Page 3177 of 4801

NISSAN TEANA 2014 Service Manual
OIL FILTERLU-27
< PERIODIC MAINTENANCE > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
LU
NP
O
OIL FILTER
Removal and InstallationINFOID:0000000009461050
REMOVAL
1. Drain engine oil. Refer to
LU-26, "Changing E

Page 3178 of 4801

NISSAN TEANA 2014 Service Manual
LU-28
< PERIODIC MAINTENANCE >[VQ35DE]
OIL FILTER
3. Screw the oil filter manually until it touches the installation sur-
face, then tighten it by 2/3 turn. Or tighten to specification below.
4. Refi

Page 3179 of 4801

NISSAN TEANA 2014 Service Manual
OIL PUMPLU-29
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
LU
NP
O
REMOVAL AND INSTALLATION
OIL PUMP
Exploded ViewINFOID:0000000009461051
Removal and InstallationINFOID:000000000946

Page 3180 of 4801

NISSAN TEANA 2014 Service Manual
LU-30
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL PUMP
Assembly is in the reverse order of disassembly.
• Assemble the outer rotor in the co rrect vane orientation to rotation
as noted during disasse

Page 3181 of 4801

NISSAN TEANA 2014 Service Manual
OIL PUMPLU-31
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
LU
NP
O
1. Visually inspect components for wear and damage.
2. Check oil pressure regulator valve sliding surface and val

Page 3182 of 4801

NISSAN TEANA 2014 Service Manual
LU-32
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL COOLER
OIL COOLER
Exploded ViewINFOID:0000000009461055
Removal and InstallationINFOID:0000000009461056
WARNING:
Be careful not to burn yourself, as the

Page 3183 of 4801

NISSAN TEANA 2014 Service Manual
OIL COOLERLU-33
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
LU
NP
O
When removing components such as hoses, tubes/lines, etc.
, cap or plug openings to prevent fluid from spill-
in

OIL COOLERLU-33
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
LU
NP
O
When removing components such as hoses, tubes/lines, etc.
, cap or plug openings to prevent fluid from spill-
ing.
REMOVAL
1. Remove the engine under cover. Refer to EXT-17, "Removal and Installation".
2. Remove the RH wheel and tire. Refer to WT-53, "Inspection"
.
3. Remove the front fender protector side cover RH. Refer to EXT-26, "FENDER PROTECTOR : Exploded
View".
4. Drain engine coolant. Refer to CO-36, "Changing Engine Coolant"
.
CAUTION:
Do not spill coolant on the drive belt.
5. Disconnect water hoses from oil cooler.
6. Remove the oil filter. Refer to LU-27, "Removal and Installation"
.
7. Remove oil cooler.
8. Remove core support cover. Refer to DLK-179, "Removal and Installation"
.
9. Remove front air duct. Refer to EM-84, "Removal and Installation"
.
10. Remove reservoir tank. Refer to CO-40, "Exploded View"
.
INSPECTION AFTER REMOVAL
1. Check oil cooler for cracks.
2. Check oil cooler for clogging by blowing through coolant inlet. If necessary, replace oil cooler.
Oil Pressure Relief Valve
Inspect oil pressure relief valve for movement, cracks and breaks by pushing the ball. If replacement is neces-
sary, remove valve by prying it out with a suitable tool. Install a new valve in place by tapping it.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Do not reuse copper gasket.
• When installing the oil cooler, align the oil cooler slot with the stopper of the oil pan.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level and the engine coolant level and add engine oil and engine coolant. Refer to LU-9, "Inspection"
and CO-11, "System Inspection".
2. Start the engine, and check that there is no leakage of engine oil or engine coolant.
3. Stop the engine and wait for 10 minutes.
4. Check the engine oil level and the engine coolant level again. Refer to LU-9, "Inspection"
and CO-11,
"System Inspection".
Revision: November 20132014 Altima NAM

Page 3184 of 4801

NISSAN TEANA 2014 Service Manual
LU-34
< SERVICE DATA AND SPECIFICATIONS (SDS) [VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Oil PressureINFOID:00000000094
