Page 969 of 4801
DOOR HANDLEDLK-201
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
CAUTION:
• Check rear door lock cables are properly engaged to inside handle.
• After installation, check rear doo r open/close, lock/unlock operation.
REAR DOOR HANDLE : Removal and Installation - Outside HandleINFOID:0000000009461948
REMOVAL
1. Fully close rear door glass.
2. Remove rear door finisher. Refer to INT-18, "Removal and Installation"
.
3. Remove rear door vapor barrier.
4. Remove door side grommet, and loosen screw that retains the rear door outside handle bracket.
5. While pulling outside handle (1), remove outside handle escutcheon (2).
6. While pulling outside handle (1), slide toward rear of vehicle to remove outside handle.
7. Remove front gasket (1) and rear gasket (2). : Front
JMKIA1467ZZ
JMKIA5342ZZ
AWKIA1997ZZ
JMKIA5889ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 970 of 4801
DLK-202
< REMOVAL AND INSTALLATION >
DOOR HANDLE
8. Slide outside handle bracket toward rear of vehicle to remove.: Front
9. Remove clip and disconnect the outside handle cable from the outside handle bracket.
INSTALLATION
Installation in the reverse order of removal.
Tighten rear door outside handle bracket screw to specified torque.
CAUTION:
• When installing do not reuse rear door outside handle bracket screw. Always replace screw with new
ones when removed.
• Check rear door lock cable is proper ly engaged to outside handle bracket.
• After installation, check rear door open/close, lock/unlock operation.
JMKIA5890ZZ
PIIB5815E
Rear door outside handle
bracket screw 5.8 N·m (0.59 kg-m, 51 in-lb)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 971 of 4801
DOOR LOCKDLK-203
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK
FRONT DOOR LOCK
FRONT DOOR LOCK : Exploded ViewINFOID:0000000009461949
FRONT DOOR LOCK : Removal and InstallationINFOID:0000000009461950
CAUTION:
Before servicing, turn igni tion switch OFF, disconnect both batt ery terminals and wait at least three
minutes.
REMOVAL
1. Remove the front door outside handle. Refer to DLK-198, "FRONT DOOR HANDLE : Removal and Instal-
lation - Outside Handle".
2. Remove the rear glass run.
3. Disconnect the harness connector from the front door lock actuator.
1. Outside handle escutcheon 2. Rear gasket 3. Screw
4. Door key cylinder rod (driver side) 5. Front door lock assembly 6. Cable clip
7. Inside door handle escutcheon 8. Inside handle 9. Outside handle bracket
10. Front gasket 11. Outside handle 12. Door key cylinder assembly (driv- er side only)
Front
ALKIA2713ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 972 of 4801

DLK-204
< REMOVAL AND INSTALLATION >
DOOR LOCK
4. Remove screws, and the door lock assembly.
INSTALLATION
Installation is in the reverse order of removal.
• Tighten front door lock screws to specified torque.
CAUTION:
• Do not reuse inside door handle escutcheon. Replace with new part after removal.
• Do not reuse front door lock assembly screw s. Always replace screws with new ones when
removed.
• Check front door lock cables are properly engage d to inside handle and outside handle bracket.
• When installing door key cylinder rod on the LH front door, be sure to rotate door key cylinder rod
holder until a click is felt.
• After installation, check front doo r open/close, lock/unlock operation.
• Check front door lock assembly for poor lubricatio n. If necessary apply a suitable multi-purpose
grease.
REAR DOOR LOCK
REAR DOOR LOCK : Exploded ViewINFOID:0000000009461951
PIIB5812E
Front door lock screw 5.8 N·m (0.59 kg-m, 51 ft-lb)
ALKIA2714ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 973 of 4801

DOOR LOCKDLK-205
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
REAR DOOR LOCK : Re moval and InstallationINFOID:0000000009461952
REMOVAL
1. Remove the rear door outside handle. Refer to DLK-201, "REAR DOOR HANDLE : Removal and Installa-
tion - Outside Handle".
2. Disconnect the harness connector from the rear door lock actuator.
3. Remove the screws, and the door lock assembly.
INSTALLATION
Installation is in the reverse order of removal.
• Tighten rear door lock screws to specified torque.
CAUTION:
• Do not reuse rear door lock assembly screws. Always replace screws with new ones when removed.
• Check rear door lock cables are properly engage d to inside handle and outside handle bracket.
• After installation, check rear doo r open/close, lock/unlock operation.
• Check rear door lock assembly for poor lubrication. If necessary apply a suitable multi-purpose
grease.
1. Outside handle escutcheon 2. Rear gasket 3. Screw
4. Rear door lock assembly 5. Cable clip 6. Inside handle finisher
7. Inside handle 8. Outside handle bracket 9. Front gasket
10. Outside handle Front
PIIB5812E
Rear door lock screw 5.8 N·m (0.59 kg-m, 51 ft-lb)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 974 of 4801

DLK-206
< REMOVAL AND INSTALLATION >
TRUNK LID
TRUNK LID
TRUNK LID ASSEMBLY
TRUNK LID ASSEMBLY : Exploded ViewINFOID:0000000009461953
TRUNK LID ASSEMBLY : Removal and InstallationINFOID:0000000009461954
CAUTION:
• Use two people when removing or installing trunk lid assembly due to its heavy weight.
• Use protective tape or shop cloths to protect surrounding components from damage during removal
and installation of trunk lid assembly.
REMOVAL
1. Remove trunk lid finisher (if equipped). Refer to INT-33, "TRUNK LID FINISHER : Removal and Installa-
tion".
1. Trunk lid hinge (LH/RH) 2. Torsion bar (LH/RH) 3. Torsion bar clips
4. Trunk lid finisher (if equipped) 5. Emergency release lever handle 6. Emergency release lever clip
7. Emergency release lever cable 8. Trunk lamp switch and trunk re- lease solenoid9. Trunk lid bumpers
10. License plate finisher 11. Rear spoiler (if equipped) 12. Trunk lid
13. Weatherstrip A. Clip Clip
ALKIA2718ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 975 of 4801
TRUNK LIDDLK-207
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
2. Disconnect the harness connectors in the trunk lid assembly (1) and remove the harness clips (A) then pull out harness from the
trunk lid assembly (1).
3. Disconnect rear view camera (2) from rear washer tube (1) then release clip from the truck lid assembly (if necessary).
4. Remove the bolts (A) and the trunk lid assembly (1).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, perform the trunk lid assembly adjustment procedure. Refer to DLK-208, "TRUNK
LID ASSEMBLY : Adjustment".
ALKIA2733ZZ
ALOIA0202ZZ
ALKIA2734ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 976 of 4801
DLK-208
< REMOVAL AND INSTALLATION >
TRUNK LID
TRUNK LID ASSEMBLY : Adjustment
INFOID:0000000009461955
Check the clearance and the surface height between hood and each part by visual inspection and tactile feel.
1. Trunk lid assembly 2. Trunk lid hinge 3. Trunk lid striker
4. Body side outer 5. Rear combination lamp 6. Rear bumper fascia
A. Trunk bolts B. Striker bolts
ALKIA2735ZZ
