Page 1713 of 4801

NISSAN TEANA 2014 Service Manual
U0101 CAN COMM CIRCUITEC-713
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
U0101 CAN COMM CIRCUIT
DescriptionINFOID:0000000009462574
CAN (Controller Area Network) is a serial co

Page 1714 of 4801

NISSAN TEANA 2014 Service Manual
EC-714
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
U1001 CAN COMM CIRCUIT
U1001 CAN COMM CIRCUIT
DescriptionINFOID:0000000009462577
CAN (Controller Area Network) is a serial communication
line for real time a

Page 1715 of 4801

NISSAN TEANA 2014 Service Manual
P0011, P0021 IVT CONTROLEC-715
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000009462580
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or

P0011, P0021 IVT CONTROLEC-715
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000009462580
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P0021 is displayed with DTC P0075 or P0081, first perform the trouble diagnosis for
DTC P0075, P0081. Refer to EC-725, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
With CONSULT
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT.
2. Start engine and warm it up to the normal operating temperature.
3. Maintain the following conditions for at least 6 c onsecutive seconds. Hold the accelerator pedal as steady
as possible.
CAUTION:
Always drive at a safe speed.
4. Stop vehicle with engine running and let engine idle for 10 seconds.
5. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-716, "Diagnosis Procedure"
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
With CONSULT
1. Maintain the following conditions for at least 20 consecutive seconds.
DTC No. Trouble diagnosis
name DTC detecting condition Possible cause
P0011 Intake valve timing
control performance
(bank 1)
There is a gap between angle of target and
phase-control angle degree. • Crankshaft position sensor (POS)
• Camshaft positi on sensor (PHASE)
• Intake valve timing control solenoid valve
• Accumulation of debris to the signal pick-up portion of the camshaft
• Timing chain installation
• Foreign matter caught in the oil groove for in- take valve timing control
P0021
Intake valve timing
control performance
(bank 2)
ENG SPEED 1,200 - 2,000 rpm
COOLAN TEMP/S More than 60 °C (140 °F)
Selector lever D position
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1716 of 4801

NISSAN TEANA 2014 Service Manual
EC-716
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0011, P0021 IVT CONTROL
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip D

EC-716
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0011, P0021 IVT CONTROL
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-716, "Diagnosis Procedure"
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462581
1.CHECK OIL PRESSURE WARNING LAMP
1. Start engine.
2. Check oil pressure warning lamp and confirm it is not illumi- nated.
Is oil pressure warming lamp illuminated?
YES >> Check the engine oil level. Refer to LU-25, "Inspection".
NO >> GO TO 2.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Check intake valve timing control solenoid valve. Refer to EC-717, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace malfunctioning intake valve timing control solenoid valve. Refer to EM-172, "Intake Valve
Timing Control Solenoid Valve (LH) (bank 2)" or EM-173, "Intake Valve Timing Control Solenoid
Valve (RH) (bank 1)".
3.CHECK CRANKSHAFT POSI TION SENSOR (POS)
Check crankshaft position sensor (POS). Refer to EC-819, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace crankshaft position sensor (POS). Refer to EM-157, "Removal and Installation (Upper Oil
Pan)".
4.CHECK CAMSHAFT POSITION SENSOR (PHASE)
Check camshaft position sensor (PHASE). Refer to EC-822, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning camshaft position sensor (PHASE). Refer to EM-168, "Removal and
Installation LH" or EM-169, "Removal and Installation RH".
5.CHECK CAMSHAFT (INTAKE)
Check the following.
ENG SPEED 1,200 - 3,175 rpm (A cons tant rotation is maintained.)
COOLAN TEMP/S More than 60 °C (140 °F)
Selector lever 1st or 2nd position
Driving location uphill Driving vehicle uphill
(Increased engine load will help maintain the driving conditions re-
quired for this test.)
PBIA8559J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1717 of 4801

NISSAN TEANA 2014 Service Manual
P0011, P0021 IVT CONTROLEC-717
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
• Accumulation of debris on the signal plate of camshaft rear end
• Chipping signal plate of ca

P0011, P0021 IVT CONTROLEC-717
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
• Accumulation of debris on the signal plate of camshaft rear end
• Chipping signal plate of camshaft rear end
Is the inspection result normal?
YES >> GO TO 6.
NO >> Remove debris and clean the signal plate of camshaft rear end or replace camshaft. Refer to EM-194,
"Removal and Installation".
6.CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misalignment.
Are there any service records that may cause timing chain misalignment?
YES >> Check timing chain installation. Refer to EM-182, "Removal and Installation".
NO >> GO TO 7.
7.CHECK LUBRICATION CIRCUIT
Check lubrication circuit. Refer to EM-202, "Inspection after Installation"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Clean lubrication line.
Component InspectionINFOID:0000000009462582
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-I
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Check resistance between intake valve timing control solenoid valve terminals as per the following.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace malfunctioning intake valve timing control solenoid valve. Refer to EM-172, "Intake Valve
Timing Control Solenoid Valve (LH) (bank 2)" or EM-173, "Intake Valve Timing Control Solenoid
Valve (RH) (bank 1)".
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-II
1. Remove intake valve timing control solenoid valve. Refer to EM-172, "Intake Valve Timing Control Sole-
noid Valve (LH) (bank 2)" or EM-173, "Intake Valve Timing Control Solenoid Valve (RH) (bank 1)".
JMBIA0058ZZ
Intake valve timing control solenoid valve
Resistance
+ −
Te r m i n a l
1 2 7.0 - 7.7 Ω [at 20 °C (68 °F)]
1 Ground ∞
Ω
(Continuity should not exist)
2
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1718 of 4801

NISSAN TEANA 2014 Service Manual
EC-718
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0011, P0021 IVT CONTROL
2. Provide 12 V DC between intake valve timing control solenoid
valve terminals 1 and 2, and then interrupt it. Check that the
plung

Page 1719 of 4801

NISSAN TEANA 2014 Service Manual
P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
EC-719
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0031, P0032, P0051, P0052
A/F SENSOR 1 HEATER
DTC LogicINFOID:0000000009462

P0031, P0032, P0051, P0052 A/F SENSOR 1 HEATER
EC-719
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0031, P0032, P0051, P0052
A/F SENSOR 1 HEATER
DTC LogicINFOID:0000000009462583
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-719, "Diagnosis Procedure".
NG >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462584
1.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY
1. Disconnect air fuel ratio (A/F) sensor 1 harness connector.
2. Turn ignition switch ON.
3. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0031 Air fuel ratio (A/F) sensor
1 heater (bank 1) control
circuit low The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the A/F sensor 1 heater.) • Harness or connectors
(The A/F sensor 1 heater circuit is
open or shorted.)
• A/F sensor 1 heater
P0032 Air fuel ratio (A/F) sensor
1 heater (bank 1) control
circuit high The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the A/F sensor 1 heater.) • Harness or connectors
(The A/F sensor 1 heater circuit is
shorted.)
• A/F sensor 1 heater
P0051 Air fuel ratio (A/F) sensor
1 heater (bank 2) control
circuit low The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the A/F sensor 1 heater.) • Harness or connectors
(The A/F sensor 1 heater circuit is
open or shorted.)
• A/F sensor 1 heater
P0052 Air fuel ratio (A/F) sensor
1 heater (bank 2) control
circuit high The current amperage in the A/F sensor 1 heater
circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the A/F sensor 1 heater.) • Harness or connectors
(The A/F sensor 1 heater circuit is
shorted.)
• A/F sensor 1 heater
DTC A/F sensor 1
Ground Voltage
Bank Connector Terminal
P0031, P0032 1 F12 4 Ground Battery voltage
P0051, P0052 2 F61 4
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1720 of 4801

NISSAN TEANA 2014 Service Manual
EC-720
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0031, P0032, P0051, P00
52 A/F SENSOR 1 HEATER
NO >> GO TO 2.
2.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Dis

EC-720
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
P0031, P0032, P0051, P00
52 A/F SENSOR 1 HEATER
NO >> GO TO 2.
2.CHECK AIR FUEL RATIO (A/F) SENSOR 1 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between A/F sensor 1 harness connector and IPDM E/R harness connector.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK A/F SENSOR 1 HEATER OUTPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between A/F sensor 1 harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK A/F SENSOR 1 HEATER
Check A/F sensor 1 heater. Refer to EC-720, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace malfunctioning air fuel ratio (A/F) sensor 1. Refer to EM-152, "Removal and Installation
(LH)" or EM-153, "Removal and Installation (RH)".
Component InspectionINFOID:0000000009462585
1.CHECK AIR FUEL RATIO (A/F) SENSOR 1
1. Turn ignition switch OFF.
2. Disconnect A/F sensor 1 harness connector.
3. Check resistance between A/F sensor 1 terminals as per the following.
Is the inspection result normal?
DTC A/F sensor 1 IPDM E/R
Continuity
Bank Connector Terminal Connector Terminal
P0031, P0032 1 F12 4 F8352
Existed
P0051, P0052 2 F61 4 53
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P0031, P0032 1 F12 3 F786
Existed
P0051, P0052 2 F61 3 3
+ −
Resistance
A/F sensor 1
Te r m i n a l
3 4 1.8 - 2.44
Ω [at 25 °C (77 °F)]
1
∞ Ω
(Continuity should not exist)
2
4 1
2
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Load next 8 pages

Page: < prev 1-10 ... 1681-1688 1689-1696 1697-1704 1705-1712 1713-1720 1721-1728 1729-1736 1737-1744 1745-1752 ... 4808 next >

wheel size engine coolant fuel consumption check engine light headrest rear view mirror
