TM-410
< UNIT DISASSEMBLY AND ASSEMBLY >[CVT: RE0F10E]
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEAL
UNIT DISASSEMBLY AND ASSEMBLY
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEAL
Exploded ViewINFOID:0000000009464375
DisassemblyINFOID:0000000009464376
1. Remove transaxle assembly. Refer to
TM-407, "Removal and Installation".
2. Remove torque converter from transaxle assembly. CAUTION:
Do not damage the bushing on th e inside of torque converter sleeve when removing torque con-
verter.
3. Remove converter housing oil seal using suitable tool. CAUTION:
Be careful not to scratch converter housing.
AssemblyINFOID:0000000009464377
Assembly is in the reverse order of disassembly.
CAUTION:
Do not reuse converter housing oil seal.
NOTE:
Lubricate converter housing oil seal prior to installation.
Transaxle assembly Torque converter Converter housing oil seal
: Always replace after every disassembly.
: Apply CVT Fluid
JSDIA3623ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4626 of 4801
![NISSAN TEANA 2014 Service Manual
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEALTM-411
< UNIT DISASSEMBLY AND ASSEMBLY > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• Drive converter housing oil seal evenly using a drift (A) NISSAN TEANA 2014 Service Manual
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEALTM-411
< UNIT DISASSEMBLY AND ASSEMBLY > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• Drive converter housing oil seal evenly using a drift (A)](/manual-img/5/57390/w960_57390-4625.png)
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEALTM-411
< UNIT DISASSEMBLY AND ASSEMBLY > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• Drive converter housing oil seal evenly using a drift (A) (com- mercial service tool) so that converter housing oil seal protrudes by
the dimension (B) respectively.
Unit: mm (in)
Unit: mm (in)
NOTE:
Converter housing oil seal pulling direction is used as the refer-
ence.
• Attach the pawl of the torque converter to the drive sprocket hole on the transaxle assembly side.
CAUTION:
• Rotate the torque converter fo r installing torque converter.
• Do not damage the bushing inside the torque converter
sleeve when installing the converter housing oil seal.
InspectionINFOID:0000000009464378
INSPECTION AFTER INSTALLATION
Commercial service tool: (A) Outer diameter: 65 (2.56)
Inner diameter: 60 (2.36)
: Transaxle assembly
SCIA7908J
Dimension (B) 1.0 ± 0.5 (0.039 ± 0.020)
SCIA7909J
SCIA7907J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4627 of 4801
TM-412
< UNIT DISASSEMBLY AND ASSEMBLY >[CVT: RE0F10E]
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEAL
• After inserting a torque converter to the CVT, check dimension (A)
with in the reference value limit.
B: Scale
C : Straightedge
Dimension (A) : Refer to TM-413, "Torque Converter".
JPDIA0115ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4628 of 4801
![NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)TM-413
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATI NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)TM-413
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATI](/manual-img/5/57390/w960_57390-4627.png)
SERVICE DATA AND SPECIFICATIONS (SDS)TM-413
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000009464379
*1: Refer to MA-11, "FOR USA AND CANADA : Fluids and Lubricants".
*2: The CVT fluid capacity is the reference value.
Shift CharacteristicsINFOID:0000000009464380
Unit: rpm
CAUTION:
Lock-up is engaged at the vehicle speed of approximately 18 km/h (12 MPH) to 40 km/h (24 MPH).
Stall SpeedINFOID:0000000009464381
Torque ConverterINFOID:0000000009464382
Unit: mm (in)
Heater ThermostatINFOID:0000000009464383
Standard
Reference value
Applied model Engine VQ35DE
Axle 2WD
Transaxle model RE0F10E
Transaxle gear ratio D position 2.436 – 0.384
R position 0.745
Final drive 4.677
Recommended fluid Genuine NISSAN CVT Fluid NS-3
*1
Fluid capacity liter (US qt, Imp qt) Approx. 8.2 (8-5/8, 7-1/4)*2
CAUTION:
• Use only Genuine NISSAN CVT Fluid NS-3. Never mix with other fluid.
• Using CVT fluid other than Genuine NISSAN CVT Fluid NS-3 will deteriorate in driveability and CVT durability, and may dam-
age the CVT, which is not covered by the NISSAN new vehicle limited warranty.
Throttle position Shift pattern Engine speed
At 40 km/h (25 MPH) At 60 km/h (37 MPH)
2/8 “D” position 1,410 – 1,550 1,550 – 1,710
8/8 “D” position 3,610 – 3,990 4,560 – 5,040
Stall speed 2,400 – 2,700 rpm
Distance “A” between the converter housing and torque converter 14.0 (0.55)
Va l v e l i f tMore than 5.0 mm (0.197 in)
Valve opening temperature 71 °C (160 °F)
Minimum valve lift 5.0 mm/85 °C (0.197 in/203 °F)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4629 of 4801

VTL-1
VENTILATION, HEATER & AIR CONDITIONER
C
D E
F
G H
J
K L
M
SECTION VTL
A
B
VTL
N
O P
CONTENTS
VENTILATION SYSTEM
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution for Work ..................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tool ........................................... ......3
Commercial Service Tool ..........................................3
PERIODIC MAINTENANCE ..........................4
IN-CABIN MICROFILTER .............................. .....4
Removal and Installation ...........................................4
SYSTEM DESCRIPTION . .............................5
IN-CABIN MICROFILTER .............................. .....5
Description .......................................................... ......5
REMOVAL AND INSTALLATION ................6
DUCTS AND GRILLES .................................. .....6
Exploded View .................................................... ......6
DEFROSTER NOZZLE .......................................... ......7
DEFROSTER NOZZLE : Removal and Installation
......
7
CENTER VENTILATOR DUCT .............................. ......7
CENTER VENTILATOR DUCT : Removal and In-
stallation .............................................................. ......
7
SIDE DEFROSTER DUCT ..................................... ......7
SIDE DEFROSTER DUCT : Removal and Instal-
lation .................................................................... ......
7
FRONT FLOOR DUCT .......................................... ......8
FRONT FLOOR DUCT : Removal and Installation
- Front Floor Duct ................................................ .....
8
FRONT FLOOR DUCT : Removal and Installation
- Front Floor Connecting Duct ............................. .....
8
FRONT FLOOR DUCT : Removal and Installation
- Front Floor Duct Nozzle .................................... .....
8
ADAPTOR DUCT ................................................... .....8
ADAPTOR DUCT : Removal and Installation -
Adaptor Duct ........................................................ .....
8
ADAPTOR DUCT : Removal and Installation -
Adaptor Extension Duct ....................................... .....
9
REAR CENTER VENTILATOR DUCT ................... .....9
REAR CENTER VENTILATOR DUCT : Removal
and Installation .................................................... .....
9
Exploded View .........................................................10
CENTER VENTILATOR GRILLE ........................... ....10
CENTER VENTILATOR GRILLE : Removal and
Installation ........................................................... ....
11
SIDE VENTILATOR GRILLE ................................. ....11
SIDE VENTILATOR GRILLE : Removal and In-
stallation .............................................................. ....
11
SIDE DEFROSTER GRILLE .................................. ....11
SIDE DEFROSTER GRILLE : Removal and In-
stallation .............................................................. ....
11
REAR CENTER VENTILATOR GRILLE ............... ....12
REAR CENTER VENTILATOR GRILLE : Remov-
al and Installation ................................................. ....
12
BLOWER UNIT .................................................13
BLOWER UNIT ...................................................... ....13
BLOWER UNIT : Exploded View .............................13
BLOWER UNIT : Removal and Installation .............13
BLOWER MOTOR ................................................. ....13
BLOWER MOTOR : Removal and Installation ........13
Revision: November 20132014 Altima NAM
Page 4630 of 4801

VTL-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951791
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000009461571
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: November 20132014 Altima NAM
Page 4631 of 4801
PREPARATIONVTL-3
< PREPARATION >
C
D E
F
G H
J
K L
M A
B
VTL
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000009461572
The actual shapes of the tools may differ from those illustrated here.
Commercial Service ToolINFOID:0000000009461573
Tool number
(TechMate No.)
Tool name Description
—
(J-46534)
Trim Tool Set Removing trim components
AWJIA0483ZZ
Tool name
Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: November 20132014 Altima NAM
Page 4632 of 4801
VTL-4
< PERIODIC MAINTENANCE >
IN-CABIN MICROFILTER
PERIODIC MAINTENANCE
IN-CABIN MICROFILTER
Removal and InstallationINFOID:0000000009461574
REMOVAL
1. Disengage the filter cover tab (1) to remove the filter cover.CAUTION:
Use care when lifting up on th e tab to avoid damaging it.
2. Remove the in-cabin microfilter from the blower unit.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• When installing, handle the filter with extreme care to avoid deforming or damaging the filter.
• If the filter is deformed/damaged when removing , replace it with a new one. A deformed or damaged
filter may affect the du st collecting performance.
ALIIA0636ZZ
Revision: November 20132014 Altima NAM
