Page 2913 of 4801

NISSAN TEANA 2014 Service Manual INT-22 < REMOVAL AND INSTALLATION > BODY SIDE TRIM When installing the front kicking plate inner, check that the pawls are securely placed in the body panel holes. FRONT KICKING PLATE : Remova l and

Page 2914 of 4801

NISSAN TEANA 2014 Service Manual BODY SIDE TRIMINT-23 < REMOVAL AND INSTALLATION > C D E F G H I K L M A B INT N O P 1. Release the rear kicking plate outer pawls and remove the rear kicking plate outer. : Pawl INSTALLATION Instal

Page 2915 of 4801

NISSAN TEANA 2014 Service Manual INT-24 < REMOVAL AND INSTALLATION > BODY SIDE TRIM 6. Release the center pillar lower finisher clips.: Clip 7. Remove the seat belt from the center pillar lower fi nisher, then remove the center pill

Page 2916 of 4801

NISSAN TEANA 2014 Service Manual BODY SIDE TRIMINT-25 < REMOVAL AND INSTALLATION > C D E F G H I K L M A B INT N O P REAR PILLAR FINISHER REAR PILLAR FINISHER : Removal and InstallationINFOID:0000000009461357 REMOVAL 1. Remove th

Page 2917 of 4801

NISSAN TEANA 2014 Service Manual INT-26 < REMOVAL AND INSTALLATION > REAR PARCEL SHELF FINISHER REAR PARCEL SHELF FINISHER Exploded ViewINFOID:0000000009461358 Removal and InstallationINFOID:0000000009461359 REMOVAL 1. Remove the hi

Page 2918 of 4801

NISSAN TEANA 2014 Service Manual FLOOR TRIMINT-27 < REMOVAL AND INSTALLATION > C D E F G H I K L M A B INT N O P FLOOR TRIM Exploded ViewINFOID:0000000009461360 Removal and InstallationINFOID:0000000009461361 REMOVAL 1. Remove the

Page 2919 of 4801

NISSAN TEANA 2014 Service Manual INT-28 < REMOVAL AND INSTALLATION > FLOOR TRIM 7. Release all floor trim hold downs (A). 8. Remove the floor trim. INSTALLATION Installation is in the reverse order of removal. ALJIA0911ZZ Revision:

Page 2920 of 4801

NISSAN TEANA 2014 Service Manual HEADLININGINT-29 < REMOVAL AND INSTALLATION > C D E F G H I K L M A B INT N O P HEADLINING Exploded ViewINFOID:0000000009461362 With Sunroof ALJIA0907ZZ 1. Headlining 2. Rear assist grip (RH) 3. Fr
