SEC-136
< REMOVAL AND INSTALLATION >
PUSH BUTTON IGNITION SWITCH
PUSH BUTTON IGNITION SWITCH
Exploded ViewINFOID:0000000009461210
Removal and InstallationINFOID:0000000009461211
REMOVAL
1. Remove instrument pad LH. Refer to IP-14, "Exploded View".
2. Release the pawl on each side of NATS antenna amp (1) using a suitable tool and remove from the instrument pad LH.
: Pawl
3. Release the pawl on each side using a suitable tool and remove the push-button ignition switch from the NATS antenna amp.
INSTALLATION
Installation is in the reverse order of removal.
1. NATS antenna amp. 2. Push-button ignition switch
ALKIA2470ZZ
ALMIA0583ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3962 of 4801
IMMOBILIZER CONTROL MODULESEC-137
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
IMMOBILIZER CONTROL MODULE
Removal and InstallationINFOID:0000000009461212
The immobilizer control module is integrated into the body control module (BCM). For removal and installation,
refer to BCS-80, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3963 of 4801

SR-1
RESTRAINTS
C
D E
F
G
I
J
K L
M
SECTION SR
A
B
SR
N
O P
CONTENTS
SRS AIRBAG
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Service ......................................................................2
Precaution for Work ..................................................2
PREPARATION ............................................4
PREPARATION .............................................. .....4
Special Service Tools .......................................... ......4
BASIC INSPECTION ....................................5
COLLISION DIAGNOSIS ............................... .....5
For Frontal Collision ..................................................5
For Side and Rollover Collision ........................... ......7
REMOVAL AND INSTALLATION ...............11
DRIVER AIR BAG MODULE .......................... ....11
Exploded View .................................................... ....11
Removal and Installation .........................................11
SPIRAL CABLE ............................................. ....15
Removal and Installation .........................................15
FRONT PASSENGER AIR BAG MODULE ... ....17
Exploded View .................................................... ....17
Removal and Installation ..................................... ....17
SIDE CURTAIN AIR BAG MODULE ................19
Exploded View .........................................................19
Removal and Installation .........................................19
SIDE AIR BAG MODULE ..................................21
Removal and Installation .........................................21
CRASH ZONE SENSOR ...................................22
Removal and Installation ..................................... ....22
SIDE AIR BAG (SATELLITE) SENSOR ...........23
Exploded View .........................................................23
Removal and Installation .........................................23
DIAGNOSIS SENSOR UNIT .............................26
Removal and Installation .........................................26
OCCUPANT CLASSIFICATION SYSTEM .......28
Removal and Installation .........................................28
SEAT BELT PRE-TENSIONER ........................29
Removal and Installation .........................................29
FRONT SEAT BELT BUCKLE SWITCH ..........30
Removal and Installation .........................................30
PASSENGER AIR BAG INDICATOR ...............31
Removal and Installation .........................................31
Revision: November 20132014 Altima NAM
Page 3964 of 4801

SR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951759
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
ServiceINFOID:0000000009463063
• Do not use electrical test equipment to check SRS ci rcuits unless instructed to in this Service Manual.
• Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least three
minutes.
For approximately three minutes after the cables are remo ved, it is still possible for the air bag and seat belt
pre-tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least three minutes
have passed.
• Diagnosis sensor unit must always be installed with their arrow marks “ ⇐” pointing towards the front of the
vehicle for proper operation. Also chec k diagnosis sensor unit for cracks, deformities or rust before installa-
tion and replace as required.
• The spiral cable must be aligned with the neutral position since its rotations are limited. Do not turn steering
wheel and column after removal of steering gear.
• Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad side facing upward and seat mounted front side air bag m odule standing with the stud bolt side facing down.
• Conduct self-diagnosis to check entire SRS for proper function after replacing any components.
• After air bag inflates, the instrument panel assembly should be replaced if damaged.
• Always replace instrument panel pad following front passenger air bag deployment.
Precaution for WorkINFOID:0000000009463065
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
