Page 3105 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 650SW±01 E59986 ClawClaw ± LIGHTINGSIDE TURN SIGNAL LAMP ASSY LH 65±21 AVENSIS REPAIR MANUAL (RM1018E) SIDE TURN SIGNAL LAMP ASSY LH REPLACEMENT 1. REMOVE SIDE TURN SIGNAL LAMP ASSY LH (a) Diseng

Page 3106 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 650SV±01 I33423 V LH LineV RH LineV Line Ground H Line ± LIGHTINGHEADLAMP UNIT LH 65±19 AVENSIS REPAIR MANUAL (RM1018E) ADJUSTMENT 1. HEADLIGHT AIM ONLY HINT: Perform aiming adjustment with Low

Page 3107 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual I35248 V LH Line V RH Line V Line90 3 m (9.84 ft) I37308 Low Beam:V LH Line V RH Line 30mm (1.18 in.)84 mm (3.3 in.) H Line6mm (0.23 in.) I37102 High Beam:V LH Line V RH Line H Line I35802Adjusting B

Page 3108 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 650SU±01 I35241 I35242 I35243 I35254 65±16 ± LIGHTING HEADLAMP UNIT LH AVENSIS REPAIR MANUAL (RM1018E) REPLACEMENT 1.REMOVE FRONT SPOILER COVER LH (See page 76±3) 2.REMOVE FRONT SPOILER COVER RH

Page 3109 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual I35255 I35244 I35229 I35245 I36703 ± LIGHTINGHEADLAMP UNIT LH 65±17 AVENSIS REPAIR MANUAL (RM1018E) (b) Release the lock of the set spring and remove the dis- charge headlamp bulb. 7. REMOVE HEADL

Page 3110 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual I36704 65±18 ± LIGHTING HEADLAMP UNIT LH AVENSIS REPAIR MANUAL (RM1018E) (b)Install the headlamp protector retainer with the 2 screws. 11.HEADLIGHT AIM ONLY (See page 65±19)

Page 3111 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 650ST±01 I35226 Headlamp No.2 BulbBulb Socket Socket Cover Bulb Socket Back Cover Headlamp No.1 Bulb Front Turn Signal Lamp Bulb Clearance Lamp Bulb Halogen Headlamp: Discharge Headlamp: Headlamp No.

Page 3112 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 650SR±01 7 8 9 654 3 2 1 10 11 12 13 14 15 16 17I33101 I35771 ± LIGHTINGLIGHTING SYSTEM 65±9 AVENSIS REPAIR MANUAL (RM1018E) INSPECTION 1. HEADLAMP DIMMER SWITCH ASSY (a) Inspect light cont
