Page 4481 of 5135

D30688
ECM
MPX2
MPX1 29
18 E10 11
B8
22 SNOWI14
Integration Relay
8 14
DA B E8
ECT Pattern Select SW
*1: RHD
*2: LHD 4 1 W−B
CH
CF
CA 8
11
6
W−B
IPE10 MPX1
MPX2
*1
*2
B8
(*3) Pattern Select Switch (ECT SNOW Switch)
When the ECT SNOW switch is pushed, the switch contact is made and the ECT SNOW mode is selected.
To cancel the ECT SNOW mode, push the ECT SNOW switch once again. The ECT SNOW mode is automatical-
ly cancelledout when the ignition switch is turned ”OFF”.
*3
Instrument Panel J/B 05−630
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
PATTERN SELECT SWITCH CIRCUIT
CIRCUIT DESCRIPTION
Integration relay receives pattern select switch information, and sends it through the multiplex communica-
tion system to the ECM.
ECT SNOW is the system that operates the throttle motor to control engine output to reduce skidding of the
driving wheels, guarantee takeoff acceleration, driving straightness and turning stability.
WIRING DIAGRAM
05JLL−01
Page 4482 of 5135
![TOYOTA AVENSIS 2005 Service Repair Manual B59192
Wire Harness Side:
(Connector Front View):E8
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−63 1
AVENSIS Supplement (RM1045E)
INSPECTION PROCEDURE
1 DRIVING TEST
TOYOTA AVENSIS 2005 Service Repair Manual B59192
Wire Harness Side:
(Connector Front View):E8
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−63 1
AVENSIS Supplement (RM1045E)
INSPECTION PROCEDURE
1 DRIVING TEST](/manual-img/14/57441/w960_57441-4481.png)
B59192
Wire Harness Side:
(Connector Front View):E8
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−63 1
AVENSIS Supplement (RM1045E)
INSPECTION PROCEDURE
1 DRIVING TEST
(a) Start the engine.
(b) Turn the ECT SNOW switch ”OFF” (Normal drive mode).
(c) Confirm vehicle response by driving from a parked position to fully depressing the accelerator pedal.
(d) Turn the ECT SNOW switch ”ON” and perform the same check as (c).
Confirm that there is a difference between ECT SNOW switch ”ON” and ”OFF”.
HINT:
S Driving test should be done on a paved road (a nonskid road).
S Make sure not to use the TRAC system when testing a vehicle equipped with one.
OK:
There is a difference in acceleration between ”ON” and ”OFF”.
NG Go to step 2
OK
PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
(SEE PAGE 05 −545)
2 CHECK HARNESS AND CONNECTOR(PATTERN SELECT SWITCH ASSY − BODY
GROUND)
(a) Disconnect the connector of pattern select switch.
(b) Measure the resistance according to the value(s) in the
table below.
Standard:
Tester ConnectionSpecified Condition
1− Body groundBelow 1
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR (SEE PAGE 0 1− 32)
OK
Page 4483 of 5135
D30685
Switch Side:
(Connector Front View):
E8
05−632− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
3 INSPECT PATTERN SELECT SWITCH ASSY
(a) Measure the resistance according to the value(s) in the
table below.
Standard:
Switch ConditionTester ConnectionSpecified Condition
Press continuously
Pattern select switch
(SNOW)
1−4Below 1
Release
Pattern select switch
(SNOW)
10 kor higher
NG REPLACE PATTERN SELECT SWITCH ASSY
OK
Page 4484 of 5135
D30751
Instrument Panel J/B AssyVehicle Front Side:
DA
DA
SNOW
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−633
AVENSIS Supplement (RM1045E)
4 CHECK HARNESS AND CONNECTOR(PATTERN SELECT SWITCH ASSY −
INTEGRATION RELAY)
(a) Connect the connector of pattern select switch.
(b) Disconnect the instrument panel J/B assy (integration
relay) connector.
(c) M easur e t he r esist ance bet ween t er m inal SNO W of instrument panel J/B assy (integration relay) connector
and body ground.
Standard:
Switch ConditionTester ConnectionSpecified Condition
Press continuously
Pattern select switch (SNOW)DA− 14 (SNOW) −
Body groundBelow 1
Release
Pattern select switch (SNOW)
10 k or higher
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR (SEE PAGE 0 1− 32)
OK
PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
(SEE PAGE 05 −545)
Page 4485 of 5135
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−625
AVENSIS Supplement (RM1045E)
TRANSMISSION CONTROL SWITCH CIRCUIT
CIRCUIT DESCRIPTION
When moving the shift lever into the S position using the transmission control switch, it is possible to switch
the shift range position between ”1” (first range) and ”5” (fifth range).
Shifting up ”+” once raises one shift range position, and shifting down ”−” lowers one shift range position.
05CW8−02
Page 4486 of 5135
D30750
ECM
SPT1
SFTD
SFTU L
B
R20
21
22 E10
7
1
2
5J17
J/C
W−B(*1)
(*2) A
A S
SFTD
SFTU
E IG 3 R−WT7
Transmission Control SW
Center J/B
Driver Side J/B
I13
Ignition SW
Engine Room J/B No.4
FL MAIN
Battery
*1: LHD
*2 RHDIJIK IPJ15
J/C A AM1IG1 R−W
W−B B−G
G−Y7
1
CA
7
DB
9
DA
1
DH AM1 GAUGE1 IG1Relay
5
13
2 DN
31
1
4D1
4B ALT
21E10
E10
W−B
W−B
CG
R−W 1
5
DH
G−R
G−Y
W−B
B−G R−W
B−G 05−626
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
WIRING DIAGRAM
Page 4487 of 5135
G23398
Wire Harness Side:
(Connector Front View):T7
G23398
Wire Harness Side:
(Connector Front View):
T7
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)05 −627
AVENSIS Supplement (RM 1045E)
INSPECTION PROCEDURE
1 CHECK HARNESS AND CONNECTOR(BATTERY − TRANSMISSION CONTROL
SWITCH)
(a) Disconnect the transmission control switch connector of
shift lock control unit assy.
(b) Measure the voltage according to the value(s) in the table
below.
Standard:
Switch ConditionTester ConnectionSpecified Condition
IG switch ON3− Body ground10to 14V
IG switch OFFBelow 1 V
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR (SEE PAGE 0 1− 32)
OK
2 CHECK HARNESS AND CONNECTOR(TRANSMISSION CONTROL SWITCH −
BODY GROUND)
(a) Measure the resistance according to the value(s) in the
table below.
Standard:
Tester ConnectionSpecified Condition
5− Body groundBelow 1
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR (SEE PAGE 0 1− 32)
OK
Page 4488 of 5135
G28380
Switch Side:
(Connector Front View):
T7
05−628− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
3 INSPECT SHIFT LOCK CONTROL UNIT ASSY(TRANSMISSION CONTROL
SWITCH)
(a) Measure resistance between each terminal of shift lock
control unit assy when the shift lever is moved to each
position.
Standard:
Shift PositionTester ConnectionSpecified Condition
S, ”+” and ”−”3−7Below1
Except S, ”+” and ”−”10kor higher
Press continuously
”+”
(Up shift)
2−5Below1
S10kor higher
Press continuously
”−”
(Down shift)
1−5Below1
S10kor higher
NG REPLACE SHIFT LOCK CONTROL UNIT ASSY
OK
