NISSAN TEANA 2014 Service Manual
DAS-136
< DTC/CIRCUIT DIAGNOSIS >[LDW]
WARNING BUZZER CIRCUIT
WARNING BUZZER CIRCUIT
Component Function CheckINFOID:0000000009464784
1.CHECK WARNING BUZZER
1. Turn the ignition switch ON.
2. Select

Page 570 of 4801

NISSAN TEANA 2014 Service Manual
DAS
LDW SYSTEM SYMPTOMSDAS-137
< SYMPTOM DIAGNOSIS > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
SYMPTOM DIAGNOSIS
LDW SYSTEM SYMPTOMS
Symptom TableINFOID:0000000009464786
NOTE:
For the operational condit

DAS
LDW SYSTEM SYMPTOMSDAS-137
< SYMPTOM DIAGNOSIS > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
SYMPTOM DIAGNOSIS
LDW SYSTEM SYMPTOMS
Symptom TableINFOID:0000000009464786
NOTE:
For the operational conditions of Lane Departure Wa rning (LDW), refer to the following description.
•LDW: DAS-77, "System Description"
Symptom Possible cause Inspection item/Reference page
Indicator/warning lamps do not
illuminate when ignition switch
OFF ⇒ ON Lane departure warning
lamp (orange) does not illu-
minate. • Combination meter
• ITS control unit Lane departure warning lamp
does not turn ON
Refer to DAS-138, "Description"
Warning systems ON indica-
tor does not illuminate. • Harness between ITS control
unit and warning systems
switch
• Warning systems switch
• ITS control unit Warning systems ON indicator
circuit
Refer to DAS-134, "Component
Function Check"
Lane departure warning
lamp (orange) ON indicator
lamp (white) does not illumi-
nate. • Combination meter
• ITS control unit • Lane departure warning lamp
does not turn ON
Refer to DAS-138, "Descrip-
tion"
All of indicator/warning
lamps does not illuminate;
• Lane departure warning lamp (orange)
• Warning systems ON indi-
cator • Power supply and ground cir-
cuit of ITS control unit
• ITS control unit Power supply and ground circuit
of ITS control unit
Refer to DAS-131, "Diagnosis
Procedure"
LDW system is not activated.
(Indicator/warning lamps illumi-
nate when ignition switch OFF
⇒ ON) Warning systems ON indica-
tor is not turned ON ⇔ OFF
when operating warning
systems switch • Harness between ITS control
unit and warning systems
switch
• Harness between warning systems switch and ground
• Warning systems switch
• ITS control unit • Warning systems switch cir-
cuit
Refer to DAS-132, "Compo-
nent Function Check"
• LDW system setting cannot
be turned ON/OFF on the nav-
igation screen
Refer to DAS-140, "Diagnosis
Procedure"
Warning buzzer is not
sounding.
(Lane departure warning
lamp is activated.) • Warning buzzer
• ITS control unit Refer to
DAS-136, "Component
Function Check"
Warning functions are not timely
(Example)
• Does not function when driving on lane markers
• Functions when driving in a lane
• Functions in a different position from the actual position. • Lane camera unit
• ITS control unit Camera ca
libration
DAS-107, "Description"
Functions when changing the course in direction of the turn sig-
nal Turn indicator signal (CAN)
•BCM
• ITS control unit System operates even when us-
ing turn signal . Refer to DAS-
139, "Description"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 571 of 4801

NISSAN TEANA 2014 Service Manual
DAS-138
< SYMPTOM DIAGNOSIS >[LDW]
LANE DEPARTURE WARNING LAMP DOES NOT TURN ON
LANE DEPARTURE WARNING LAMP DOES NOT TURN ON
DescriptionINFOID:0000000009464787
The lane departure warning lamp in the

Page 572 of 4801

NISSAN TEANA 2014 Service Manual
DAS
THE SYSTEM OPERATES EVEN WHEN USING TURN SIGNAL
DAS-139
< SYMPTOM DIAGNOSIS > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
THE SYSTEM OPERATES EVEN WH EN USING TURN SIGNAL
DescriptionINFOID:000000000946

Page 573 of 4801

NISSAN TEANA 2014 Service Manual
DAS-140
< SYMPTOM DIAGNOSIS >[LDW]
LDW SYSTEM SETTINGS CANNOT BE T
URNED ON/OFF IN VEHICLE INFOR-
MATION DISPLAY
LDW SYSTEM SETTINGS CANNOT BE TURNED ON/OFF IN VEHICLE IN-
FORMATION DISPLAY
Descript

DAS-140
< SYMPTOM DIAGNOSIS >[LDW]
LDW SYSTEM SETTINGS CANNOT BE T
URNED ON/OFF IN VEHICLE INFOR-
MATION DISPLAY
LDW SYSTEM SETTINGS CANNOT BE TURNED ON/OFF IN VEHICLE IN-
FORMATION DISPLAY
DescriptionINFOID:0000000009464791
• LDW system setting is not selectable on the navigation screen.
• NOTE:
When the ignition switch is in ACC posit ion, LDW system setting cannot be changed.
- “Lane Departure Warning” is not indicated on the navigation screen.
- The switching between ON and OFF cannot be per formed by operating the navigation system.
- The item of “Lane Departure Warning” on the navigation screen is not active.
• After turning ON the ignition switch or starting t he engine, LDW setting of the navigation system cannot be
selected for several tens of sec onds under the following conditions:
- After replacing AV control unit.
- After erasing connection histor y of the navigation system.
- After erasing self-diagnosis results of AV control unit.
• The LDW or LDP system setting differs from the one set at the previous driving.
NOTE:
Turn OFF the ignition switch and wait for 5 seconds or more.
Diagnosis ProcedureINFOID:0000000009464792
1.CHECK LDW SYSTEM SETTING
1. Start the engine.
2. Check that the LDW system settings is selectable on the navigation screen.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.PERFORM THE SELF-DIAGNOSIS
1. Perform “All DTC Reading” with CONSULT.
2. Check if the DTC is detected in self-diagnosis re sults of “AVM”, “MULTI AV” and “METER/M&A”. Refer to
the following.
-AVM: DAS-89, "DTC Index"
- MULTI AV (with BOSE): AV-328, "DTC Index"
- MULTI AV (without BOSE): AV-231, "DTC Index"
- METER/M&A: MWI-27, "DTC Index"
Is any DTC detected?
YES >> Repair or replace malfunctioning parts.
NO >> Inspection End.
3.CHECK DATA MONITOR OF ITS CONTROL UNIT
Check that “LDW SELECT” operates normally in “DATA MONITOR” of “AVM” with CONSULT.
Is the inspection result normal?
YES >> Refer to DAS-83, "CONSULT Function (AVM)".
NO >> GO TO 4.
4.CHECK MULTIFUNCTION SWITCH
Operate the multifunction switch to check that the audio, navigation system, and air conditioner operate prop-
erly.
Is the inspection result normal?
YES >> Replace the ITS control unit. Refer to DAS-68, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 574 of 4801

NISSAN TEANA 2014 Service Manual
DAS
NORMAL OPERATING CONDITIONDAS-141
< SYMPTOM DIAGNOSIS > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000009464793
PRECAUTIONS FOR LANE DEPARTURE WARNING

Page 575 of 4801

NISSAN TEANA 2014 Service Manual
DAS-142
< REMOVAL AND INSTALLATION >[LDW]
WARNING SYSTEMS SWITCH
REMOVAL AND INSTALLATION
WARNING SYSTEMS SWITCH
Removal and InstallationINFOID:0000000009464796
REMOVAL
1. Remove the instrument lower

Page 576 of 4801

NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERADAS-143
< REMOVAL AND INSTALLATION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
REAR VIEW CAMERA
Exploded ViewINFOID:0000000009978535
Removal and InstallationINFOID:0000000009978536
RE
