Page 2257 of 4801

NISSAN TEANA 2014 Service Manual
EX-2
< PRECAUTION >[QR25DE]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951692
The Supplemental Re

Page 2258 of 4801

NISSAN TEANA 2014 Service Manual
PREPARATIONEX-3
< PREPARATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EX
NP
O
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009460681
The actual shapes of the tools may
differ from those ill

Page 2259 of 4801

NISSAN TEANA 2014 Service Manual
EX-4
< PERIODIC MAINTENANCE >[QR25DE]
EXHAUST SYSTEM (QR25DE)
PERIODIC MAINTENANCE
EXHAUST SYSTEM (QR25DE)
Checking Exhaust SystemINFOID:0000000009460683
Check the exhaust pipes, muffler, and mountin

Page 2260 of 4801

NISSAN TEANA 2014 Service Manual
EXHAUST SYSTEM (QR25DE)EX-5
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EX
NP
O
REMOVAL AND INSTALLATION
EXHAUST SYSTEM (QR25DE)
Exploded ViewINFOID:0000000009460684
1. Rear muffle

Page 2261 of 4801

NISSAN TEANA 2014 Service Manual
EX-6
< REMOVAL AND INSTALLATION >[QR25DE]
EXHAUST SYSTEM (QR25DE)
Removal and Installation
INFOID:0000000009460685
WARNING:
• Perform the procedure with the exhaust system fu lly cooled down becau

EX-6
< REMOVAL AND INSTALLATION >[QR25DE]
EXHAUST SYSTEM (QR25DE)
Removal and Installation
INFOID:0000000009460685
WARNING:
• Perform the procedure with the exhaust system fu lly cooled down because the system will be hot
just after the engine is turned off.
• Be careful not to cut your hand on the insulator edges.
CAUTION:
• Use Genuine NISSAN exhaust system parts or equival ent, which are specifically designed for heat
resistance, corrosion resistance, and shape.
REMOVAL
Remove exhaust system components using power tool.
• Remove heated oxygen sensor using Tool as needed.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Always replace exhaust gaskets with new ones when reassembling.
• Before installing a new heated oxygen sensor, cl ean and lube the exhaust tube threads using suit-
able tool.
• Discard any heated oxygen sensor which has been dropped from a height of more than 0.5 m (19.7
in) onto a hard surface such as a co ncrete floor; install a new one.
• Do not over-tighten the heated oxygen sensor. Doing so may damage the heated oxygen sensor,
resulting in the MIL coming on.
• If any mounting insulator is badly deformed, repair or replace it. If deposits such as mud pile up on
the mounting insulator, clean and inspect them.
• When installing the insulator avoid large gaps or interference between the insulator and each
exhaust pipe.
• Remove deposits from the sealing surface of each connection. Connect them securely to avoid
exhaust gas leaks.
• Temporarily tighten the exhaust manifold side nuts and the vehicle side bolts. Check each part for
any interference, and then tighten th e nuts and bolts to specification.
• When installing each mounting rubber, avoid twisting or excessive extension in up/down and right/
left directions.
• Tighten the bolts without causi ng interference with the flange.
Inspection After InstallationINFOID:0000000009460686
• With the engine running, check the exhaust tube joints for exhaust gas leaks and abnormal noise.
• Check that the mounting brackets and mounting insulators are installed properly and free from excessive stress. Improper installation could result in excessive noise, leaks, and vibration.
10. Rear muffler (LH) 11. Rear muffle r bracket (LH) 12. Rear muffler (RH)
13. Chrome exhaust finishers (if equipped)
Tool number : KV10114400 (J-38365)
Oxygen sensor thread cleaner : (J-43897-18)
Oxygen sensor thread cleaner : (J-43897-12)
Revision: November 20132014 Altima NAM

Page 2262 of 4801

NISSAN TEANA 2014 Service Manual
PRECAUTIONSEX-7
< PRECAUTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EX
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:000

Page 2263 of 4801

NISSAN TEANA 2014 Service Manual
EX-8
< PREPARATION >[VQ35DE]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009460688
The actual shapes of the tools may
differ from those illustrated here.
Commercial Service

Page 2264 of 4801

NISSAN TEANA 2014 Service Manual
EXHAUST SYSTEM (VQ35DE)EX-9
< PERIODIC MAINTENANCE > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EX
NP
O
PERIODIC MAINTENANCE
EXHAUST SYSTEM (VQ35DE)
Checking Exhaust SystemINFOID:0000000009460690
Check the ex
