B5 F6 — : Generator C2 F45 GR/2 : Knock sensor
B4 F7 B/3 : Generator F4 F46 GR/22 : CVT unit
F2 F8 B/3 : Primary speed sensor F5 F47 B/6 : Joint connector-F01
B3 F9 — : Engine ground E5 F48 B/10 : Joint connector-F02
F 3 F 1 0 B / 1 : IPDM E/R (Intelligent power distribution
module engine room) E5 F49 B/10 : Joint connector-F03
F 5 F 1 3 B R / 4 8 : E C M ( Q R 2 5 D E e x c e p t f o r C a l i f o r n i a ) A 2 F 5 1 G / 2 : Intake valve timing intermediate lock
control solenoid valve
E5 F14 B/48 : ECM (QR25DE except for California) B2 F52 B/3 : Intake manifold runner control valve
position sensor
B3 F15 — : Engine ground G4 F53 W/4 : Joint connector-F07
E5 F16 B/48 : TCM (Transmission control module) E3 F54 GR/2 : Engine coolant temperature sensor (With
QR25DE)
B2 F17 GR/2 : Fuel injector no. 1 D3 F55 B/3 : Camshaft position sensor (PHASE)
B2 F18 GR/2 : Fuel injector no. 2 D2 F57 B/6 : Electric throttle control actuator
C 2 F 1 9 G R / 2 : F u e l i n j e c t o r n o . 3 D 3 F 5 8 B / 3 : Exhaust valve timing control position
sensor
D 2 F 2 0 G R / 2 : F u e l i n j e c t o r n o . 4 A 2 F 5 9 G / 2 : Intake valve timing control solenoid
valve
E1 F23 B/3 : Output speed sensor B2 F68 GR/2 : Engine oil temperature sensor
D4 F24 GR/4 : Air fuel ratio (A/F) sensor 1 G4 F70 W/4 : Joint connector-F08
G 4 F 2 5 B R / 8 : To E 2 3 A 3 F 8 0 G / 2 : Exhaust valve timing control solenoid
valve
E 3 F 2 6 W / 2 : C o n d e n s e r G 3 F 8 3 W / 1 0 : IPDM E/R (Intelligent power distribution
module engine room)
E 4 F 2 7 — : S t a r t e r m o t o r G 3 F 8 4 W / 1 2 : IPDM E/R (Intelligent power distribution
module engine room)
E4 F28 — : Starter motor (With QR25DE) E3 F85 B/10 : Transmission range switch
C 1 F 2 9 L / 2 : EVAP canister purge volume control
solenoid valve (With QR25DE) E3 F86 B/3 : Input speed sensor
D2 F30 B/3 : Crankshaft position sensor (POS) A2 F87 B/3 : Engine oil pressure sensor
E2 F31 GR/6 : Mass air flow sensor (With QR25DE) A4 F88 GR/2 : A/C compressor
B 3 F 3 4 G R / 3 : Ignition coil no. 1 (With power
transistor) A1 F89 B/3 : Manifold absolute pressure (Map) sensor
C 3 F 3 5 G R / 3 : Ignition coil no. 2 (With power
transistor) F5 F90 BR/48 : ECM (QR25DE for California)
C 3 F 3 6 G R / 3 : Ignition coil no. 3 (With power
transistor) F5 F91 B/48 : ECM (QR25DE for California)
Revision: November 20132014 Altima NAM
Page 3482 of 4801
PG-50
< DTC/CIRCUIT DIAGNOSIS >
HARNESS
ENGINE CONTROL HARNESS (VQ35DE)
ABMIA5144ZZ
G4 F1 W/10 : To E3 E5 F48 B/10 : Joint connector-F02
F4 F2 W/16 : To E11 G5 F49 B/10 : Joint connector-F03
A4 F3 B/2 : A/C compressor F5 F50 B/10 : Joint connector-F04
F3 F4 — : Fusible link box (Battery) G3 F53 W/4 : Joint connector-F07
G5 F5 GR/4 : Battery current sensor D4 F56 B/4 : Heated oxygen sensor 2 (Bank 2)
Revision: November 20132014 Altima NAM
Page 3483 of 4801

PG
HARNESSPG-51
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
B5 F6 — : Generator E2 F57 B/6 : Electric throttle control actuator
B 4 F 7 B / 3 : G e n e r a t o r D 4 F 6 0 B / 3 : Camshaft position sensor (PHASE)
(Bank 2)
F2 F8 B/3 : Primary speed sensor C4 F61 GR/4 : Air fuel ratio (A/F) sensor (Bank 2)
B4 F9 — : Engine ground B1 F62 B/4 : Heated oxygen sensor 2 (Bank 1)
F 3 F 1 0 B / 1 : IPDM E/R (Intelligent power distribution
module engine room) B3 F63 B/2 : VIAS
control solenoid valve 1
E3 F11 GR/2 : Engine coolant temperature sensor B3 F64 BR/2 : Electronic controlled engine mount
control solenoid valve
C1 F12 GR/4 : Air fuel ratio (A/F) sensor (Ban k 1) C3 F65 B/2 : VIAS control solenoid valve 2
B 3 F 1 5 — : E n g i n e g r o u n d A 3 F 6 6 G / 2 : Intake valve timing control solenoid
valve (Bank 2)
E5 F16 B/48 : TCM (Transmission control module) B2 F67 G/2 : Intake valve timing control solenoid
valve (Bank 1)
B3 F17 GR/2 : Fuel injector no. 1 A2 F68 GR/2 : Engine oil temperature sensor
B3 F18 GR/2 : Fuel injector no. 2 F4 F70 W/4 : Joint connector-F08
C2 F19 GR/2 : Fuel injector no. 3 B2 F71 G/6 : Joint connector-F09
C3 F20 GR/2 : Fuel injector no. 4 E3 F76 L/4 : To F201
D 3 F 2 1 G R / 2 : F u e l i n j e c t o r n o . 5 D 2 F 7 7 B / 3 : Camshaft position sensor (PHASE)
(Bank 1)
C3 F22 GR/2 : Fuel injector no. 6 F5 F78 B/48 : ECM (With VQ35DE)
E1 F23 B/3 : Output speed sensor E5 F79 BR/48 : ECM (With VQ35DE)
D3 F26 W/2 : Condenser F4 F81 GR/1 : Starter motor (With VQ35DE)
F 4 F 2 7 — : S t a r t e r m o t o r G 3 F 8 3 W / 1 0 : IPDM E/R (Intelligent power distribution
module engine room)
D5 F30 B/3 : Crankshaft position sensor (POS) G3 F84 W/12 : IPDM E/R (Intelligent power distribution
module engine room)
D 3 F 3 2 G R / 2 : EVAP canister purge volume control
solenoid valve (With VQ35DE) E3 F85 B/10 : Transmission range switch
C 2 F 3 4 G R / 3 : Ignition coil no. 1 (With power
transistor) E3 F86 B/3 : Input speed sensor
C 4 F 3 5 G R / 3 : Ignition coil no. 2 (With power
transistor) A2 F87 B/3 : Engine oil pressure sensor
C 2 F 3 6 G R / 3 : Ignition coil no. 3 (With power
transistor) A 4 F 8 8 G R / 2 : A / C c o m p r e s s o r
C 4 F 3 7 G R / 3 : Ignition coil no. 4 (With power
transistor) E1 F93 GR/6 : Mass air flow sensor (With VQ35DE)
D 2 F 3 8 G R / 3 : Ignition coil no. 5 (With power
transistor) Knock sensor sub-harness
D 4 F 3 9 G R / 3 : Ignition coil no. 6 (With power
transistor) D 3 F 2 0 1 L / 4 : T o F 7 6
F3 F46 GR/22 : CVT unit C3 F202 GR/2 : Knock sensor (Bank 1)
F5 F47 B/6 : Joint connector-F01 C3 F203 GR/2 : Knock sensor (Bank 2)
Revision: November 20132014 Altima NAM
Page 3484 of 4801
PG-52
< DTC/CIRCUIT DIAGNOSIS >
HARNESS
BODY HARNESS
AAMIA0028ZZ
G1 B1 SMJ : To M6 C3 B40 BR/2: High-mounted stop lamp (With rear
spoiler)
C3 B3 W/3 : Joint connector-B05 E4 B41 GR/3 : EVAP control system pressure sensor
F1 B4 W/8 : Fuse block (J/B) E3 B42 GR/6 : Fuel level sensor unit and fuel pump
E2 B6 W/8 : To D201 D4 B43 B/4 : To C1
E2 B7 — : Body ground E4 B45 W/6 : Rear combination lamp RH
Revision: November 20132014 Altima NAM
Page 3485 of 4801

PG
HARNESSPG-53
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
E2 B8 W/4 : Front door switch LH C5 B46 GR/2 : Rear bumper antenna
G3 B9 Y/22 : Air bag diagnosis sensor unit E4 B47 W/2 : Rear speaker RH (Without BOSE audio
system)
G1 B10 W/12 : To E29 C2 B52 W/1 : Condenser
F2 B11 Y/2 : Front LH side air bag module B2 B53 B/1 : Rear window defogger
F2 B12 W/6 : To B201 D3 B54 B/1 : Rear window defogger
G1 B13 W/6 : Fuse block (J/B) D3 B58 — : Body ground
E2 B14 Y/2 : Front LH seat belt pre-tensioner D3 B61 Y/2 : Rear side air bag satellite sensor LH
E2 B15 Y/2 : Front side air bag satellite sensor LH G3 B65 W/4 : Joint connector-B04
B3 B16 W/12 : Rear view camera washer control unit E3 B66 O/2 : Front LH seat belt pre-tensioner
B4 B17 W/2 : Rear view camera air pump motor Chassis harness
D2 B18 W/4 : Rear door switch LH D4 C1 B/4 : To B43
C2 B19 — : Body ground C4 C2 B/2 : Rear wheel sensor LH
F2 B21 W/4 : Joint connector-B06 D5 C3 B/2 : Rear wheel sensor RH
B2 B22 L/12 : Joint connector-B07 Front seat LH harness
C 3 B 2 5 W / 2 : Rear speaker LH (Without BOSE audio
system) F 3 B 2 0 1 W / 6 : T o B 1 2
C 4 B 2 8 W / 3 : Trunk lamp switch and trunk release
solenoid F3 B202 W/2 : Seat belt buckle switch LH
D3 B29 GR/2 : Rear parcel shelf antenna E2 B203 W/10 : Power seat switch
A3 B30 W/6 : Rear combination lamp LH E2 B205 BR/4 : Lumbar support switch
C4 B32 BR/2 : License plate lamp RH F3 B206 GR/5 : Sliding motor
C4 B33 GR/2 : Trunk opener request switch E3 B207 W/6 : Reclining motor
B3 B34 BR/2 : License plate lamp LH F2 B208 W/6 : Front lifting motor
B4 B35 W/8 : Rear view camera F3 B209 W/6 : Rear lifting motor
C3 B36 W/2 : Trunk room lamp E3 B210 W/3 : Seat cushion heater LH
C 3 B 3 7 B / 2 : High-mounted stop lamp (Without rear
spoiler) D2 B211 W/2 : Seat back heater LH
E1 B38 Y/2 : LH side curtain air bag module G3 B212 B/2 : Lumbar support motor
D4 B39 B/2 : EVAP canister vent control valve
Revision: November 20132014 Altima NAM
Page 3486 of 4801
PG-54
< DTC/CIRCUIT DIAGNOSIS >
HARNESS
BODY NO. 2 HARNESS
ABMIA5146ZZ
C 1 B 1 0 2 W / 1 2 : T o M 8 E 3 B 1 2 4 W / 2: Rear speaker RH (With BOSE audio
system)
D 1 B 1 0 3 W / 1 6 : T o M 9 C 2 B 1 2 8 W / 6 : T o B 3 0 5
D1 B104 BR/16 : To M10 C2 B133 W/4 : Joint connector-B01
D2 B105 W/4 : To B301 E3 B134 O/2 : Front RH seat belt pre-tensioner
E2 B106 W/8 : To D301 E3 B135 Y/2 : Rear side air bag satellite sensor RH
Revision: November 20132014 Altima NAM
Page 3487 of 4801

PG
HARNESSPG-55
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
E2 B107 — : Body ground Front seat RH harness
E2 B108 W/4 : Front door switch RH D2 B301 W/4 : To B106
E3 B109 BR/23 : BOSE speaker amp. C3 B3 02 W/4 : Seat belt buckle switch RH
E4 B110 BR/14 : BOSE speaker amp. D3 B304 W/3 : Seat cushion heater RH
C2 B111 W/4 : Joint connector-B02 D3 B305 W/6 : To B128
D2 B112 Y/2 : Front RH side air bag module D2 B308 W/4 : To B326
C3 B113 Y/22 : Air bag diagnosis sensor unit D2 B310 W/2 : Seat back heater RH
E2 B115 Y/2 : Front RH seat belt pre-tensioner ODS sub-harness
F3 B116 W/4 : Rear door switch RH C2 B326 W/4 : To B308
F2 B117 — : Body ground D3 B327 B/20 : Occupant classification system control
unit
E2 B118 Y/2 : Front side air bag satellite sensor RH C3 B328 P/3 : Occupant classification system sensor FL
E1 B119 Y/2 : RH side curtain air bag module C3 B329 P/3 : Occupant classification system sensor RL
D 4 B 1 2 0 W / 2 : Rear speaker LH (With BOSE audio
system)
Revision: November 20132014 Altima NAM
Page 3488 of 4801
PG-56
< DTC/CIRCUIT DIAGNOSIS >
HARNESS
ROOM LAMP HARNESS
AAMIA0030ZZ
C 5 R 1 W / 1 2 : To M 7 C 2 R 7 W / 4 : M i c r o p h o n e
B 5 R 2 W / 4 : To M 1 3 B 4 R 8 B / 7 : Auto anti-dazzling inside mirror
(Without homelink universal transceiver)
C 3 R 3 W / 2 : Va n i t y m i r r o r l a m p L H B2 R9 W/2 : Vanity mirror lamp RH
B 4 R 4 B / 1 0 : Auto anti-dazzling
inside mirror (With
homelink universal transceiver) E 3 R 5 0 W / 8 : P e r s o n a l l a m p r e a r
Revision: November 20132014 Altima NAM
