TM-162
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P2815 SELECT SOLENOID
P2815 SELECT SOLENOID
DTC LogicINFOID:0000000009464103
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Maintain the following conditions. (Keep 5 seconds or more after the selector lever shifted.)
3. Check the first trip DTC.
Is
“P2815” detected?
YES >> Go to TM-162, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464104
1.CHECK CIRCUIT BETWEEN TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P2815 SELECT SOLENOID
(Select solenoid) When all of the following conditions are satis-
fied and this state is maintained for 0.2 sec-
onds:
• TCM power supply voltage: More than 11 V
• TCM judges that solenoid valve circuit is open.
• P2814 is not detected. • Harness or connector
(Select solenoid valve circuit open or
shorted to power supply)
• Select solenoid valve
Selector lever N → D, N → R, P → R
TCM CVT unit Continuity
Connector Terminal Connector Terminal
F1637F46 3Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4378 of 4801
![NISSAN TEANA 2014 Service Manual
P2815 SELECT SOLENOIDTM-163
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermitt NISSAN TEANA 2014 Service Manual
P2815 SELECT SOLENOIDTM-163
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermitt](/manual-img/5/57390/w960_57390-4377.png)
P2815 SELECT SOLENOIDTM-163
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 3.
3.CHECK CIRCUIT BETW EEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-187, "Removal and Installation"
.
2. Check continuity between CVT unit harness connecto r terminal and control valve harness connector ter-
minal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace terminal cord assembly. Refer to TM-187, "Removal and Installation"
.
4.CHECK CIRCUIT BETWEEN CONTROL VALVE AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> There is malfunction of select solenoid solenoi d valve. Replace transaxle assembly. Refer to TM-
206, "Removal and Installation".
CVT unit
— Condition Resistance
Connector Terminal
F209 3 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
CVT unit Control valve
Continuity
Connector Terminal Connector Terminal
F2093F2074Existed
Control valve — Condition Resistance
Te r m i n a l
4Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4379 of 4801
![NISSAN TEANA 2014 Service Manual
TM-164
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
MAIN POWER SUPPLY AND GROUND CIRCUIT
MAIN POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009464105
1.CHECK TCM POWER CIRCUIT (PART 1)
NISSAN TEANA 2014 Service Manual
TM-164
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
MAIN POWER SUPPLY AND GROUND CIRCUIT
MAIN POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009464105
1.CHECK TCM POWER CIRCUIT (PART 1)](/manual-img/5/57390/w960_57390-4378.png)
TM-164
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
MAIN POWER SUPPLY AND GROUND CIRCUIT
MAIN POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009464105
1.CHECK TCM POWER CIRCUIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check voltage between TCM harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK TCM POWER CIRCUIT (PART 2)
Check voltage between TCM harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 5.
3.CHECK TCM GROUND CIRCUIT
Check continuity between TCM harness connector terminals and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
4.DETECT MALFUNCTION ITEMS (PART 1)
Check the following items:
• Open or short circuit in harness between battery positive terminal and TCM connector terminal 45, and 46.
• 10A fuse (No.60, located in the fuse and fusible link block). Refer to PG-71, "Terminal Arrangement"
.
Is the inspection result normal?
YES >> Check intermitt ent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
5.CHECK CIRCUIT BETWEEN IPDM E/R AND TCM (PART 1)
+
−Vo l ta g e
TCM
Connector Terminal
F16 45
Ground 10 – 16 V
46
+
−Condition Voltage
TCM
Connector Terminal
F16 47
GroundIgnition switch ON 10 – 16 V
Ignition switch OFF Approx. 0 V
48 Ignition switch ON 10 – 16 V
Ignition switch OFF Approx. 0 V
TCM —Continuity
Connector Terminal
F16 41
Ground Existed
42
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4380 of 4801
![NISSAN TEANA 2014 Service Manual
MAIN POWER SUPPLY AND GROUND CIRCUITTM-165
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continui NISSAN TEANA 2014 Service Manual
MAIN POWER SUPPLY AND GROUND CIRCUITTM-165
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continui](/manual-img/5/57390/w960_57390-4379.png)
MAIN POWER SUPPLY AND GROUND CIRCUITTM-165
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness c onnector terminal and TCM harness connector terminals.
Is the check result normal?
YES >> GO TO 6.
NO >> Repair or replace malfunctioning parts.
6.CHECK CIRCUIT BETWEEN IPDM E/R AND TCM (PART 2)
Check continuity between IPDM E/ R harness connector terminal and ground.
Is the check result normal?
YES >> GO TO 7.
NO >> Repair or replace malfunctioning parts.
7.DETECT MALFUNCTIONING ITEMS (PART 2)
Check the following items:
• Open or short circuit in harness between i gnition switch and IPDM E/R. Refer to PCS-21, "Wiring Diagram"
.
• 10A fuse (No.46, located in the IPDM E/R). Refer to PG-72, "Fuse, Connector and Terminal Arrangement"
.
• IPDM E/R
Is the check result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
IPDM E/R harness connector TCM harness connector Continuity
Connector Terminal Connector Terminal
F8361F16 47
Existed
48
IPDM E/R harness connector —Continuity
Connector Terminal
F83 61 Ground Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4381 of 4801
![NISSAN TEANA 2014 Service Manual
TM-166
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OVERDRIVE CONTROL SWITCH
OVERDRIVE CONTROL SWITCH
Component Function CheckINFOID:0000000009464106
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF NISSAN TEANA 2014 Service Manual
TM-166
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OVERDRIVE CONTROL SWITCH
OVERDRIVE CONTROL SWITCH
Component Function CheckINFOID:0000000009464106
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF](/manual-img/5/57390/w960_57390-4380.png)
TM-166
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OVERDRIVE CONTROL SWITCH
OVERDRIVE CONTROL SWITCH
Component Function CheckINFOID:0000000009464106
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF indicator lamp turns ON for approx. 2 seconds when ignition switch turns ON.
Is the inspection results normal?
YES >> GO TO 2.
NO >> Go to TM-168, "Diagnosis Procedure"
.
2.CHECK OVERDRIVE CONT ROL SWITCH FUNCTION
1. Shift the selector lever to “D” position.
2. Check that O/D OFF indicator lamp turns ON /OFF when overdrive control switch is operated.
Is the inspection results normal?
YES >> INSPECTION END
NO >> Go to TM-166, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009464107
1.CHECK O/D OFF SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector connector.
3. Turn ignition switch ON.
4. Check voltage between CVT shift se lector harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK O/D OFF SWITCH
Check overdrive control switch. Refer to TM-167, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK GROUND CIRCUIT
Check continuity between CVT shift sele ctor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CHECK CIRCUIT BETWEEN CVT SHIFT SELECTOR AND COMBINATION METER (PART 1)
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between CVT shift selector harness connector terminal and combination meter harness connector terminal.
CVT shift selector
Vo l ta g e
Connector +
−
Te r m i n a l
M23 1 2 Approx. 5.0 V
CVT shift selector —Continuity
Connector Terminal
M23 2 Ground Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4382 of 4801
![NISSAN TEANA 2014 Service Manual
OVERDRIVE CONTROL SWITCHTM-167
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts NISSAN TEANA 2014 Service Manual
OVERDRIVE CONTROL SWITCHTM-167
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts](/manual-img/5/57390/w960_57390-4381.png)
OVERDRIVE CONTROL SWITCHTM-167
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK CIRCUIT BETWEE N CVT SHIFT SELECTOR AND COMBINATION METER (PART 2)
Check continuity between CVT shift selector harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace malfunctioning parts.
6.CHECK COMBINATION METER INPUT SIGNAL
1. Connect all of disconnected connectors.
2. Turn ignition switch ON.
3. Select “Data Monitor” in “METER/M&A”.
4. Select “O/D OFF SW”.
5. Check that “O/D OFF SW” turns ON/OFF when ov erdrive control switch is operated. Refer to MWI-22,
"Reference Value".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace combination meter. Refer to MWI-82, "Removal and Installation"
.
Component InspectionINFOID:0000000009464108
1.CHECK OVERDRIVE CONTROL SWITCH
Check continuity between wires of selector lever knob.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace selector lever knob. Refer to TM-179, "Removal and Installation"
.
CVT shift selector Combination meter
Continuity
Connector Terminal Connector Terminal
M23 1 M26 52 Existed
CVT shift selector —Continuity
Connector Terminal
M23 1 Ground Not existed
Condition Continuity
Overdrive control switch is depressed Existed
Overdrive control switch is depressed Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4383 of 4801
![NISSAN TEANA 2014 Service Manual
TM-168
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OD OFF INDICATOR LAMP
OD OFF INDICATOR LAMP
Component Function CheckINFOID:0000000009464109
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF indica NISSAN TEANA 2014 Service Manual
TM-168
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OD OFF INDICATOR LAMP
OD OFF INDICATOR LAMP
Component Function CheckINFOID:0000000009464109
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF indica](/manual-img/5/57390/w960_57390-4382.png)
TM-168
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
OD OFF INDICATOR LAMP
OD OFF INDICATOR LAMP
Component Function CheckINFOID:0000000009464109
1.CHECK O/D OFF INDICATOR LAMP FUNCTION
Check O/D OFF indicator lamp turns ON for approx. 2 seconds when ignition switch turns ON.
Is the inspection results normal?
YES >> INSPECTION END
NO >> Go to TM-168, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009464110
1.CHECK DTC (TCM)
With CONSULT
1. Turn ignition switch ON.
2. Check “Self Diagnostic Results” in “TRANSMISSION”.
Is any DTC detected?
YES >> Check DTC detected item. Refer to TM-60, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC (COMBINATION METER)
With CONSULT
Check “Self Diagnostic Results” in “METER/M&A”.
Is any DTC detected?
YES >> Check DTC detected item. Refer to MWI-27, "DTC Index".
NO >> GO TO 3.
3.CHECK COMBINATION METER INPUT SIGNAL
With CONSULT
1. Shift the selector lever to “D” position.
2. Select “Data Monito r” in “METER/M&A”.
3. Select “O/D OFF IND”.
4. Check that “O/D OFF IND” turns ON/OFF when ov erdrive control switch is operated. Refer to MWI-22,
"Reference Value".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-82, "Removal and Installation".
NO >> GO TO 4.
4.CHECK TCM INPUT/OUTPUT SIGNAL
With CONSULT
1. Select “Data Monitor” in “TRANSMISSION”.
2. Select “SPORT MODE SW”.
3. Check that “SPORT MODE SW” turns ON/OFF when overdrive control switch is operated. Refer to TM-
49, "Reference Value".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-82, "Removal and Installation".
NO >> Check overdrive control switch. Refer to TM-166, "Diagnosis Procedure"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4384 of 4801
![NISSAN TEANA 2014 Service Manual
SHIFT POSITION INDICATOR CIRCUITTM-169
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT POSITION INDICATOR CIRCUIT
Component Parts Function InspectionINFOID:00000000094 NISSAN TEANA 2014 Service Manual
SHIFT POSITION INDICATOR CIRCUITTM-169
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT POSITION INDICATOR CIRCUIT
Component Parts Function InspectionINFOID:00000000094](/manual-img/5/57390/w960_57390-4383.png)
SHIFT POSITION INDICATOR CIRCUITTM-169
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT POSITION INDICATOR CIRCUIT
Component Parts Function InspectionINFOID:0000000009464111
1.CHECK SHIFT POSITION INDICATOR
1. Start the engine.
2. Shift selector lever.
3. Check that the selector lever position and the shift position indicator on the combination meter are identi-
cal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to TM-169, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009464112
1.CHECK TCM INPUT/OUTPUT SIGNAL
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “RANGE”.
4. Shift selector lever.
5. Check that selector lever position, “RANGE” on CONSULT screen, and shift position indicator display on
combination meter are identical.
Is the check result normal?
YES >> INSPECTION END
NO-1 (“RANGE” is changed but is not displayed on shif t position indicator.>>Check “Self Diagnostic Result”
in “TRANSMISSION”.
NO-2 (“RANGE” and shift position indicator are diff erent.)>>Check “Self Diagnostic Result” in “TRANSMIS-
SION”.
NO-3 (Specific“RANGE” is not displayed on shift pos ition indicator.)>>Check “Self Diagnostic Result” in
“METER/M&A”.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
