Page 4777 of 5135

40187−01
C91925
D30865
AT0103
C91927
40−16
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION WIRE (U151E)
AVENSIS Supplement (RM1045E)
TRANSMISSION WIRE (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 Nm (479 kgfcm, 35 ftlbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.
Page 4778 of 5135
D30866
D30867
D30866
C91927
D30865
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION WIRE (U151E)
40−17
AVENSIS Supplement (RM1045E)
5. REMOVE TRANSMISSION WIRE
(a) Disconnect the transmission wire connectors.
(b) Remove the bolt and transmission wire.
6. INSTALL TRANSMISSION WIRE
(a) Coat an O−ring of the transmission wire connector with
AT F.
(b) Install the transmission wire and bolt.
Torque: 5.4 Nm (55 kgfcm, 48 in.lbf)
7. CONNECT TRANSMISSION WIRE
(a) Coat an O−ring of the ATF temperature sensor with ATF.
(b) Install the ATF temperature sensor with the lock plate and
bolt.
Torque: 6.6 Nm (67 kgfcm, 58 in.lbf)
(c) Connect the 7 shift solenoid valve connectors.
8. INSTALL AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Install the 2 magnets in the oil pan.
(b) Apply seal packing to the 18 bolts.
Seal packing:
THREE BOND1344 or equivalent
Page 4779 of 5135
C91925
40−1 8
−
AUTOMATIC TRANSMISSION / TRANS TRANSMISSION WIRE (U151E)
AVENSIS Supplement (RM1045E)
(c) Install a new gasket, the oil pan and 18 bolts to the trans- axle case.
Torque: 7.8 N m (80 kgf cm, 69 in. lbf)
NOTICE:
Apply seal packing to the bolts and tighten them within 10
minutes of application.
9. ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
1 0. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
11 . RESET MEMORY (SEE PAGE 05 −54 1)
Page 4780 of 5135

141Q9−01
A36642
A13397
A13400
14−56
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
OVERHAUL
1. INSPECT CONNECTING ROD THRUST CLEARANCE
(a) Using a dial indicator, measure the thrust clearance while
moving the connecting rod back and forth.
Standard thrust clearance:
0.160 to 0.362 mm (0.0063 to 0.0143 in.)
Maximum thrust clearance: 0.362 mm (0.0143 in.)
If the thrust clearance is greater than the maximum, replace the
connecting rod assembly(s). If necessary, replace the crank-
shaft.
2. INSPECT CONNECTING ROD OIL CLEARANCE
HINT:
The connecting rod cap bolts are tightened in 2 progressive
steps.
(a) Check that the matchmarks on the connecting rod and
cap are aligned to ensure the correct reassembly.
HINT:
The matchmarks on the connecting rods and caps are for en-
suring the correct reassembly.
(b) Using a 12 mm socket wrench, remove the 2 connecting
rod cap bolts.
(c) Using the 2 removed connecting rod cap bolts, remove
the connecting rod cap and the lower bearing by wiggling
the connecting rod cap right and left.
HINT:
Keep the lower bearing inserted to the connecting rod cap.
(d) Clean the crank pin and bearing.
(e) Check the crank pin and bearing for pitting and scratches.
(f) Lay a strip of Plastigage on the crank pin.
Page 4781 of 5135

Front Mark
A52515
A36644
Mark
1, 2 or 3Mark
1, 2 or 3
A13840
A13469
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
14−57
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
(g) Check that the front mark of the connecting rod cap is fac-
ing in the correct direction.
(h) Apply a light coat of engine oil on the threads and under
the heads of the connecting rod cap bolts.
(i) Install the connecting cap (see step 37).
NOTICE:
Do not turn the crankshaft.
(j) Remove the 2 bolts and connecting rod cap.
(k) Measure the Plastigage at its widest point.
Standard oil clearance:
0.024 to 0.048 mm (0.0009 to 0.0019 in.)
Maximum oil clearance: 0.08 mm (0.0031 in.)
If the crank pin or bearing is damaged, replace the bearings. If
necessary, replace the crankshaft.
HINT:
If replacing a bearing, replace it with one that has the same
number as the connecting rod. There are 3 sizes of standard
bearings: 1, 2 and 3.
Standard bearing center wall thickness:
Mark 11.485 to 1.488 mm (0.0585 to 0.0586 in.)
Mark 21.489 to 1.491 mm (0.0586 to 0.0587 in.)
Mark 31.492 to 1.494 mm (0.0587 to 0.0588 in.)
(l) Completely remove the Plastigage.
3. REMOVE PISTON SUB−ASSY W/CONNECTING ROD
(a) Using a ridge reamer, remove all the carbon from the top
of the cylinder.
(b) Push the piston, connecting rod assembly and upper
bearing through the top of the cylinder block.
HINT:
SKeep the bearing, connecting rod and cap together.
SArrange the piston and connecting rod assemblies in the
correct order.
4. REMOVE CONNECTING ROD BEARING
Page 4782 of 5135

A36647
A13478
A01178
80 to 90_C
A01179
A36645
14−58
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
5. REMOVE PISTON RING SET
(a) Using a piston ring expander, remove the 2 compression
rings.
(b) Remove the 2 side rails and oil ring by hand.
6. REMOVE PISTON PIN HOLE SNAP RING
(a) Using a small screwdriver, pry out the 2 snap rings.
7. REMOVE PISTON
(a) Gradually heat the piston to approximately 80 to 90_C
(176 to 194_F).
(b) Using a plastic−faced hammer and brass bar, lightly tap
out the piston pin and remove the connecting rod.
HINT:
SThe piston and pin are a matched set.
SArrange the pistons, pins, rings, connecting rods and
bearings in the correct order.
8. INSPECT CRANKSHAFT THRUST CLEARANCE
(a) Using a dial indicator, measure the thrust clearance while
prying the crankshaft back and forth with a screwdriver.
Standard thrust clearance:
0.040 to 0.240 mm (0.0016 to 0.0094 in.)
Maximum thrust clearance: 0.30 mm (0.0118 in.)
If the thrust clearance is greater than the maximum, replace the
thrust washers as a set.
Thrust washer thickness:
1.930 to 1.980 mm (0.0760 to 0.0780 in.)
Page 4783 of 5135

A87780
1
2
3
4
5
68
79
10
A87781
A87782
Plastigage
A87783
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
14−59
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
9. INSPECT CRANKSHAFT OIL CLEARANCE
(a) Uniformly loosen and remove the 10 main bearing cap
bolts in the sequence shown in the illustration.
(b) Use 2 removed main bearing cap bolts to remove the 5
main bearing caps and 5 lower bearings.
NOTICE:
Insert the bolts into one of the caps. Ease the cap out by
gently pulling up and applying force toward the front and
back side of the cylinder block, as shown in the illustration.
Take care not to damage the contact surfaces of the cap
and cylinder block.
HINT:
SKeep the lower bearing and main bearing cap together.
SArrange the main bearing caps in the correct order.
(c) Lift out the crankshaft.
HINT:
Keep the upper bearings together with the cylinder block.
(d) Clean each main journal and bearing.
(e) Check each main journal and bearing for pitting and
scratches.
If the journal or bearing is damaged, replace the bearings.
If necessary, replace the crankshaft.
(f) Place the crankshaft on the cylinder block.
(g) Lay a strip of Plastigage across each journal.
(h) Install the main bearing caps (see step 36).
HINT:
Do not turn the crankshaft.
(i) Remove the main bearing cap (see steps (a) to (b)
above).
(j) Measure the Plastigage at its widest point.
Standard oil clearance:
0.017 to 0.040 mm (0.00067 to 0.00157 in.)
Maximum oil clearance: 0.050 mm (0.002 in.)
If the oil clearance is greater than the maximum, replace the
bearings. If necessary, replace the crankshaft.
Page 4784 of 5135

A87784
Number Mark
Number Mark
No. 1
No. 2
No. 3
No. 4
No. 5
14−60
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
(k) If using a standard bearing, replace it with one having the
same number. If the number of the bearing cannot be de-
termined, select the correct bearing by adding together
the numbers imprinted on the cylinder block and crank-
shaft, and then selecting the bearing according to the
chart below. There are 4 sizes of standard bearings: 1, 2,
3 and 4.
Cylinder block
(A)
+
Crankshaft (B)
0to23to56to89to11
Use bearing1234
HINT:
EXAMPLE
Cylinder block 4 (A) + Crankshaft 3 (B) =
Total number 7 (Use bearing 3)
Reference:
ItemMarkSpecified Condition
Cylinder block main journal bore diameter (A)0
1
2
3
4
5
659.000 to 59.002 mm (2.08683 to 2.32291 in.)
59.003 to 59.004 mm (2.08694 to 2.32299 in.)
59.005 to 59.006 mm (2.08701 to 2.32307 in.)
59.007 to 59.009 mm (2.08708 to 2.32318 in.)
59.010 to 59.011 mm (2.08718 to 2.32326 in.)
59.012 to 59.013 mm (2.08725 to 2.32334 in.)
59.014 to 59.016 mm (2.08733 to 2.32346 in.)
Crankshaft main journal diameter (B)0
1
2
3
4
554.999 to 55.000 mm (1.94528 to 2.16535 in.)
54.997 to 54.998 mm (1.94521 to 2.16527 in.)
54.995 to 54.996 mm (1.94514 to 2.16519 in.)
54.993 to 54.994 mm (1.94507 to 2.16511 in.)
54.991 to 54.992 mm (1.94500 to 2.16504 in.)
54.988 to 54.990 mm (1.94493 to 2.16496 in.)
Standard bearing center wall thickness1
2
3
41.993 to 1.996 mm (0.07846 to 0.07858 in.)
1.996 to 1.999 mm (0.07858 to 0.07870 in.)
2.000 to 2.002 mm (0.07874 to 0.07882 in.)
2.003 to 2.005 mm (0.07886 to 0.07894 in.)
(l) Completely remove the Plastigage.
10. REMOVE CRANKSHAFT
(a) Lift out the crankshaft.
(b) Remove the 5 upper main bearings and 2 thrust washers from the cylinder block.
HINT:
Arrange the main bearings and thrust washers in the correct order.
11. REMOVE CRANKSHAFT THRUST WASHER UPPER
12. REMOVE CRANKSHAFT BEARING
HINT:
Arrange the bearings in the correct order.
13. REMOVE CRANKSHAFT BEARING NO.2
HINT:
Arrange the main bearings and thrust washers in the correct order.
14. REMOVE STUD BOLT
