH tire pressure is 70 kPa (0.7 kg/cm
2, 10
psi) or less.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4718 of 4801

NISSAN TEANA 2014 Service Manual
C1730, C1731, C1732, C1733 FLAT TIRE
WT-43
< DTC/CIRCUIT DIAGNOSIS >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
3.CHECK TIRE PRESSURE SIGNAL
With CONSULT
1. Adjust tire pressure for all wheels to the speci

Page 4719 of 4801

NISSAN TEANA 2014 Service Manual
WT-44
< DTC/CIRCUIT DIAGNOSIS >
C1734 BCM
C1734 BCM
DTC LogicINFOID:0000000009464510
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech

Page 4720 of 4801

NISSAN TEANA 2014 Service Manual
C1734 BCMWT-45
< DTC/CIRCUIT DIAGNOSIS >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connectors.
4.CHECK REMOTE KEYLESS ENT
