P2135 TP SENSOREC-489
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK THROTTLE POSITI ON SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
*1: Except for California
*2: For California
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK THROTTLE PO SITION SENSOR INPUT SIGNAL CIRCUIT
1. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
*1: Except for California
*2: For California
2. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK THROTTLE POSITION SENSOR
Check the throttle position sensor. Refer to EC-490, "Component Inspection"
.
Is the inspection result normal?
+ −
Continuity
Electric throttle control actu-
ator ECM
Connector Terminal Connector Terminal
F57 2 F13
*1
F90*280 Existed
+
−
Continuity
Electric throttle control actu-
ator ECM
Connector Terminal Connector Terminal
F57 4 F13
*1
F90*278 Existed
+
−
Continuity
Electric throttle control actu-
ator ECM
Connector Terminal Connector Terminal
F57 1
F13
*1
F90*2
79
Existed
377
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
