Page 1497 of 4801
![NISSAN TEANA 2014 Service Manual
BRAKE PEDAL POSITION SWITCHEC-497
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NISSAN TEANA 2014 Service Manual
BRAKE PEDAL POSITION SWITCHEC-497
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.](/manual-img/5/57390/w960_57390-1496.png)
BRAKE PEDAL POSITION SWITCHEC-497
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK BRAKE PEDAL POSITION SWITCH INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between brake pedal posit ion switch harness connector and ECM harness connec-
tor.
*1: Except for California
*2: For California
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BRAKE PEDAL POSITION SWITCH
Check brake pedal position switch. Refer to EC-497, "Component Inspection (Brake Pedal Position Switch)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace brake pedal position switch. Refer to BR-18, "Exploded View"
.
Component Inspection (Brake Pedal Position Switch)INFOID:0000000009462430
1.CHECK BRAKE PEDAL POSITION SWITCH-1
1. Turn ignition switch OFF.
2. Disconnect brake pedal position harness connector.
3. Check the continuity between brake pedal position switch terminals as per the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK BRAKE PEDAL POSITION SWITCH-2
1. Adjust brake pedal position switch installation. Refer to BR-13, "Inspection and Adjustment"
.
2. Check the continuity between brake pedal position switch terminals as per the following conditions.
++
Continuity
Brake pedal position switch Fuse block (J/B)
Connector Terminal Connector Terminal E51 1 E6 1M Existed
++ Continuity
Brake pedal position switch ECM
Connector Terminal Connector Terminal
E51 2 E10
*1
E31*2116 Existed
Brake pedal position switch
Condition Continuity
+ −
Te r m i n a l s
1 2 Brake pedal Fully released Existed
Slightly de-
pressed Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1498 of 4801
EC-498
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
BRAKE PEDAL POSITION SWITCH
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace brake pedal position switch. Refer to BR-18, "Exploded View"
.
Brake pedal position switch
Condition Continuity
+ −
Te r m i n a l s
1 2 Brake pedal Fully released Existed
Slightly de-
pressed Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1499 of 4801
![NISSAN TEANA 2014 Service Manual
COOLING FANEC-499
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
COOLING FAN
Component Function CheckINFOID:0000000009462431
1.CHECK COOLING FAN FUNCTION
With CONSULT
1. Turn ign NISSAN TEANA 2014 Service Manual
COOLING FANEC-499
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
COOLING FAN
Component Function CheckINFOID:0000000009462431
1.CHECK COOLING FAN FUNCTION
With CONSULT
1. Turn ign](/manual-img/5/57390/w960_57390-1498.png)
COOLING FANEC-499
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
COOLING FAN
Component Function CheckINFOID:0000000009462431
1.CHECK COOLING FAN FUNCTION
With CONSULT
1. Turn ignition switch ON.
2. Perform “COOLING FAN” in “ACTIVE TE ST” mode of “ENGINE” using CONSULT.
3. Touch “LOW”, “MID”, “HI” on the CONSULT screen.
4. Check that cooling fan operates.
Without CONSULT
1. Activates IPDM E/R auto active test and check cooling fan motors operation, refer to PCS-8, "Diagnosis
Description".
2. Check that cooling fan operates.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-499, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462432
1.CHECK COOLING FAN RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect cooling fan relays-2, -3.
3. Turn ignition switch ON.
4. Check the voltage between cooling fan relays-2, -3 harness con- nectors and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis for power supply circuit.
2.CHECK COOLING FAN RELAY OUTPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connectors.
3. Check the continuity between cooling fan relay- 2, -3 harness connectors and IPDM E/R harness connec-
tor.
4. Also check harness for short to ground and to power.
Is the inspection result normal?
+
−Voltag e
Cooling fan relay
Connector Terminal
E42
(cooling fan relay-2) 2
Ground Battery voltage
5
E43
(cooling fan relay-3) 2
5
PBIB0071E
+ −
Continuity
Cooling fan relay IPDM E/R
Connector Terminal Connector Terminal E42
(cooling fan relay-2) 1
E63 27
Existed
E43
(cooling fan relay-3) 139
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1500 of 4801
![NISSAN TEANA 2014 Service Manual
EC-500
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK COOLING FAN MOTOR POWER SUPPLY CIRCUIT
1. Disconnect cooling fan motor-1 ha NISSAN TEANA 2014 Service Manual
EC-500
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK COOLING FAN MOTOR POWER SUPPLY CIRCUIT
1. Disconnect cooling fan motor-1 ha](/manual-img/5/57390/w960_57390-1499.png)
EC-500
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK COOLING FAN MOTOR POWER SUPPLY CIRCUIT
1. Disconnect cooling fan motor-1 harness connector.
2. Check the voltage between cooling fan motor-1 harness con- nector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Perform trouble diagnosis for power supply circuit.
4.CHECK COOLING FAN MOTOR CIRCUIT-1
1. Disconnect cooling fan motor-2 harness connector.
2. Check the continuity between cooling fan relay-2, -3 harness connectors and cooling fan motor-1, -2 har-
ness connectors.
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK COOLING FAN MOTOR CIRCUIT-2
1. Check the continuity between IPDM E/R harness connector and cooling fan motor-1, -2 harness connec-
tor.
2. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace error-detected parts.
+
−Voltag e
Cooling fan motor-1
Connector Terminal
E220 1
Ground Battery voltage
2
PBIB1670E
+ −
Continuity
Cooling fan relay Cooling fan motor
Connector Terminal Connector Terminal
E42
(cooling fan relay-2) 3
E221
(Cooling fan motor-2) 2
Existed
7
E220
(Cooling fan motor-1) 3
E43
(cooling fan relay-3) 3
E221
(Cooling fan motor-2) 1
7 E220
(Cooling fan motor-1) 4
+
−
Continuity
IPDM E/R Cooling fan motor
Connector Terminal Connector Terminal
E17 4
E220
(Cooling fan motor-1) 4
Existed
6 E221
(Cooling fan motor-2) 1
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1501 of 4801
![NISSAN TEANA 2014 Service Manual
COOLING FANEC-501
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
6.CHECK COOLING FAN MOTOR CIRCUIT-3
1. Check the continuity between cooling f an relay-2, -3 harness connectors a NISSAN TEANA 2014 Service Manual
COOLING FANEC-501
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
6.CHECK COOLING FAN MOTOR CIRCUIT-3
1. Check the continuity between cooling f an relay-2, -3 harness connectors a](/manual-img/5/57390/w960_57390-1500.png)
COOLING FANEC-501
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
6.CHECK COOLING FAN MOTOR CIRCUIT-3
1. Check the continuity between cooling f an relay-2, -3 harness connectors and ground.
2. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
7.CHECK COOLING FAN MOTOR CIRCUIT-4
1. Check the continuity between cooli ng fan motor-2 harness connector and ground.
2. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace error-detected parts.
8.CHECK COOLING FAN RELAY-2 AND -3
Refer to EC-502, "Component Inspection (Cooling Fan Relay)"
.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace malfunctioning cooling fan relay.
9.CHECK COOLING FAN MOTORS-1 AND -2
Refer to EC-501, "Component Inspection (Cooling Fan Motor)"
.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Replace malfunctioning cooling fan motor. Refer to CO-18, "Removal and Installation"
.
10.CHECK INTERMITTENT INCIDENT
Perform GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Component Inspection (Cooling Fan Motor)INFOID:0000000009462433
1.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
+
−Continuity
Cooling fan relay
Connector Terminal E42
(cooling fan relay-2) 6
Ground Existed
E43
(cooling fan relay-3) 6
+
−Continuity
Cooling fan motor-2
Connector Terminal
E221 3
Ground Existed
4
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1502 of 4801
![NISSAN TEANA 2014 Service Manual
EC-502
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
3. Supply cooling fan motor terminals with battery voltage and
check operation.
Check that cooling fan speed of cond ition B is higher than that NISSAN TEANA 2014 Service Manual
EC-502
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
3. Supply cooling fan motor terminals with battery voltage and
check operation.
Check that cooling fan speed of cond ition B is higher than that](/manual-img/5/57390/w960_57390-1501.png)
EC-502
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
COOLING FAN
3. Supply cooling fan motor terminals with battery voltage and
check operation.
Check that cooling fan speed of cond ition B is higher than that of A.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor. Refer to CO-18, "Removal and Installation"
.
Component Inspection (Cooling Fan Relay)INFOID:0000000009462434
1.CHECK COOLING FAN RELAYS
1. Turn ignition switch OFF.
2. Remove cooling fan relay-2, -3.
3. Check the continuity between cooling fan relay-2, -3 terminals as per the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan relay.
Cooling fan motor
Condition
Te r m i n a l
+– 1 3 and 4
A
2 3 and 4
1 and 2 3
1 and 2 4 1, 2 3, 4 B
SEF734W
Cooling fan relay-2, -3 Conditions Continuity
+ −
Te r m i n a l
35 12V direct current supply between termi-
nals 1 and 2 Existed
No current supply Not existed
67 12V direct current supply between termi-
nals 1 and 2 Existed
No current supply Not existed
PBIB0439E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1503 of 4801
![NISSAN TEANA 2014 Service Manual
ELECTRICAL LOAD SIGNALEC-503
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000009462435
The electrical load signal (Headlamp switch NISSAN TEANA 2014 Service Manual
ELECTRICAL LOAD SIGNALEC-503
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000009462435
The electrical load signal (Headlamp switch](/manual-img/5/57390/w960_57390-1502.png)
ELECTRICAL LOAD SIGNALEC-503
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000009462435
The electrical load signal (Headlamp switch signal, rear
window defogger switch signal, etc.) is transferred via
the CAN communication.
Component Function CheckINFOID:0000000009462436
1.CHECK REAR WINDOW DEF OGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Connect CONSULT and select “DATA MONITOR” mode.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to EC-503, "Diagnosis Procedure"
.
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Proceed to EC-503, "Diagnosis Procedure"
.
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-503, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462437
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-503, "Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2.
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Check rear window defogger system. Refer to DEF-16, "Work Flow"
.
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switch ON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switch ON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switchON ON
OFF OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1504 of 4801
EC-504
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Check headlamp system. Refer to EXL-86, "Work Flow"
.
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Check heater fan control system. Refer to HAC-46, "Work Flow"
(with automatic air conditioner) or HAC-139,
"Work Flow" (with manual air conditioner).
>> INSPECTION END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
