IGNITION TIMING
Work ProcedureINFOID:0000000009462868
1.CHECK IGNITION TIMING
1. Attach timing light (A) to loop wires as shown.
2. Check ignition timing. >> INSPECTION END
: Vehicle front
ALBIA0809ZZ
JMBIA1135GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1994 of 4801
![NISSAN TEANA 2014 Service Manual
EC-994
< PERIODIC MAINTENANCE >[VQ35DE]
EVAP LEAK CHECK
EVAP LEAK CHECK
Work ProcedureINFOID:0000000009462869
CAUTION:
• Never use compressed air or a high pressure pump.
• Never exceed 4.12 kP NISSAN TEANA 2014 Service Manual
EC-994
< PERIODIC MAINTENANCE >[VQ35DE]
EVAP LEAK CHECK
EVAP LEAK CHECK
Work ProcedureINFOID:0000000009462869
CAUTION:
• Never use compressed air or a high pressure pump.
• Never exceed 4.12 kP](/manual-img/5/57390/w960_57390-1993.png)
EC-994
< PERIODIC MAINTENANCE >[VQ35DE]
EVAP LEAK CHECK
EVAP LEAK CHECK
Work ProcedureINFOID:0000000009462869
CAUTION:
• Never use compressed air or a high pressure pump.
• Never exceed 4.12 kPa (0.042 kg/cm
2, 0.6 psi) of pressure in EVAP system.
NOTE:
• Do not start engine.
• Improper installation of EVAP service port adapter (com mercial service tool) to the EVAP service port may
cause a leakage.
WITH CONSULT
1. To locate the EVAP leakage, install EVAP service port adapter (commercial service tool) and pressure pump to EVAP service
port.
2. Turn ignition switch ON.
3. Select the “EVAP SYSTEM CLOSE” of “WORK SUPPORT MODE” with CONSULT.
4. Touch “START”. A bar graph (Pressure indicating display) will appear on the screen.
5. Apply positive pressure to the EVAP system until the pressure indicator reaches the middle of the bar graph.
6. Remove EVAP service port adapter (commercial service tool) and hose with pressure pump.
7. Locate the leakage using a leakage detector (commercial ser- vice tool). Refer to EC-580, "EVAPORATIVE EMISSION SYS-
TEM : System Description".
WITHOUT CONSULT
1. To locate the EVAP leakage, install EVAP service port adapter
(commercial service tool) and pressure pump to EVAP service
port.
2. Apply battery voltage between the terminals of EVAP canister vent control valve to ma ke a closed EVAP system.
3. To locate the leakage, deliver positive pressure to the EVAP sys- tem until pressure gauge points r each 1.38 to 2.76 kPa (0.014 to
0.028 kg/cm
2, 0.2 to 0.4 psi).
4. Remove EVAP service port adapter (commercial service tool) and hose with pressure pump.
SEF462UA
SEF200U
SEF462UA
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1995 of 4801
EVAP LEAK CHECKEC-995
< PERIODIC MAINTENANCE > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
5. Locate the leakage using a leak detector (commercial service
tool). Refer to EC-580, "EVAPORATIVE EMISSION SYSTEM :
System Description".
SEF200U
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1996 of 4801
EC-996
< PERIODIC MAINTENANCE >[VQ35DE]
POSITIVE CRANKCASE VENTILATION
POSITIVE CRANKCASE VENTILATION
Work ProcedureINFOID:0000000009462870
1.CHECK PCV VALVE
With engine running at idle, remove PCV valve from rocker cover. A
properly working valve makes a hissing noise as air passes through
it. A strong vacuum should be felt immediately when a finger is
placed over valve inlet.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace PCV valve.
PBIB1589E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1997 of 4801
ECM
EC-997
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
REMOVAL AND INSTALLATION
ECM
Removal and InstallationINFOID:0000000009462871
CAUTION:
Perform ADDITIONAL SERVICE WHEN REPLACING ECM. Refer to EC-679, "Work Procedure"
.
REMOVAL
1. Remove battery. Refer to PG-73, "Exploded View".
2. Disconnect ECM harness connectors. Refer to PG-65, "Description"
.
3. Remove ECM mounting nuts (A), and then remove ECM (1).
INSTALLATION
Install in the reverse order of removal.
JSBIA1367GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1998 of 4801
![NISSAN TEANA 2014 Service Manual
EC-998
< SERVICE DATA AND SPECIFICATIONS (SDS) [VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:000000000946 NISSAN TEANA 2014 Service Manual
EC-998
< SERVICE DATA AND SPECIFICATIONS (SDS) [VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:000000000946](/manual-img/5/57390/w960_57390-1997.png)
EC-998
< SERVICE DATA AND SPECIFICATIONS (SDS) [VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000009462872
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000009462873
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000009462874
Mass Air Flow SensorINFOID:0000000009462875
*: Engine is warmed up to normal operating temperature and running under no load. Condition Specification
No load* (in P or N position) 650 ± 50 rpm
Condition Specification
No load* (in P or N position) 12 ± 2 ° BTDC
Condition Specification (Using CONSULT or GST)
At idle 10 – 35 %
At 2,500 rpm 10 – 35 %
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle (in N position) 0.9 – 1.2 V*
Mass air flow (Using CONSULT or GST) 2.0 – 6.0 g/s at idle*
7.0 – 20.0 g/s at 2,500 rpm*
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
