LAN-52
< DTC/CIRCUIT DIAGNOSIS >[CAN]
IPDM-E BRANCH LINE CIRCUIT
IPDM-E BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461427
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the IPDM E/R for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of IPDM E/R.
2. Check the resistance between the IPDM E/R harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the IPDM E/R branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the IPDM E/R. Refer to PCS-31, "Diagnosis Procedure"
.
Is the inspection result normal?
YES (Present error)>>Replace the IPDM E/R. Refer to PCS-32, "Removal and Installation".
YES (Past error)>>Error was detected in the IPDM E/R branch line.
NO >> Repair the power supply and the ground circuit.
IPDM E/R harness connector Resistance (Ω)
Connector No. Terminal No.
E63 29 28 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3002 of 4801
![NISSAN TEANA 2014 Service Manual
LAN
TCM BRANCH LINE CIRCUITLAN-53
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461428
1.CHECK CONNECTOR
1. Turn the igni NISSAN TEANA 2014 Service Manual
LAN
TCM BRANCH LINE CIRCUITLAN-53
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461428
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/5/57390/w960_57390-3001.png)
LAN
TCM BRANCH LINE CIRCUITLAN-53
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461428
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con- nector side).
-TCM
- Harness connector F2
- Harness connector E11
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the TCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the TCM. Refer to the following.
• QR25DE: TM-164, "Diagnosis Procedure"
• VQ35DE: TM-366, "Diagnosis Procedure"
Is the inspection result normal?
YES (Present error)>>Replace the TCM. Refer to the following.
• QR25DE: TM-183, "Removal and Installation"
• VQ35DE: TM-384, "Removal and Installation"
YES (Past error)>>Error was detected in the TCM branch line.
NO >> Repair the power supply and the ground circuit.
TCM harness connector Resistance (Ω)
Connector No. Terminal No.
F16 33 23 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3003 of 4801
LAN-54
< DTC/CIRCUIT DIAGNOSIS >[CAN]
DLC BRANCH LINE CIRCUIT
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461429
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection (connector side and harness side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
Is the measurement value within the specification?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the data link connector branch line circuit.
NO >> Repair the data link connector branch line.
Data link connector Resistance (Ω)
Connector No. Terminal No.
M22 6 14 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3004 of 4801
![NISSAN TEANA 2014 Service Manual
LAN
M&A BRANCH LINE CIRCUITLAN-55
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461430
1.CHECK CONNECTOR
1. Turn the igni NISSAN TEANA 2014 Service Manual
LAN
M&A BRANCH LINE CIRCUITLAN-55
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461430
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/5/57390/w960_57390-3003.png)
LAN
M&A BRANCH LINE CIRCUITLAN-55
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461430
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the combination meter branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the combination meter. Refer to MWI-58, "COMBINATION
METER : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the combination meter. Refer to MWI-82, "Removal and Installation".
YES (Past error)>>Error was detected in the combination meter branch line.
NO >> Repair the power supply and the ground circuit.
Combination meter harness connector Resistance (Ω)
Connector No. Terminal No.
M24 39 38 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3005 of 4801
![NISSAN TEANA 2014 Service Manual
LAN-56
< DTC/CIRCUIT DIAGNOSIS >[CAN]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461431
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect th NISSAN TEANA 2014 Service Manual
LAN-56
< DTC/CIRCUIT DIAGNOSIS >[CAN]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461431
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect th](/manual-img/5/57390/w960_57390-3004.png)
LAN-56
< DTC/CIRCUIT DIAGNOSIS >[CAN]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461431
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steering angle sensor for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steeri ng angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-47, "Wiring Dia-
gram".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-132, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M53 5 2 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3006 of 4801
![NISSAN TEANA 2014 Service Manual
LAN
A-BAG BRANCH LINE CIRCUITLAN-57
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461432
WARNING:
Always observe the f NISSAN TEANA 2014 Service Manual
LAN
A-BAG BRANCH LINE CIRCUITLAN-57
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461432
WARNING:
Always observe the f](/manual-img/5/57390/w960_57390-3005.png)
LAN
A-BAG BRANCH LINE CIRCUITLAN-57
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461432
WARNING:
Always observe the following items fo r preventing accidental activation.
• Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
• Never use unspecified tester or other measuring device.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the air bag diagnosis sensor unit for damage, bend and loose con-
nection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the main harness.
2.CHECK AIR BAG DIAGNOSIS SENSOR UNIT
Check the air bag diagnosis sensor unit. Refer to SRC-40, "Work Flow"
.
Is the inspection result normal?
YES >> Replace the main harness.
NO >> Replace parts whose air bag system has a malfunction.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3007 of 4801
![NISSAN TEANA 2014 Service Manual
LAN-58
< DTC/CIRCUIT DIAGNOSIS >[CAN]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461433
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the ba NISSAN TEANA 2014 Service Manual
LAN-58
< DTC/CIRCUIT DIAGNOSIS >[CAN]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461433
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the ba](/manual-img/5/57390/w960_57390-3006.png)
LAN-58
< DTC/CIRCUIT DIAGNOSIS >[CAN]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461433
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the AV c ontrol unit for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of AV control unit.
2. Check the resistance between the AV control unit harness connector terminals.
- With navigation system without BOSE audio system
- With navigation system and BOSE audio system
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the AV control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the AV control unit. Refer to the following.
• With navigation system without BOSE audio system: AV-270, "AV CONTROL UNIT : Diagnosis Procedure"
• With navigation system and BOSE audio system: AV-376, "AV CONTROL UNIT : Diagnosis Procedure"
Is the inspection result normal?
YES (Present error)>>Replace the AV control unit. Refer to the following.
• With navigation system without BOSE audio system: AV-298, "Removal and Installation"
• With navigation system and BOSE audio system: AV-418, "Removal and Installation"
YES (Past error)>>Error was detected in the AV control unit branch line.
NO >> Repair the power supply and the ground circuit.
AV control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M96 8 17 Approx. 54 – 66
AV control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M151 8 17 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3008 of 4801
![NISSAN TEANA 2014 Service Manual
LAN
AVM BRANCH LINE CIRCUITLAN-59
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
AVM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461434
1.CHECK CONNECTOR
1. Turn the igni NISSAN TEANA 2014 Service Manual
LAN
AVM BRANCH LINE CIRCUITLAN-59
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
AVM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461434
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/5/57390/w960_57390-3007.png)
LAN
AVM BRANCH LINE CIRCUITLAN-59
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
AVM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000009461434
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the ITS c ontrol unit for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ITS control unit.
2. Check the resistance between the ITS control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ITS control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circui t of the ITS control unit. Refer to DAS-62, "Diagnosis Proce-
dure".
Is the inspection result normal?
YES (Present error)>>Replace the ITS control unit. Refer to DAS-68, "Removal and Installation".
YES (Past error)>>Error was detected in the ITS control unit branch line.
NO >> Repair the power supply and the ground circuit.
ITS control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M58 27 7 Approx. 54 – 66
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
