EC-962
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
FUEL INJECTOR
FUEL INJECTOR
Component Function CheckINFOID:0000000009462842
1.INSPECTION START
Turn ignition switch to START.
Are any cylinders ignited?
YES >> GO TO 2.
NO >> Proceed to EC-962, "Diagnosis Procedure"
.
2.CHECK FUEL INJECTOR FUNCTION
With CONSULT
1. Start engine.
2. Perform “POWER BALANCE” in “ACTIVE TEST” mode with CONSULT.
3. Check that each circuit produces a momentary engine speed drop.
Without CONSULT
1. Start engine.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-962, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462843
1.CHECK FUEL INJECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Turn ignition switch ON.
4. Check the voltage between fuel injector harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK FUEL INJECTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between fuel injector harness connector and IPDM E/R harness connector.
Clicking sound should be heard.
PBIB3332E
Fuel injector
Ground Voltage
Cylinder Connector Terminal
1F171
Ground Battery voltage
2F181
3F191
4F201
5F211
6F221
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
