Page 2225 of 4801

NISSAN TEANA 2014 Service Manual
CYLINDER BLOCKEM-227
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
b. Heat the pistons to 60
° - 70 °C (140 ° - 158 °F).
WARNING:
Pistons contain heat. when wo rkin

Page 2226 of 4801

NISSAN TEANA 2014 Service Manual
EM-228
< UNIT DISASSEMBLY AND ASSEMBLY >[VQ35DE]
CYLINDER BLOCK
Do not reuse washer.
• Apply sealant to the thread of water drain plug (A). Use Anaerobic Liquid Gasket or equivalent. Refer to EM-

Page 2227 of 4801

NISSAN TEANA 2014 Service Manual
CYLINDER BLOCKEM-229
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
5. Set the upper main bearings in their proper positions on the cyl-
inder block.
• Confirm the cor

Page 2228 of 4801

NISSAN TEANA 2014 Service Manual
EM-230
< UNIT DISASSEMBLY AND ASSEMBLY >[VQ35DE]
CYLINDER BLOCK
Measure the tightening angle in
stage 2 using Tool. Do not mea-
sure visually.
8. Measure crankshaft end play. • If beyond the lim

Page 2229 of 4801

NISSAN TEANA 2014 Service Manual
CYLINDER BLOCKEM-231
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
f. Slide the new rear main seal (1) over the Tool (A) and onto the
crankshaft.
g. Loosen the wing nut

Page 2230 of 4801

NISSAN TEANA 2014 Service Manual
EM-232
< UNIT DISASSEMBLY AND ASSEMBLY >[VQ35DE]
CYLINDER BLOCK
c. Install the snap ring into the front of the piston pin-groove.
• After installing, check that the connecting rod pivots smoothlyo

Page 2231 of 4801

NISSAN TEANA 2014 Service Manual
CYLINDER BLOCKEM-233
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
13. Install the piston and connecting rod assembly into the corre-
sponding cylinder.
• Position t

CYLINDER BLOCKEM-233
< UNIT DISASSEMBLY AND ASSEMBLY > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
13. Install the piston and connecting rod assembly into the corre-
sponding cylinder.
• Position the crankshaft pin corresponding to the connecting
rod to be installed onto the bottom dead center.
• Apply engine oil sufficiently to the cylinder bore, piston, and crankshaft pin.
• Match the cylinder position wit h the cylinder No. (B) on the
connecting rod to install.
• Install the piston with the piston front mark (A) on the crown
facing the front of the engine ( ), using a suitable tool.
- Oil hole (C)
CAUTION:
Be careful not to damage the crankshaft pin and cyl inder wall, resulting from an interference of the
connecting rod big end.
14. Install the connecting rod cap. • Match the stamped cylinder number marks on the connectingrod with those on the cylinder cap for installation.
• Install the piston connecting rod assembly and cap so that the front mark on the cap and piston are facing the front of the
engine.
• Lubricate the threads and seat surfaces with new engine
oil.
15. Check the connecting rod cap bolts before reusing, then install
in their original position in the connecting rod. The bolts should
screw in smoothly by hand.
• Measure the outer diameter of the connecting rod cap bolts as
shown.
16. Tighten the connecting rod cap bolts in two stages using Tool: CAUTION:
Always use either an angle wr ench or protractor. Avoid
tightening based on visual check alone.
• Apply engine oil to the threads and seats of the connecting rod cap bolts.
• After tightening the connecting rod cap bolts, make sure that the crankshaft rotates smoothly.
• Check the connecting rod side clearance. If beyond t he limit, replace the connecting rod and/or crank-
shaft.
AWBIA0029ZZ
SEM457G
Outer diameter (d) of th e connecting rod cap bolt
Standard : 7.90 - 8.00 mm (0.3110 - 0.3150 in)
Limit : 7.75 mm (0.3051 in)
SEM538G
Stage 1 : 19.6 N·m (2.0 kg-m, 14 ft-lb)
Stage 2 : 90 ° - 95 ° degrees clockwise
Tool number : KV10112100 (BT-8653-A)
Connecting rod side clearance:
Standard : 0.20 - 0.35 mm (0.0079 - 0.0138 in)
Limit : 0.40 mm (0.0157 in)
SEM953E
Revision: November 20132014 Altima NAM

Page 2232 of 4801

NISSAN TEANA 2014 Service Manual
EM-234
< UNIT DISASSEMBLY AND ASSEMBLY >[VQ35DE]
CYLINDER BLOCK
17. Install the baffle plate to the main bearing beam.
18. Install the knock sensor. • Make sure that there is no foreign material o
