Page 1625 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-625
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
89
(LG) 84
(SB) Crankshaft position sensor
(POS) Input[Engine is running]
• Warm-up condition
• Idle speed NO

Page 1626 of 4801

NISSAN TEANA 2014 Service Manual
EC-626
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
96
(R) 64
(P) Sensor power supply
(Refrigerant pressure sensor) — [Ignition switch: ON] 5 V
97
(W) 100
(O) Accelerator pedal position
sensor 1 In

Page 1627 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-627
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
*1: This may vary dependi

Page 1628 of 4801

NISSAN TEANA 2014 Service Manual
EC-628
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
DTC RELATED ITEM
Engine operating condi-
tion in fail-safe mode Detected items Remarks
Reference
page
Engine speed will not
rise more than 2,500 rp

EC-628
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
DTC RELATED ITEM
Engine operating condi-
tion in fail-safe mode Detected items Remarks
Reference
page
Engine speed will not
rise more than 2,500 rpm
due to the fuel cut Malfunction indicator
lamp circuit When there is an open circuit on MIL circuit, the ECM cannot warn the
driver by illuminating MIL when there is malfunction on engine control
system.
Therefore, when electrical controlled throttle and part of ECM related
diagnoses are continuously detected as NG for 5 trips, ECM warns the
driver that engine control system malfunctions and MIL circuit is open
by means of operating the fail-safe function.
The fail-safe function also operates when above diagnoses except MIL
circuit are detected and demands the driver to repair the malfunction. EC-973
DTC No. Detected items Engine operating condition in fail-safe mode
P0011
P0021 Intake valve timing control The signal is not energized to the intake valve timing control solenoid valve and the valve
control does not function.
P0101
P0102
P0103 Mass air flow sensor circuit Engine speed will not rise more than 2,400 rpm due to the fuel cut.
P0117
P0118 Engine coolant tempera-
ture sensor circuit Engine coolant temperature will be determined by ECM based on the following condition.
CONSULT displays the engine coolant temperature decided by ECM.
Condition Engine coolant temperature decided
(CONSULT display)
Just as ignition switch is turned ON
or START 40
°C (104 °F)
Approx 4 minutes or more after en-
gine starting 80
°C (176 °F)
Except as shown above 40 - 80
°C (104 - 176 °F)
(Depends on the time)
When the fail-safe system for engine coolant temperature sensor is activated, the cooling
fan operates while engine is running.
P0122
P0123
P0222
P0223
P2135 Throttle position sensor The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
Therefore, the acceleration will be poor.
P0196
P0197
P0198 Engine oil temperature
sensor Intake valve timing control does not function.
P0500 Vehicle speed sensor The cooling fan operates (Highest) while engine is running.
P0524 Engine oil pressure • ECM illuminates oil pressure warning lamp on the combination meter.
• Engine speed will not rise more than 4,000 rpm due to the fuel cut.
• Fail-safe is canceled when ignition switch OFF → ON.
P0605 ECM (When ECM calculation function is malfunctioning:) ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
ECM deactivates ASCD operation.
P0643 Sensor power supply ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
P1805 Brake switch ECM controls the electric throttle control actuator by regulating the throttle opening to a small range.
Therefore, acceleration will be poor.
Vehicle condition Driving condition
When engine is idling Normal
When accelerating Poor acceleration
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1629 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-629
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
DTC Inspection Priority ChartINFOID:0000000009462544
If some DTCs are displayed at the same time, perform inspection

ECM
EC-629
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
DTC Inspection Priority ChartINFOID:0000000009462544
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
P2100
P2103 Throttle control motor relay ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2101 Electric th rottle control
function ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2118 Throttle control motor ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return spring.
P2119 Electric thro ttle control ac-
tuator (When electric throttle control actuator does not function properly due to the return spring
malfunction:)
ECM controls the electric throttle actuator by regulating the throttle opening around the
idle position. The engine speed will not rise more than 2,000 rpm.
(When throttle valve opening angle in fail-safe mode is not in specified range:)
ECM controls the electric throttle control actuator by regulating the throttle opening to 20
degrees or less.
(When ECM detects the throttle valve is stuck open:)
While the vehicle is being driven, it slows down gradually because of fuel cut. After the
vehicle stops, the engine stalls.
The engine can restart in the N or P position, and engine speed will not exceed 1,000 rpm
or more.
P2122
P2123
P2127
P2128
P2138 Accelerator pedal position
sensor The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
Therefore, the acceleration will be poor.
DTC No. Detected items Engine operating condition in fail-safe mode
Priority Detected items (DTC) Detected items (DTC)
1 U0101, U1001 CAN communication line P0101, P0102, P0103 Mass air flow sensor
P0111, P0112, P0113, P0127 Intake air temperature sensor
P0116, P0117, P0118, P0125 Engine coolant temperature sensor
P0122, P0123, P0222, P0223, P1225, P1226, P2135 Throttle position sensor
P0128 Thermostat function
P0181, P0182, P0183 Fuel tank temperature sensor
P0196, P0197, P0198 Engine oil temperature sensor
P0327, P0328, P0332, P0333 Knock sensor
P0335 Crankshaft position sensor (POS)
P0340, P0345 Camshaft position sensor (PHASE)
P0460, P0461, P0462, P0463 Fuel level sensor
P0500 Vehicle speed sensor
P0520 EOP sensor
P0605, P0607 ECM
P0643 Sensor power supply
P0850 Transmission range switch
P1550, P1551, P1552, P1553, P1554 Battery current sensor
P1556, P1557 Battery temperature sensor
P1610 - P1615 NATS
P2122, P2123, P2127, P2128, P2138 Accelerator pedal position sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1630 of 4801

NISSAN TEANA 2014 Service Manual
EC-630
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
DTC Index
INFOID:0000000009462545
× :Applicable —: Not applicable
2 P0031, P0032, P0051, P0052 Air fuel ratio (A/F) sensor 1 heater
P0037, P0038, P

EC-630
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
DTC Index
INFOID:0000000009462545
× :Applicable —: Not applicable
2 P0031, P0032, P0051, P0052 Air fuel ratio (A/F) sensor 1 heater
P0037, P0038, P0057, P0058 Heated oxygen sensor 2 heater
P0075, P0081 Intake valve timing control solenoid valve
P0130, P0131, P0132, P014 C, P014D, P014E, P014F,
P0150, P0151, P0152, P209 6, P2097, P2098, P2099 Air fuel ratio (A/F) sensor 1
P0137, P0138, P0139, P0157, P0158, P0159 Heated oxygen sensor 2
P0441 EVAP control system purge flow monitoring
P0443, P0444, P0445 EVAP canister purge volume control solenoid valve
P0447, P0448 EVAP canister vent control valve
P0451, P0452, P0453 EVAP control system pressure sensor
P0603 ECM power supply
P1217 Engine over temperature (OVERHEAT)
P1800, P1801 VIAS cont rol solenoid valve
P1805 Brake switch
P2100, P2103 Throttle control motor relay
P2101 Electric throttle control function
P2118 Throttle control motor
3 P0011, P0021 Intake valve timing control P0171, P0172, P0174, P0175 Fuel injection system function
P0300 - P0306 Misfire
P0420, P0430 Three way catalyst function
P0456 EVAP control syst em (VERY SMALL LEAK)
P0506, P0507 Idle speed control system
P050A, P050E Cold start control
P0524 Engine oil pressure
P1148, P1168 Closed loop control
P1212 TCS communication line
P1564 ASCD steering switch
P1572 Brake pedal position switch
P1574 ASCD vehicle speed sensor
P2119 Electric throttle control actuator
Priority Detected items (DTC) Detected items (DTC)
DTC*1
Items
(CONSULT screen terms) SRT
code Trip MIL Permanent
DTC group*4Refer-
ence page
CONSULT
GST
*2ECM*3
U0101 0101*5LOST COMM (ECM) — 1 ×BEC-713
U1001
1001*5CAN COMM CIRCUIT — 2 — — EC-714
P0000 0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED. ——
Blinking*6——
P0011 0011 INT/V TIM CONT-B1 ×2 ×BEC-715
P0021 0021 INT/V TIM CONT-B2 ×2 ×BEC-715
P0031 0031 A/F SEN1 HTR (B1) — 2 ×BEC-719
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1631 of 4801

NISSAN TEANA 2014 Service Manual
ECM
EC-631
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
OP0032 0032 A/F SEN1 HTR (B1) — 2
×BEC-719
P0037 0037 HO2S2 HTR (B1) — 2 ×BEC-722
P0038 0038 HO2S2 HTR (B1) —

ECM
EC-631
< ECU DIAGNOSIS INFORMATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
OP0032 0032 A/F SEN1 HTR (B1) — 2
×BEC-719
P0037 0037 HO2S2 HTR (B1) — 2 ×BEC-722
P0038 0038 HO2S2 HTR (B1) — 2 ×BEC-722
P0051 0051 A/F SEN1 HTR (B2) — 2 ×BEC-719
P0052 0052 A/F SEN1 HTR (B2) — 2 ×BEC-719
P0057 0057 HO2S2 HTR (B2) — 2 ×BEC-722
P0058 0058 HO2S2 HTR (B2) — 2 ×BEC-722
P0075 0075 INT/V TIM V/CIR-B1 — 2 ×BEC-725
P0081 0081 INT/V TIM V/CIR-B2 — 2 ×BEC-725
P0101 0101 MAF SEN/CIRCUIT-B1 — 2 ×BEC-727
P0102 0102 MAF SEN/CIRCUIT-B1 — 1 ×BEC-732
P0103 0103 MAF SEN/CIRCUIT-B1 — 1 ×BEC-732
P0111 0111 IAT SENSOR 1 B1 — 2 ×AEC-736
P0112 0112 IAT SEN/CIRCUIT-B1 — 2 ×BEC-738
P0113 0113 IAT SEN/CIRCUIT-B1 — 2 ×BEC-738
P0116 0116 ECT SEN/CIRC — 2 ×AEC-740
P0117 0117 ECT SEN/CIRC — 1 ×BEC-742
P0118 0118 ECT SEN/CIRC — 1 ×BEC-742
P0122 0122 TP SEN 2/CIRC-B1 — 1 ×BEC-744
P0123 0123 TP SEN 2/CIRC-B1 — 1 ×BEC-744
P0125 0125 ECT SENSOR — 2 ×BEC-746
P0127 0127 IAT SENSOR-B1 — 2 ×BEC-748
P0128 0128 THERMSTAT FNCTN — 2 ×AEC-750
P0130 0130 A/F SENSOR1 (B1) — 2 ×AEC-753
P0131 0131 A/F SENSOR1 (B1) — 2 ×BEC-757
P0132 0132 A/F SENSOR1 (B1) — 2 ×BEC-760
P0137 0137 HO2S2 (B1) ×2 ×AEC-763
P0138 0138 HO2S2 (B1) ×2 ×AEC-768
P0139 0139 HO2S2 (B1) ×2 ×AEC-775
P014C 014C A/F SENSOR1 (B1) ×2 ×AEC-781
P014D 014D A/F SENSOR1 (B1) ×2 ×AEC-781
P014E 014E A/F SENSOR1 (B2) ×2 ×AEC-781
P014F 014F A/F SENSOR1 (B2) ×2 ×AEC-781
P0150 0150 A/F SENSOR1 (B2) — 2 ×AEC-753
P0151 0151 A/F SENSOR1 (B2) — 2 ×BEC-757
P0152 0152 A/F SENSOR1 (B2) — 2 ×BEC-760
P0157 0157 HO2S2 (B2) ×2 ×AEC-763
P0158 0158 HO2S2 (B2) ×2 ×AEC-768
P0159 0159 HO2S2 (B2) ×2 ×AEC-775
P015A 015A A/F SENSOR1 (B1) ×2 ×AEC-781
P015B 015B A/F SENSOR1 (B1) ×2 ×AEC-781
P015C 015C A/F SENSOR1 (B2) ×2 ×AEC-781
DTC*1
Items
(CONSULT screen terms) SRT
code Trip MIL Permanent
DTC group*4Refer-
ence page
CONSULT
GST
*2ECM*3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1632 of 4801

NISSAN TEANA 2014 Service Manual
EC-632
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
P015D 015D A/F SENSOR1 (B2)
×2 ×AEC-781
P0171 0171 FUEL SYS-LEAN-B1 — 2 ×BEC-787
P0172 0172 FUEL SYS-RICH-B1 — 2 ×BEC-791
P0174 0174 FUEL SYS-

EC-632
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
P015D 015D A/F SENSOR1 (B2)
×2 ×AEC-781
P0171 0171 FUEL SYS-LEAN-B1 — 2 ×BEC-787
P0172 0172 FUEL SYS-RICH-B1 — 2 ×BEC-791
P0174 0174 FUEL SYS-LEAN-B2 — 2 ×BEC-787
P0175 0175 FUEL SYS-RICH-B2 — 2 ×BEC-791
P0181 0181 FTT SENSOR — 2 ×A and B EC-795
P0182 0182 FTT SEN/CIRCUIT — 2 ×BEC-799
P0183 0183 FTT SEN/CIRCUIT — 2 ×BEC-799
P0196 0196 EOT SENSOR — 2 ×A and B EC-801
P0197 0197 EOT SEN/CIRC — 2 ×BEC-805
P0198 0198 EOT SEN/CIRC — 2 ×BEC-805
P0222 0222 TP SEN 1/CIRC-B1 — 1 ×BEC-807
P0223 0223 TP SEN 1/CIRC-B1 — 1 ×BEC-807
P0300 0300 MULTI CYL MISFIRE — 1 or 2 ×BEC-809
P0301 0301 CYL 1 MISFIRE — 1 or 2 ×BEC-809
P0302 0302 CYL 2 MISFIRE — 1 or 2 ×BEC-809
P0303 0303 CYL 3 MISFIRE — 1 or 2 ×BEC-809
P0304 0304 CYL 4 MISFIRE — 1 or 2 ×BEC-809
P0305 0305 CYL 5 MISFIRE — 1 or 2 ×BEC-809
P0306 0306 CYL 6 MISFIRE — 1 or 2 ×BEC-809
P0327 0327 KNOCK SEN/CIRC-B1 — 2 — — EC-815
P0328 0328 KNOCK SEN/CIRC-B1 — 2 — —EC-815
P0332 0332 KNOCK SEN/CIRC-B2 — 2 — —EC-815
P0333 0333 KNOCK SEN/CIRC-B2 — 2 — —EC-815
P0335 0335 CKP SEN/CIRCUIT — 2×BEC-817
P0340 0340 CMP SEN/CIRC-B1 — 2 ×BEC-820
P0345 0345 CMP SEN/CIRC-B2 — 2 ×BEC-820
P0420 0420 TW CATALYST SYS-B1 ×2 ×AEC-823
P0430 0430 TW CATALYST SYS-B2 ×2 ×AEC-823
P0441 0441 EVAP PURG FLOW/MON ×2 ×AEC-828
P0443 0443 PURG VOLUME CONT/V — 2 ×AEC-833
P0444 0444 PURG VOLUME CONT/V — 2 ×BEC-837
P0445 0445 PURG VOLUME CONT/V — 2 ×BEC-837
P0447 0447 VENT CONTROL VALVE — 2 ×BEC-840
P0448 0448 VENT CONTROL VALVE — 2 ×BEC-843
P0451 0451 EVAP SYS PRES SEN — 2 ×AEC-847
P0452 0452 EVAP SYS PRES SEN — 2 ×BEC-850
P0453 0453 EVAP SYS PRES SEN — 2 ×BEC-853
P0456 0456 EVAP VERY SML LEAK
×*72×AEC-857
P0460 0460 FUEL LEV SEN SLOSH — 2 ×AEC-863
P0461 0461 FUEL LEVEL SENSOR — 2 ×BEC-864
P0462 0462 FUEL LEVL SEN/CIRC — 2 ×BEC-866
DTC*1
Items
(CONSULT screen terms) SRT
code Trip MIL Permanent
DTC group*4Refer-
ence page
CONSULT
GST
*2ECM*3
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Load next 8 pages

Page: < prev 1-10 ... 1593-1600 1601-1608 1609-1616 1617-1624 1625-1632 1633-1640 1641-1648 1649-1656 1657-1664 ... 4808 next >

bulb rear view mirror auxiliary battery navigation roof roof rack
