FRONT BUMPEREXT-19
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
EXT
N
O P
mm (in)
ALKIA2610ZZ
Section Measurement Minimum Target Value Maximum A-A Clearance 2.0 (0.08) 4.1 (0.16) 6.2 (0.24)
A-A Surface height -0.6 (-0.02) 0.8 (0.03) 2.0 (0.08)
B-B Clearance 0.2 (0.01) 1.5 (0.06) 2.8 (0.11)
B-B Surface height 0.8 (0.03) 2.1 (0.08) 3.4 (0.13)
C-C Clearance 0.2 (0.01) 1.5 (0.06) 2.8 (0.11)
C-C Surface height 3.2 (0.13) 4.5 (0.18) 5.8 (0.23)
D-D Clearance 0.2 (0.01) 1.5 (0.06) 2.8 (0.11)
D-D Surface height 2.2 (0.09) 3.5 (0.14) 4.8 (0.19) E-E Clearance -0.7 (-0.03) 0.0 (0.00) 0.7 (0.03)
E-E Surface height -1.0 (-0.04) 0.0 (0.00) 1.0 (0.04) F-F Clearance -0.8 (-0.03) 0.0 (0.00) 0.8 (0.03)
F-F Surface height -0.3 (-0.01) 0.7 (0.03) 1.7 (0.07)
G-G Clearance 0.2 (0.01) 1.5 (0.06) 3.2 (0.13)
H-H Clearance 0.2 (0.01) 1.5 (0.06) 3.2 (0.13) J-J Surface height 0.2 (0.01) 1.5 (0.06) 3.2 (0.13)
K-K Surface height 0.5 (0.02) 1.5 (0.06) 2.5 (0.10) L-L Surface height 0.5 (0.02) 1.5 (0.06) 2.5 (0.10)
M-M Surface height 0.5 (0.02) 1.5 (0.06) 2.5 (0.10) N-N Surface height 0.1 (0.00) 1.5 (0.06) 2.9 (0.11)
O-O Surface height 0.1 (0.00) 1.5 (0.06) 2.9 (0.11) P-P Surface height 0.1 (0.00) 1.5 (0.06) 2.9 (0.11)
Q-Q Clearance 0.0 (0.00) 0.5 (0.02) 1.0 (0.04)
Q-Q Surface height -0.2 (-0.01) 0.3 (0.01) 0.8 (0.03)
Revision: November 20132014 Altima NAM
Page 2434 of 4801
EXT-20
< REMOVAL AND INSTALLATION >
REAR BUMPER
REAR BUMPER
Exploded ViewINFOID:0000000009460996
1. Rear bumper side bracket (LH) 2. Rear bumper reinforcement support (LH)3. Rear bumper reinforcement
4. Rear bumper energy absorber 5. Rear bumper fascia 6. Rear bumper reinforcement support (RH)
7. Rear bumper side bracket (RH) A. Clip
ALKIA2611ZZ
Revision: November 20132014 Altima NAM
Page 2435 of 4801
REAR BUMPEREXT-21
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
EXT
N
O P
Removal and InstallationINFOID:0000000009460997
REMOVAL
1. Remove the rear combination lamps (LH/RH). Refer to EXL-137, "Removal and Installation".
2. Remove the rear bumper fascia clips (A) and screws (B) (LH/ RH).
3. Remove the rear bumper fascia upper side screws (A) (LH/RH).
4. Remove rear bumper fascia lower side clips (A) (LH/RH).
5. Remove the rear bumper fascia lower rear clips (A).
ALKIA2612ZZ
ALKIA2613ZZ
ALKIA2614ZZ
ALKIA2615ZZ
Revision: November 20132014 Altima NAM
Page 2436 of 4801

EXT-22
< REMOVAL AND INSTALLATION >
REAR BUMPER
6. Pull rear bumper fascia outward in the order as shown by thearrows to release from rear bumper side brackets (LH/RH).
: Pawl
7. Remove the rear bumper fascia. CAUTION:
When removing rear bumper fascia, two people are required to avoid damaging.
8. Remove the rear bumper side brackets (LH/RH) from the rear bumper fascia.
9. Remove rear bumper energy absorber.
10. Remove the nuts and the rear bumper reinforcement.
11. Remove the nuts and the rear bumper supports (LH/RH).
INSTALLATION
Installation is in the reverse order of removal.
mm (in)
ALKIA2616ZZ
ALKIA2658ZZ
Section Measurement Minimum Target Value Maximum
A-A Clearance 0.0 (0.00) 0.0 (0.00) 0.8 (0.03)
A-A Surface height -1.8 (-0.07) -0.8 (-0.03) 0.2 (0.01)
B-B Clearance 0.0 (0.00) 0.0 (0.00) 0.8 (0.03)
B-B Surface height -1.8 (-0.07) -0.8 (-0.03) 0.2 (0.01)
C-C Clearance 0.0 (0.00) 0.0 (0.00) 0.8 (0.03)
C-C Surface height -1.8 (-0.07) -0.8 (-0.03) 0.2 (0.01)
D-D Clearance 0.5 (0.02) 2.0 (0.08) 3.5 (0.14)
D-D Surface height -1.5 (-0.06) 0.0 (0.00) 1.5 (0.06) E-E Clearance 2.0 (0.08) 4.0 (0.16) 6.0 (0.24)
F-F Clearance 4.0 (0.16) 6.0 (0.24) 8.0 (0.31)
Revision: November 20132014 Altima NAM
Page 2437 of 4801
FRONT GRILLEEXT-23
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
EXT
N
O P
FRONT GRILLE
Exploded ViewINFOID:0000000009460998
Removal and InstallationINFOID:0000000009460999
REMOVAL
1. Remove the front bumper fascia. Refer to EXT-17, "Removal and Installation".
2. Remove the front grille screws from the front grille.
3. Release the front grille pawls from the front bumper fascia and remove.
4. Remove the front grille emblem (if necessary).
INSTALLATION
Installation is in the reverse order of removal.
1. Front grille 2. Emblem A. Screw
Pawl
ALKIA2594ZZ
Revision: November 20132014 Altima NAM
Page 2438 of 4801
EXT-24
< REMOVAL AND INSTALLATION >
COWL TOP
COWL TOP
Exploded ViewINFOID:0000000009461000
Removal and InstallationINFOID:0000000009461001
REMOVAL
1. Remove front wiper arms (LH/RH). Refer to WW-58, "Removal and Installation".
2. Release the cowl top seal clips, then remove the cowl top seal.
3. Release the pawls, then remove cowl top side trim covers (1) (LH/RH).
: Pawl
4. Remove cowl top cover clips.
1. Cowl top side trim cover (RH) 2. Cowl top seal 3. Cowl top side trim cover (LH)
4. Cowl top cover A Clip Pawl
ALKIA2672ZZ
ALKIA2673ZZ
Revision: November 20132014 Altima NAM
Page 2439 of 4801
COWL TOPEXT-25
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
EXT
N
O P
5. Pull forward to release cowl top cover (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2674ZZ
Revision: November 20132014 Altima NAM
Page 2440 of 4801
EXT-26
< REMOVAL AND INSTALLATION >
FENDER PROTECTOR
FENDER PROTECTOR
FENDER PROTECTOR
FENDER PROTECTOR : Exploded ViewINFOID:0000000009461002
FENDER PROTECTOR : Removal and InstallationINFOID:0000000009461003
REMOVAL
Release the front fender protector clips, then remove the front fender protector screws and the front fender
protector.
INSTALLATION
Installation is in the reverse order of removal.
REAR WHEEL HOUSE PROTECTOR
1. Front fender protector 2. J-nut 3. Front fender protector side cover
A. Clip
ALKIA2666ZZ
