Page 4369 of 4801

NISSAN TEANA 2014 Service Manual
TM-154
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0967 PRESSURE CONTROL SOLENOID B
NO >> GO TO 3.
3.CHECK CIRCUIT BETWEEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-

Page 4370 of 4801

NISSAN TEANA 2014 Service Manual
P2765 INPUT SPEED SENSOR BTM-155
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P2765 INPUT SPEED SENSOR B
DTC LogicINFOID:0000000009464097
DTC DETECTION LOGIC
DTC CONFIRM

P2765 INPUT SPEED SENSOR BTM-155
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P2765 INPUT SPEED SENSOR B
DTC LogicINFOID:0000000009464097
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P2765 INPUT SPEED SENSOR B
(Input/Turbine Speed Sensor
B Circuit) When 1 is satisfied and any of 2, 3 or 4 is sat-
isfied and this state is maintained for 5 sec-
onds:
1. When all of the following conditions are
satisfied:
- TCM power supply voltage: More than 11 V
- After range change completion, it spends 2 seconds or more.
2. When all of the following conditions are
satisfied and this state is maintained for
5 seconds:
- Secondary pulley speed: Less than 149
rpm
- Primary pulley speed: 1,000 rpm or more
3. When all of the following conditions are
satisfied and this state is maintained for
0.5 seconds:
- 10-msec-ago secondary pulley speed: 1000 rpm or more
- Now secondary pulley speed: 0 rpm
4. When all of the following conditions are satisfied and this state is maintained for
5 seconds:
- Range: D or DS
- Engine speed: 450 rpm or more
- Primary pulley speed: 300 rpm or more
- Secondary pulley speed: 300 rpm or more
- Input speed: 300 rpm or more
- The difference between engine speed and primary pulley speed is 1,000 rpm or
less
- The difference between engine speed and input speed is 1,000 rpm or less
- The difference between primary pulley speed and input speed is 1,000 rpm or
less
- Lock-up command is being given (except for slip lock-up)
- DTC other than the applicable DTC is not
detected.
- When any of following items are satis- fied:
• Primary pulley speed/secondary pulley speed: More than 2.9
• Primary pulley speed/secondary pulley
speed: Less than 0.3 • Harness or connector
(Output speed sensor circuit is open or
shorted)
• Output speed sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4371 of 4801

NISSAN TEANA 2014 Service Manual
TM-156
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P2765 INPUT SPEED SENSOR B
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 se

Page 4372 of 4801

NISSAN TEANA 2014 Service Manual
P2765 INPUT SPEED SENSOR BTM-157
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CHECK CIRCUIT BETWEEN OUT

Page 4373 of 4801

NISSAN TEANA 2014 Service Manual
TM-158
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P2813 SELECT SOLENOID
P2813 SELECT SOLENOID
DTC LogicINFOID:0000000009464099
DTC DETECTION LOGIC
NOTE:
DC stands for “DRIVING CYCLE” and indicates

TM-158
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P2813 SELECT SOLENOID
P2813 SELECT SOLENOID
DTC LogicINFOID:0000000009464099
DTC DETECTION LOGIC
NOTE:
DC stands for “DRIVING CYCLE” and indicates a seri es of driving cycle of “Ignition switch OFF → ON → driv-
ing → OFF”.
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P2813 SELECT SOLENOID
(Select solenoid) When any of 1, or 2 is satisfied:
1. When all the following conditions are es- tablished three times in 1DC
-Precondition
• DTC other than the applicable DTC is not detected.
• Throtte position: More than 6.27 deg.
• Vehicle speed: Less than 3 km/h (1 MPH)
• CVT fluid temperature: More than 20 °C
(68 °F)
• Selector lever: Other than P, N
• Turbine speed when performed N → D,
N (P) → R: More than 500 rpm
• TCM power supply voltage: More than 11 V
- Detection time
•N → D: 0.4 seconds
•N → R: 0.3 seconds
•P → R: 0.3 seconds
2. When all of the following conditions are satisfied and this state is maintained for
30 seconds:
- The counting of time continues while all of the following conditions are satisfied
and stops when the conditions become
unsatisfied (the count is maintained).
When accumulated time reaches 30 sec-
onds (Clutch is judged as engaged and
the count is reset.)
• Selector lever: Other than P, N
• Vehicle speed: Less than 3 km/h (1
MPH)
• Differences between primary pulley speed and secondary speed speed:
Less than 120 rpm
• Clutch instructions pressure: 0.95 MPa or more
• Differences between turbine speed and input speed speed: Less than 200 rpm
• Turbine speed – speed: More than 450
rpm
• DTC other than the applicable DTC is not detected.
• TCM power supply voltage: More than 11 V Select solenoid valve
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4374 of 4801

NISSAN TEANA 2014 Service Manual
P2813 SELECT SOLENOIDTM-159
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait fo

Page 4375 of 4801

NISSAN TEANA 2014 Service Manual
TM-160
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P2814 SELECT SOLENOID
P2814 SELECT SOLENOID
DTC LogicINFOID:0000000009464101
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the

Page 4376 of 4801

NISSAN TEANA 2014 Service Manual
P2814 SELECT SOLENOIDTM-161
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermitt
