Page 1785 of 4801

NISSAN TEANA 2014 Service Manual
P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D A/F SENSOR 1
EC-785
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
4. Check the continuity between A/F sensor 1
harness co

Page 1786 of 4801

NISSAN TEANA 2014 Service Manual
EC-786
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P014C, P014D, P014E, P0
14F, P015A, P015B, P015C, P015D A/F SENSOR 1
YES >> GO TO 11.
NO >> Repair or replace PCV valve. Refer to EC-548, "ENGINE CONTROL SY

Page 1787 of 4801

NISSAN TEANA 2014 Service Manual
P0171, P0174 FUEL INJECTION SYSTEM FUNCTION
EC-787
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0171, P0174 FUEL INJE
CTION SYSTEM FUNCTION
DTC LogicINFOID:0000000009462645
DT

P0171, P0174 FUEL INJECTION SYSTEM FUNCTION
EC-787
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0171, P0174 FUEL INJE
CTION SYSTEM FUNCTION
DTC LogicINFOID:0000000009462645
DTC DETECTION LOGIC
With the Air/Fuel Mixture Ratio Self-Learning Control, the actual mixture ratio can be brought closely to the
theoretical mixture ratio based on the mixture ratio f eedback signal from A/F sensor 1. The ECM calculates
the necessary compensation to co rrect the offset between the actual and the theoretical ratios.
In case the amount of the compensation value is extrem ely large (the actual mixture ratio is too lean), the
ECM judges the condition as the fuel injection system malfunction and illuminates the MIL (2 trip detection
logic).
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Clear the mixture ratio self-learning value. Refer to EC-685, "Work Procedure"
.
2. Start engine.
Is it difficult to start engine?
YES >> GO TO 3.
NO >> GO TO 4.
3.RESTART ENGINE
If it is difficult to start engine, the f uel injection system has a malfunction, too.
Crank engine while depressing accelerator pedal.
NOTE:
• When depressing accelerator pedal three-fourths (3/4 ) or more, the control system does not start the
engine. Do not depress accelerator pedal too much.
Does engine start?
YES >> Proceed to EC-788, "Diagnosis Procedure".
NO >> Check exhaust and intake air leakage visually.
4.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Keep engine idle for at least 5 minutes.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
Sensor Input signal to ECM ECM function Actuator
A/F sensor 1 Density of oxygen in exhaust gas
(Mixture ratio feedback signal) Fuel injection control Fuel injector
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0171 Fuel injection system too
lean (bank 1)
• Fuel injection system does not operate properly.
• The amount of mixture ratio compensation is too
large. (The mixture ratio is too lean.) • Intake air leakage
• A/F sensor 1
• Fuel injector
• Exhaust gas leakage
• Incorrect fuel pressure
• Lack of fuel
• Mass air flow sensor
• Incorrect PCV hose connection
P0174
Fuel injection system too
lean (bank 2)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1788 of 4801

NISSAN TEANA 2014 Service Manual
EC-788
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0171, P0174 FUEL INJECTION SYSTEM FUNCTION
YES >> Proceed to
EC-788, "Diagnosis Procedure".
NO >> GO TO 5.
5.PERFORM DTC CONFIRMATION PROCEDURE-III
1. Turn

Page 1789 of 4801

NISSAN TEANA 2014 Service Manual
P0171, P0174 FUEL INJECTION SYSTEM FUNCTION
EC-789
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
5. Check the continuity between A/F sensor 1
harness connector and ground, or E

Page 1790 of 4801

NISSAN TEANA 2014 Service Manual
EC-790
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0171, P0174 FUEL INJECTION SYSTEM FUNCTION
1. Start engine.
2. Perform “POWER BALANCE” in “ACTIVE TEST” mode with CONSULT.
3. Check that each circu

Page 1791 of 4801

NISSAN TEANA 2014 Service Manual
P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-791
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0172, P0175 FUEL INJE
CTION SYSTEM FUNCTION
DTC LogicINFOID:0000000009462647
DT

P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-791
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0172, P0175 FUEL INJE
CTION SYSTEM FUNCTION
DTC LogicINFOID:0000000009462647
DTC DETECTION LOGIC
With the Air/Fuel Mixture Ratio Self-Learning Control, the actual mixture ratio can be brought closely to the
theoretical mixture ratio based on the mixture ratio f eedback signal from A/F sensor 1. The ECM calculates
the necessary compensation to co rrect the offset between the actual and the theoretical ratios.
In case the amount of the compensation value is extremely large (the actual mixture ratio is too rich), the ECM
judges the condition as the fuel injection system malfunc tion and illuminates the MIL (2 trip detection logic).
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Clear the mixture ratio self-learning value. Refer to EC-685, "Work Procedure"
.
2. Start engine.
Is it difficult to start engine?
YES >> GO TO 3.
NO >> GO TO 4.
3.RESTART ENGINE
If it is difficult to start engine, the f uel injection system has a malfunction, too.
Crank engine while depressing accelerator pedal.
NOTE:
• When depressing accelerator pedal three-fourths (3/4 ) or more, the control system does not start the
engine. Do not depress accelerator pedal too much.
Does engine start?
YES >> Proceed to EC-792, "Diagnosis Procedure".
NO >> Check exhaust and intake air leakage visually.
4.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Keep engine idle for at least 5 minutes.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-792, "Diagnosis Procedure".
NO >> GO TO 5.
5.PERFORM DTC CONFIRMATION PROCEDURE-III
Sensor Input signal to ECM ECM function Actuator
A/F sensor 1 Density of oxygen in exhaust gas
(Mixture ratio feedback signal) Fuel injection control Fuel injector
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0172 Fuel injection system too
rich (bank 1) • Fuel injection system does not operate properly. • The amount of mixture ratio compensation is too large. (The mixture ratio is too rich.) • A/F sensor 1
• Fuel injector
• Exhaust gas leakage
• Incorrect fuel pressure
• Mass air flow sensor
P0175
Fuel injection system too
rich (bank 2)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1792 of 4801

NISSAN TEANA 2014 Service Manual
EC-792
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Start engine.
3. Maintain the following conditions

Load next 8 pages
