Page 1945 of 4801

NISSAN TEANA 2014 Service Manual
P2135 TP SENSOREC-945
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P2135 TP SENSOR
DTC LogicINFOID:0000000009462821
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DT

P2135 TP SENSOREC-945
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P2135 TP SENSOR
DTC LogicINFOID:0000000009462821
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DTC P0643, first pe rform the trouble diagnosis for DTC P0643. Refer to
EC-885, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-945, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462822
1.CHECK THROTTLE POSITI ON SENSOR POWER SUPPLY
1. Disconnect electric throttle c ontrol actuator harness connector.
2. Turn ignition switch ON.
3. Check the voltage between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK THROTTLE POSITI ON SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2135 Throttle position sensor
circuit range/perfor-
mance Rationally incorrect voltage is sent to ECM
compared with the signals from TP sensor 1
and TP sensor 2. • Harness or connector
(TP sensor 1 or 2 circuit is open or short-
ed.)
• Electric throttle control actuator
(TP sensor 1 or 2)
Electric throttle control actuator Ground Voltage (V)
Connector Terminal
F57 1 Ground Approx. 5
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1946 of 4801

NISSAN TEANA 2014 Service Manual
EC-946
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P2135 TP SENSOR
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, sh

Page 1947 of 4801

NISSAN TEANA 2014 Service Manual
P2138 APP SENSOREC-947
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P2138 APP SENSOR
DTC LogicINFOID:0000000009462824
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with

P2138 APP SENSOREC-947
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P2138 APP SENSOR
DTC LogicINFOID:0000000009462824
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P0643, first pe rform the trouble diagnosis for DTC P0643. Refer to
EC-885, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-947, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462825
1.CHECK APP SENSOR 1 POWER SUPPLY
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2138 Accelerator
pedal posi-
tion sensor circuit range/
performance Rationally incorrect voltage is sent to ECM
compared with the signals from APP sensor 1
and APP sensor 2. • Harness or connector
(APP sensor 1 or 2 circuit is open or
shorted.)
[CKP sensor (POS) circuit is shorted.]
(Refrigerant pressure sensor circuit is
shorted.)
(EVAP control system pressure sensor
circuit is shorted.)
• Accelerator pedal position sensor (APP sensor 1 or 2)
• Crankshaft position sensor (POS)
• EVAP control system pressure sensor
• Refrigerant pressure sensor
• Sensor power supply 2 circuit
APP sensor Ground Voltage (V)
Connector Terminal
E40 4 Ground Approx. 5
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1948 of 4801

NISSAN TEANA 2014 Service Manual
EC-948
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P2138 APP SENSOR
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between

Page 1949 of 4801

NISSAN TEANA 2014 Service Manual
P2138 APP SENSOREC-949
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 7.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
7.CH

Page 1950 of 4801

NISSAN TEANA 2014 Service Manual
EC-950
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
BRAKE PEDAL POSITION SWITCH
BRAKE PEDAL POSITION SWITCH
Component Function CheckINFOID:0000000009462827
1.CHECK BRAKE PEDAL POSI
TION SWITCH FUNCTION
With CO

Page 1951 of 4801

NISSAN TEANA 2014 Service Manual
BRAKE PEDAL POSITION SWITCHEC-951
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
3.CHECK BRAKE PEDAL POSITION
SWITCH INPUT SIGNAL C

BRAKE PEDAL POSITION SWITCHEC-951
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
3.CHECK BRAKE PEDAL POSITION
SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between brake pedal posit ion switch harness connector and ECM harness connec-
tor.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK BRAKE PEDAL POSITION SWITCH
Check brake pedal position switch. Refer to EC-951, "Component Inspection (Brake Pedal Position Switch)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace brake pedal position switch. Refer to BR-18, "Exploded View"
.
Component Inspection (Brake Pedal Position Switch)INFOID:0000000009462829
1.CHECK BRAKE PEDAL POSITION SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect brake pedal position switch harness connector.
3. Check the continuity between brake pedal position switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK BRAKE PEDAL POSITION SWITCH-II
1. Adjust brake pedal position switch installation. Refer to BR-13, "Inspection and Adjustment"
.
2. Check the continuity between brake pedal position switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace brake pedal position switch. Refer to BR-18, "Removal and Installation"
.
Brake pedal position switch ECM
Continuity
Connector Terminal Connector Terminal
E51 2 E32 126 Existed
Terminals Condition Continuity
1 and 2 Brake pedal Fully released Existed
Slightly depressed Not existed
Terminals Condition Continuity
1 and 2 Brake pedal Fully released Existed
Slightly depressed Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1952 of 4801

NISSAN TEANA 2014 Service Manual
EC-952
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
ASCD INDICATOR
ASCD INDICATOR
Component Function CheckINFOID:0000000009462830
1.CHECK ASCD INDICATOR FUNCTION
Check ASCD indicator under the following conditi
