Page 609 of 4801

NISSAN TEANA 2014 Service Manual
DAS-176
< BASIC INSPECTION >[BSW]
DIAGNOSIS AND REPAIR WORK FLOW
>> GO TO 2.
2.SELF-DIAGNOSIS WITH CONSULT
1. Perform “All DTC Reading” with CONSULT.
2. Check if the DTC is detected on the self-

Page 610 of 4801

NISSAN TEANA 2014 Service Manual
DAS
DIAGNOSIS AND REPAIR WORK FLOWDAS-177
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
Utilize a work sheet sample to organize all of the information for troubleshooting.
KEY POINTS•

Page 611 of 4801

NISSAN TEANA 2014 Service Manual
DAS-178
< BASIC INSPECTION >[BSW]
PRE-INSPECTION FOR DIAGNOSIS
PRE-INSPECTION
FOR DIAGNOSIS
Inspection ProcedureINFOID:0000000009464820
1.CHECK CAMERA LENS
Is camera lens contaminated with foreign m

Page 612 of 4801

NISSAN TEANA 2014 Service Manual
DAS
ACTION TESTDAS-179
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
ACTION TEST
DescriptionINFOID:0000000009464821
• Perform action test to verify the customers concern.
• Perform

DAS
ACTION TESTDAS-179
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
ACTION TEST
DescriptionINFOID:0000000009464821
• Perform action test to verify the customer's concern.
• Perform action test and check the system operation after system diagnosis.
WARNING:
Be careful of traffic conditions and safety aro und the vehicle when performing road test.
CAUTION:
• Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-73, "Precaution for LDW System Service"
.
- System description for LDW: Refer to DAS-77, "System Description"
.
- System description for BSW: Refer to DAS-152, "System Description"
.
- System description for MOD: Refer to DAS-228, "System Description"
.
- Handling precaution: Refer to DAS-82, "Precautions for Lane Departure Warning"
.
Inspection ProcedureINFOID:0000000009464822
WARNING:
Be careful of traffic conditions and safety aro und the vehicle when performing road test.
CAUTION:
• Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-73, "Precaution for LDW System Service"
.
- System description for LDW: Refer to DAS-77, "System Description"
.
- System description for BSW: Refer to DAS-152, "System Description"
.
- System description for MOD: Refer to DAS-228, "System Description"
.
- Handling precaution: Refer to DAS-82, "Precautions for Lane Departure Warning"
.
1.CHECK BSW SYSTEM SETTING
1. Start the engine.
2. Check that the BSW system setting can be enabl ed/disabled on the vehicle information display.
3. Turn OFF the ignition switch and wait for 30 seconds or more.
4. Check that the previous setting is saved when the engine starts again.
>> GO TO 2.
2.ACTION TEST FOR BSW
1. Enable the setting of the BSW system on the vehicle information display.
2. Turn warning systems switch ON (w arning systems ON indicator is ON).
3. Check the BSW operation according to the following table.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 613 of 4801

NISSAN TEANA 2014 Service Manual
DAS-180
< BASIC INSPECTION >[BSW]
ACTION TEST
Vehicle condition/Driver’s operation
NOTE:
After the operating conditions of warning are satisf ied, the warning continues until the vehicle speed
rea

Page 614 of 4801

NISSAN TEANA 2014 Service Manual
DAS
ADDITIONAL SERVICE WHEN REPLACING REAR VIEW CAMERA
DAS-181
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
ADDITIONAL SERVICE WHEN RE PLACING REAR VIEW CAMERA
DescriptionINFOID:0000000

Page 615 of 4801

NISSAN TEANA 2014 Service Manual
DAS-182
< BASIC INSPECTION >[BSW]
REAR VIEW CAMERA CALIBRATION
REAR VIEW CAMERA CALIBRATION
DescriptionINFOID:0000000009464825
Always perform the calibration after removing and installing or replacin

Page 616 of 4801

NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA CALIBRATIONDAS-183
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
>> Refer to DAS-183, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:00000

DAS
REAR VIEW CAMERA CALIBRATIONDAS-183
< BASIC INSPECTION > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
>> Refer to DAS-183, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000009464827
CAUTION:
• Perform this operation in a horizontal position wh ere there is a clear view for 3 m (9.84 ft) backward
and 4 m (13.12 ft) wide.
• Place the target in a well-lig hted location. (Poor lighting may make it hard to adjust.)
• The target may not be detected when it shines by the reflected light of the sun or lighting.
• The target may not be detected when there is the same pattern of black and white as the target when
the pattern is within 0.5 m (1.64 ft) from either si de and upward/downward position from the target. (It
is desirable that the vehicle is pos itioned on a single-color floor.)
1.TARGET SETTING
1. Mark points “A”, “B”, “C” and “D” at the center of the lateral sur- face of each wheel.
NOTE:
Hang a string with a cone from the fender so as to pass through
the center of wheel, and then mark a point at the center of the
lateral surface of the wheel.
2. Draw line “LH” passing through points “A” and “B” on the left side of vehicle.
NOTE:
Approximately 2.2 m (7.22 ft) or more at the rear from the rear
axle.
3. Mark point “E” on the line “LH” at the positions 2125 mm (83.66
in) from point “B”.
4. Draw line “RH” passing through points “C” and “D” on the right side of vehicle in the same way as step 2.
5. Mark point “F” on the line “RH” at the positions 2125 mm (83.66 in) from point “D”.
6. Draw line “RW” passing through the points “E” and “F” on the rear of the vehicle. NOTE:
Approximately 1.8 m (5.91 ft) or more at bot h left and right sides from vehicle center.
7. Mark point “C
t” at the center of point “E” and “F” on the line “RW”.
CAUTION:
Make sure that “E” to “C
t” is equal to “F” to “Ct”.
8. Mark point "Lt" and "Rt" on the line "RW" at t he positions 1500 mm (59.06 in) from point "Ct".
9. Position the center of the ta rget mark to point of “Ct”.
Side distance (S
d): “B”–“E” (“D”–“F”) : 2125 mm (83.66 in)
Left distance (L
d): “Ct”–“Lt” : 1500 mm (59.06 in)
Right distance (R
d): “Ct”–“Rt” : 1500 mm (59.06 in)
ALOIA0187GB
PKIB7667E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
