Page 1705 of 4801
![NISSAN TEANA 2014 Service Manual
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-705
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALP NISSAN TEANA 2014 Service Manual
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-705
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALP](/manual-img/5/57390/w960_57390-1704.png)
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-705
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
8.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALPHA-B1”, “A/F ALPHA-B2” in “S PEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> GO TO 9.
9.PERFORM POWER BALANCE TEST
1. Perform “POWER BALANCE ” in “ACTIVE TEST” mode.
2. Check that the each cylinder pr oduces a momentary engine speed drop.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 10.
10.DETECT MALFUNCTIONING PART
Check the following below.
• Ignition coil and its circuit (Refer to EC-967, "Component Function Check"
.)
• Fuel injector and its circuit (Refer to EC-962, "Component Function Check"
.)
• Intake air leakage
• Low compression pressure (Refer to EM-142, "On-Vehicle Service"
.)
Is the inspection result normal?
YES >> Replace fuel injector, refer to EM-163, "Removal and Installation", and then GO TO 11.
NO >> Repair or replace malfunctioning part and then GO TO 11.
11 .CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALPHA-B1”, “A/F ALPHA-B2” in “S PEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> GO TO 12.
12.CHECK A/F SENSOR 1 FUNCTION
Perform all DTC CONFIRMATION PROC EDURE related with A/F sensor 1.
• For DTC P0130, P0150, refer to EC-753, "DTC Logic"
.
• For DTC P0131, P0151, refer to EC-757, "DTC Logic"
.
• For DTC P0132, P0152, refer to EC-760, "DTC Logic"
.
• For DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, refer to EC-781, "DTC Logic"
.
• For DTC P2096, P2097, P2098, P2099, refer to EC-927, "DTC Logic"
.
Are any DTCs detected?
YES >> GO TO 15.
NO >> GO TO 13.
13.CHECK A/F SENSOR 1 CIRCUIT
Perform Diagnostic Procedure according to corresponding DTC.
>> GO TO 14.
14.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALPHA-B1”, “A/F ALPHA-B2” in “S PEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> GO TO 15.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1706 of 4801
![NISSAN TEANA 2014 Service Manual
EC-706
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
15.DISCONNECT AND RECONNE
CT ECM HARNESS CONNECTOR
1. Stop the engine.
2. Disconnect ECM harness connector. Check pin NISSAN TEANA 2014 Service Manual
EC-706
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
15.DISCONNECT AND RECONNE
CT ECM HARNESS CONNECTOR
1. Stop the engine.
2. Disconnect ECM harness connector. Check pin](/manual-img/5/57390/w960_57390-1705.png)
EC-706
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
15.DISCONNECT AND RECONNE
CT ECM HARNESS CONNECTOR
1. Stop the engine.
2. Disconnect ECM harness connector. Check pin terminal and connector for damage, and then reconnect it.
>> GO TO 16.
16.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALPHA-B1”, “A/F ALPHA-B2” in “ SPEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> Detect malfunctioning part according to EC-987, "Symptom Table"
.
17.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO-1 >> More than the SP value: GO TO 18.
NO-2 >> Less than the SP value: GO TO 25.
18.DETECT MALFUNCTIONING PART
1. Check for the cause of large engine friction. Refer to the following.
- Engine oil level is too high
- Engine oil viscosity
- Belt tension of power steering, alternat or, A/C compressor, etc. is excessive
- Noise from engine
- Noise from transmission, etc.
2. Check for the cause of insufficient combustion. Refer to the following.
- Valve clearance malfunction
- Intake valve timing control function malfunction
- Camshaft sprocket installation malfunction, etc.
>> Repair or replace malfunctioning part, and then GO TO 30.
19.CHECK INTAKE SYSTEM
Check for the cause of uneven air flow through mass air flow sensor. Refer to the following.
• Crushed air ducts
• Malfunctioning seal of air cleaner element
• Uneven dirt of air cleaner element
• Improper specification of intake air system
Is the inspection result normal?
YES >> GO TO 21.
NO >> Repair or replace malfunctioning part, and then GO TO 20.
20.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”, AND “B/FUEL SCHDL”
Select “A/F ALPHA-B1”, “A/F ALPHA-B2”, and “B/F UEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and
check that each indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> “B/FUEL SCHDL” is more, “A/F ALPHA-B1”, “A /F ALPHA-B2” are less than the SP value: GO TO
21.
21.DISCONNECT AND RECONNECT MASS AIR FLOW SENSOR HARNESS CONNECTOR
1. Stop the engine.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1707 of 4801
![NISSAN TEANA 2014 Service Manual
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-707
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
2. Disconnect mass air flow sensor harness connecto
r. Check pin terminal and connect NISSAN TEANA 2014 Service Manual
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-707
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
2. Disconnect mass air flow sensor harness connecto
r. Check pin terminal and connect](/manual-img/5/57390/w960_57390-1706.png)
TROUBLE DIAGNOSIS - SPECIFICATION VALUEEC-707
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
2. Disconnect mass air flow sensor harness connecto
r. Check pin terminal and connector for damage and
then reconnect it again.
>> GO TO 22.
22.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”
1. Start engine.
2. Select “A/F ALPHA-B1”, “A/F ALPHA-B2” in “S PEC” of “DATA MONITOR” mode, and check that each
indication is within the SP value.
Is the measurement value within the SP value?
YES >> Detect malfunctioning part of mass air flow sensor circuit and repair it. Refer to EC-732, "Diagno-
sis Procedure". Then GO TO 29.
NO >> GO TO 23.
23.CHECK “MAS A/F SE-B1”
Select “MAS A/F SE-B1” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> GO TO 24.
NO >> More than the SP value: Replace mass air flow sensor, refer to EM-144, "Removal and Installa-
tion", and then GO TO 29.
24.REPLACE ECM
Replace ECM. Refer to EC-997, "Removal and Installation"
.
>> GO TO 29.
25.CHECK INTAKE SYSTEM
Check for the cause of uneven air flow through mass air flow sensor. Refer to the following.
• Crushed air ducts
• Malfunctioning seal in air cleaner element
• Uneven dirt in air cleaner element
• Improper specification in intake air system
Is the inspection result normal?
YES >> GO TO 27.
NO >> Repair or replace malfunctioning part, and then GO TO 26.
26.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> Less than the SP value: GO TO 27.
27.CHECK “MAS A/F SE-B1”
Select “MAS A/F SE-B1” in “SPEC” of “DATA MONITOR” mode, and check that the indication is within the SP
value.
Is the measurement value within the SP value?
YES >> GO TO 28.
NO >> Less than the SP value: Replace mass air flow sensor, refer to EM-144, "Removal and Installa-
tion",and then GO TO 30.
28.CHECK INTAKE SYSTEM
Check for the cause of air leakage after the mass air flow sensor. Refer to the following.
• Disconnection, looseness, and cracks in air duct
• Looseness of oil filler cap
• Disconnection of oil level gauge
• Open stuck, breakage, hose disconnection, or cracks in PCV valve
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1708 of 4801
![NISSAN TEANA 2014 Service Manual
EC-708
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
• Disconnection or cracks in EVAP purge hose, stu
ck open EVAP canister purge volume control solenoid
valve
• Malf NISSAN TEANA 2014 Service Manual
EC-708
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
• Disconnection or cracks in EVAP purge hose, stu
ck open EVAP canister purge volume control solenoid
valve
• Malf](/manual-img/5/57390/w960_57390-1707.png)
EC-708
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
TROUBLE DIAGNOSIS - SPECIFICATION VALUE
• Disconnection or cracks in EVAP purge hose, stu
ck open EVAP canister purge volume control solenoid
valve
• Malfunctioning seal in rocker cover gasket
• Disconnection, looseness, or cracks in hoses, such as a vacuum hose, connecting to intake air system parts
• Malfunctioning seal in intake air system, etc.
>> GO TO 30.
29.CHECK “A/F ALPHA-B1”, “A/F ALPHA-B2”, AND “B/FUEL SCHDL”
Select “A/F ALPHA-B1”, “A/F ALPHA-B2”, and “B/F UEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and
check that each indication is within the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> Detect malfunctioning part according to EC-987, "Symptom Table"
.
30.CHECK “B/FUEL SCHDL”
Select “B/FUEL SCHDL” in “SPEC” of “DATA MONITOR” mode, and then check that the indication is within
the SP value.
Is the measurement value within the SP value?
YES >> INSPECTION END
NO >> Detect malfunctioning part according to EC-987, "Symptom Table"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1709 of 4801
![NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITEC-709
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009462573
1.CHECK FUSE
Check NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITEC-709
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009462573
1.CHECK FUSE
Check](/manual-img/5/57390/w960_57390-1708.png)
POWER SUPPLY AND GROUND CIRCUITEC-709
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000009462573
1.CHECK FUSE
Check that there is no blowout in the following fuses.
Is the fuse fusing?
YES >> Replace the fuse after repairing the applicable circuit.
NO >> GO TO 2.
2.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E9. Refer to GI-46, "Circuit Inspection"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace ground connection.
3.CHECK ECM GROUND CIRCUIT
1. Disconnect ECM harness connectors.
2. Check the continuity between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK ECM POWER SUPPLY (MAIN)-I
1. Reconnect ECM harness connector.
2. Turn ignition switch ON.
3. Check the voltage between ECM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK ECM POWER SUPPLY (MAIN) CIRCUIT
Location Fuse No. Capacity
IPDM E/R #38 10 A
#45 10 A
+ −Continuity
ECM
Connector Terminal
F78 12
Ground Existed
16
E32 123
124
127
128
ECM Vo l ta g e
Connector +
−
Te r m i n a l
E32 121 128 Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1710 of 4801
![NISSAN TEANA 2014 Service Manual
EC-710
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connectors.
3. Disconnect IPDM E/R harness connector.
4. Check the c NISSAN TEANA 2014 Service Manual
EC-710
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connectors.
3. Disconnect IPDM E/R harness connector.
4. Check the c](/manual-img/5/57390/w960_57390-1709.png)
EC-710
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connectors.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harnes s connector and IPDM E/R harness connector.
5. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
6.CHECK ECM POWER SUPPLY (MAIN)-II
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 7.
7.CHECK ECM RELAY CONTROL SIGNAL
Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 8.
8.CHECK ECM RELAY CONTROL SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harnes s connector and IPDM E/R harness connector.
+−
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal E32 121 E18 13 Existed
ECM ConditionVo l ta g e
(Approx.)
Connector +
−
Te r m i n a l
E32 121 128 After turning ignition switch
OFF, battery voltage will ex-
ist for a few seconds Drop to 0 V
ECM
ConditionVo l ta g e
(Approx.)
+
−
Connector Terminal Connector Terminal
F78 31 E32 128 Ignition switch ON 0 V
Turn ignition switch OFF
and wait at least 10 sec-
onds. Battery voltage
+
−
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal F7831F8472Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1711 of 4801
![NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITEC-711
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
5. Also check harness for short to ground and to power.
Is the inspection result normal?
YES NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITEC-711
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
5. Also check harness for short to ground and to power.
Is the inspection result normal?
YES](/manual-img/5/57390/w960_57390-1710.png)
POWER SUPPLY AND GROUND CIRCUITEC-711
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
5. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace error-detected parts.
9.CHECK IGNITION SWITCH SIGNAL
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 10.
10.CHECK IGNITION SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harness connector and IPDM E/R harness connector.
5. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
11 .CHECK ECM POWER SUPPLY (BACK-UP)
Check the voltage between ECM harness connector terminals.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 12.
12.CHECK ECM POWER SUPPLY (BACK-UP) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harness connector and IPDM E/R harness connector.
ECM
ConditionVoltag e
(Approx.)
Connector +
−
Te r m i n a l
E32 109 128 Ignition switch OFF 0 V
Ignition switch ON Battery voltage
+ −
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal E32 109 E63 21 Existed
ECM Vo l ta g e
+ −
Connector Terminal Connector Terminal F78 26 E32 128 Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1712 of 4801
EC-712
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
5. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
+ −
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal F7826F8358Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
