DOOR REQUEST SWITCH
DescriptionINFOID:0000000009461865
Transmits door lock/unlock operation to BCM.
Component Function CheckINFOID:0000000009461866
1.CHECK FUNCTION
With CONSULT
Check door request switch REQ SW-DR, REQ SW-AS in Data Monitor mode.
Is the inspection result normal?
YES >> Door request switch is OK.
NO >> Refer to DLK-129, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461867
Regarding Wiring Diagram information, refer to DLK-61, "Wiring Diagram".
1.CHECK DOOR REQUEST SWITCH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
Monitor item Condition
REQ SW-DR
REQ SW-AS Door request switch is pressed : ON
Door request switch is released : OFF
Te r m i n a l s Door request
switch Condition Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M18 Door request switch
(driver side) 71
Ground Pressed 0
Released
Door request switch (passenger side) 72 Pressed 0
Released
JMKIA0059GB
JMKIA0059GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 898 of 4801

DLK-130
< DTC/CIRCUIT DIAGNOSIS >
DOOR REQUEST SWITCH
2.CHECK DOOR REQUEST SWITCH CIRCUIT
1. Disconnect BCM and front outside handle connector.
2. Check continuity between BCM connector and front outside handle connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and front outside handle.
3.CHECK DOOR REQUEST SWITCH GROUND CIRCUIT
Check continuity between front outside handle connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace front outside handle ground circuit.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5.CHECK DOOR REQUEST SWITCH
Refer to DLK-131, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 6
BCM connector Terminal Front outside
handle connector Terminal Continuity
M18 71 D6 (driver side)
3Yes
72 D106 (passenger side)
BCM connector Terminal GroundContinuity
M18 71
No
72
Front outside
handle
connector Te r m i n a l
GroundContinuity
D6 (driver side) 4Yes
D106 (passenger
side)
Te r m i n a l s Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M18 71
Ground
72
JMKIA0059GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 899 of 4801
DOOR REQUEST SWITCHDLK-131
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Replace malfunctioning front outside handle.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461868
1.CHECK DOOR REQUEST SWITCH
Check front outside handle (request switch).
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunction front outside handle.
Te r m i n a l Door request switch
condition Continuity
Front outside handle (request switch)
34 Pressed Yes
Released No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 900 of 4801

DLK-132
< DTC/CIRCUIT DIAGNOSIS >
TRUNK OPENER REQUEST SWITCH
TRUNK OPENER REQUEST SWITCH
DescriptionINFOID:0000000009461869
Performs trunk lid open request when it is pressed.
Component Function CheckINFOID:0000000009461870
1.CHECK FUNCTION
With CONSULT
Check trunk opener request switch REQ SW -BD/TR in Data Monitor mode.
Is the inspection result normal?
YES >> Trunk opener request switch is OK.
NO >> Refer to DLK-132, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461871
Regarding Wiring Diagram information, refer to DLK-61, "Wiring Diagram".
1.CHECK TRUNK OPENER REQUEST SWITCH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2.CHECK TRUNK OPENER REQUEST SWITCH CIRCUIT
1. Disconnect BCM and trunk opener request switch connector.
2. Check continuity between BCM connector and trunk opener request switch connector.
3. Check continuity between BCM connector and ground.
Monitor item Condition
REQ SW -BD/TR Trunk opener request switch is pressed : ON
Trunk opener request switch is released : OFF
Te r m i n a l s Trunk lid opener request
switch condition Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M19 83 Ground Pressed 0
Released
JPMIA0016GB
BCM connector Terminal Trunk opener request switch
connector Terminal Continuity
M19 83 B33 1 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 901 of 4801

TRUNK OPENER REQUEST SWITCHDLK-133
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and trunk opener request switch.
3.CHECK TRUNK OPENER REQUEST SWITCH GROUND CIRCUIT
Check continuity between trunk opener request switch connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace trunk opener request switch ground circuit.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5.CHECK TRUNK OPENER REQUEST SWITCH
Refer to DLK-133, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 6
NO >> Replace trunk opener request switch.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461872
1.CHECK TRUNK OPENER REQUEST SWITCH
Check trunk opener request switch.
BCM connector Terminal GroundContinuity
M19 83 No
Trunk opener request switch connector Te r m i n a l
Ground Continuity
B33 2 Yes
Te r m i n a l s Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M19 83 Ground
JPMIA0016GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 902 of 4801
DLK-134
< DTC/CIRCUIT DIAGNOSIS >
TRUNK OPENER REQUEST SWITCH
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace trunk opener request switch.
Te r m i n a l Trunk opener request switch
condition Continuity
Trunk opener request switch
12 Pressed Yes
Released No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 903 of 4801

DOOR LOCK ACTUATORDLK-135
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000009461873
Locks/unlocks the door with the signal from BCM.
DRIVER SIDE : Comp onent Function CheckINFOID:0000000009461874
1.CHECK FUNCTION
1. Use CONSULT to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-135, "DRIVER SIDE : Diagnosis Procedure"
.
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000009461875
Regarding Wiring Diagram information, refer to DLK-51, "Wiring Diagram".
1.CHECK OUTPUT SIGNAL
Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> GO TO 2
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM and front door lock actuator driver side connector.
3. Check continuity between BCM connector and front door lock actuator driver side connector.
4. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator LH.
NO >> Repair or replace harness.
Te r m i n a l s
Condition of
door lock and unlock switch Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M21 135
Ground Lock 0
→ Battery voltage → 0
137 Unlock 0 → Battery voltage → 0
BCM connector Terminal Door lock actuator
connector Terminal Continuity
M21 135
D14 1
Ye s
137 2
BCM connector Terminal Continuity M21 135
Ground No
137
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 904 of 4801

DLK-136
< DTC/CIRCUIT DIAGNOSIS >
DOOR LOCK ACTUATOR
3.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000009461876
Locks/unlocks the door with the signal from BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000009461877
1.CHECK FUNCTION
1. Use CONSULT to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LOCK” or “ALL UNLOCK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-136, "PASSENGER SIDE : Diagnosis Procedure"
.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000009461878
Regarding Wiring Diagram information, refer to DLK-51, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR SIGNAL
Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> GO TO 2
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM and front door lock actuator RH connector.
2. Check continuity between BCM connecto r and front door lock actuator RH.
3. Check continuity between BCM connector and ground.
Te r m i n a l s Condition of
door lock and unlock switch Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M21 135
Ground Lock 0
→ Battery voltage → 0
130 Unlock 0 → Battery voltage → 0
BCM connec-
tor Te r m i n a lFront door lock
actuator RH connector Terminal Continuity
M21 135
D108 2
Ye s
130 1
BCM connector Terminal Continuity M21 135
Ground No
130
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
