Page 4033 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A09512
Groove
A56048
A09497
A56046
A87946
Front Mark
(Arrow)
Front Mark
(Protrusion)
− ENGINE MECHANICALCYLINDER BLOCK ASSY (1CD−FTV)(From September,
2003)14−59
1CD−FTV ENGINE REPAIR MANUAL (R

Page 4034 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A09508
A56047
Coil Joint
Oil Ring End
A87947
No. 1
No. 2Code Mark
Code Mark
A87948
Front Mark
(Arrow)No. 1
Compression
Ring
Oil Ring
No. 2
Compression
Ring
Coil
A09511
Front Mark
(Arrow)
Front
Push
14

Page 4035 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A09514
Front Mark
(Protrusion)
A09493
90_
90_
A09490
Painted Mark
Front
− ENGINE MECHANICALCYLINDER BLOCK ASSY (1CD−FTV)(From September,
2003)14−61
1CD−FTV ENGINE REPAIR MANUAL (RM1046E)
(d) M

Page 4036 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031H4−02
− SERVICE SPECIFICATIONSCOOLING
03−21
AVENSIS Supplement (RM1045E)
TORQUE SPECIFICATION
2AZ−FSE:
Part TightenedNmkgfcmftlbf
Water pump x Cylinder block9.09280 in.lbf
Water pump x

Page 4037 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031H3−02
03−20
− SERVICE SPECIFICATIONSCOOLING
AVENSIS Supplement (RM1045E)
COOLING
SERVICE DATA
2AZ−FSE:
Thermostat
Valve opening temperature
Valve lift at 95_C (203_F)
80 to 84_C (176 to 183

Page 4038 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E3−03
− SERVICE SPECIFICATIONSEXHAUST
03−19
AVENSIS Supplement (RM1045E)
TORQUE SPECIFICATION
2AZ−FSE:
Part TightenedNmkgfcmftlbf
Exhaust pipe assy front x Exhaust manifold converter sub

Page 4039 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E2−03
03−18
− SERVICE SPECIFICATIONSEXHAUST
AVENSIS Supplement (RM1045E)
EXHAUST
SERVICE DATA
2AZ−FSE:
Compression spring (Exhaust pipe assy front x Exhaust manifold converter
sub−assy)
F

Page 4040 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031H2−02
03−14
− SERVICE SPECIFICATIONSENGINE MECHANICAL
AVENSIS Supplement (RM1045E)
TORQUE SPECIFICATION
2AZ−FSE:
Part TightenedNmkgfcmftlbf
Front wheel RH1031,05076
Drain plug (M/T)49500

031H2−02
03−14
− SERVICE SPECIFICATIONSENGINE MECHANICAL
AVENSIS Supplement (RM1045E)
TORQUE SPECIFICATION
2AZ−FSE:
Part TightenedNmkgfcmftlbf
Front wheel RH1031,05076
Drain plug (M/T)4950036
Engine hanger No.1 x Cylinder head3838728
Engine hanger No.2 x Cylinder head3838728
Engine coolant temperature sensor x Cylinder head2020815
Knock sensor x Cylinder block2020815
Engine oil pressure switch assy x Cylinder head1515311
Water by−pass pipe No.1 x Cylinder block9.09280 in.lbf
Water by−pass pipe No. 3 x Cylinder block9.09280 in.lbf
Oil cooler pipe x Cylinder block9.09280 in.lbf
Drive shaft bearing bracket x Cylinder block5455140
Oil level gauge guide x Cylinder block9.09280 in.lbf
V−ribbed belt tensioner assy x Timing chain cover6060744
Ignition coil assy x Cylinder head9.09280 in.lbf
Water inlet x Cylinder block9.09280 in.lbf
Exhaust manifold converter x Cylinder head3737827
Exhaust manifold stay x Exhaust manifold converter4444932
Exhaust manifold heat insulator No. 1 x Exhaust manifold converter121229
Surge tank stay No. 1 x Intake manifold2121015
Intake manifold x Cylinder head3030622
Throttle Body bracket x Throttle body2121015
Drive plate & ring gear x Crankshaft981,00072
Transverse engine engine mounting bracket front x Transverse engine en-
gine mounting insulator front8788764
Transverse engine engine mounting bracket rear x Transverse engine engine
mounting insulator rear8788764
Front suspension cross member sub−assy front x Body Bolt
Nut45
133459
1,35633
98
Front suspension brace RH x Frame Bolt A
Bolt B133
801,356
81698
59
Front suspension brace LH x Frame Bolt A
Bolt B133
801,356
81698
59
Transverse engine engine mounting insulator LH x Engine mounting bracket
LH8788764
Transverse engine engine mounting insulator RH x Engine mounting bracket
RH5253038
Engine mounting bracket x No. 2 RH x Transverse engine
engine mounting insulator A
B
52
11 3530
1,15238
83
Vane pump assy x Timing chain cover3737027
Front suspension arm sub−assy lower No. 1 x Lower ball joint1271,29694
Front stabilizer link assy x Front suspension7475555
Floor panel brace front x Floor3030622
Engine service cover bracket RH x Body RHD steering position type9.09280 in.lbf
Cooler bracket x Body LHD steering position type9.09280 in.lbf
Oil reservoir bracket No. 1 x Body8.08271 in.lbf
Return tube sub−assy x Frame8.08271 in.lbf
Radiator reserve tank Sub−assy x Body5.05144 in.lbf
Compressor and magnetic clutch x Cylinder block2525518
Radiator relay block x Frame5.05144 in.lbf
