Page 4305 of 4801

NISSAN TEANA 2014 Service Manual
TM-90
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
U0140 LOST COMMUNICATION (BCM)
U0140 LOST COMMUNICATION (BCM)
DTC LogicINFOID:0000000009464023
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARAT

Page 4306 of 4801

NISSAN TEANA 2014 Service Manual
U0141 LOST COMMUNICATION (BCM A)TM-91
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U0141 LOST COMMUNICATION (BCM A)
DTC LogicINFOID:0000000009464025
DTC DETECTION LOGIC

Page 4307 of 4801

NISSAN TEANA 2014 Service Manual
TM-92
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
U0155 LOST COMMUNICATION (IPC)
U0155 LOST COMMUNI
CATION (IPC)
DTC LogicINFOID:0000000009464027
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARA

Page 4308 of 4801

NISSAN TEANA 2014 Service Manual
U0300 CAN COMMUNICATION DATATM-93
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U0300 CAN COMMUNICATION DATA
DTC LogicINFOID:0000000009464029
DTC DETECTION LOGIC
DTC CONF

Page 4309 of 4801

NISSAN TEANA 2014 Service Manual
TM-94
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464031
CAN (Controller Area Network) is a serial communication
line for real-t

Page 4310 of 4801

NISSAN TEANA 2014 Service Manual
U1117 LOST COMMUNICATION (ABS)TM-95
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
U1117 LOST COMMUNICATION (ABS)
DTC LogicINFOID:0000000009464034
DTC DETECTION LOGIC
DTC

Page 4311 of 4801

NISSAN TEANA 2014 Service Manual
TM-96
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P062F EEPROM
P062F EEPROM
DescriptionINFOID:0000000009464036
TCM compares the calculated value stored in the flash
ROM with the value stored in TCM. If

Page 4312 of 4801

NISSAN TEANA 2014 Service Manual
P0705 TRANSMISSION RANGE SENSOR ATM-97
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0705 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464039
DTC DETECTION LOGIC

P0705 TRANSMISSION RANGE SENSOR ATM-97
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0705 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000009464039
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Turn ignition switch ON.
2. Shift the selector lever through entire positions from “P” to “DS”. (Hold the selector lever at each position
for 5 seconds or more.)
3. Check the first trip DTC.
Is
“P0705” detected?
YES >> Go to TM-97, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464040
1.CHECK TCM INPUT SIGNALS
With CONSULT
1. Turn ignition switch ON.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “D POSITION SW”, “N POSITION SW”, “R POSITION SW”, “P POSITION SW” and “DS RANGE
SW”.
4. Shift the selector lever through entire positions from “P” to “DS” and check ON/OFF of each monitor item.
Without CONSULT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0705 T/M RANGE SENSOR A
[Transmission Range Sensor
A Circuit (PRNDL Input)] When all of the following conditions are satis-
fied and this state is maintained for 2 seconds:
• Two or more range signals simultaneously stay ON continuously
• TCM power supply voltage: More than 11 V • Harness or connector
(Short circuit between transmission
range switch and TCM)
• Transmission range switch
Monitor item Test condition Condition
D POSITION SW Selector lever: “D” position On
Other than the above Off
N POSITION SW Selector lever: “N” position On
Other than the above Off
R POSITION SW Selector lever: “R” position On
Other than the above Off
P POSITION SW Selector lever: “P” position On
Other than the above Off
DS RANGE SW Selector lever: “DS” position On
Other than the above Off
