Page 4137 of 5135

123
5
A79099Circuit Opening Relay Connector
Wire Harness Side:
C8
A83891
Wire Harness Side:
F26
Fuel Pump Resistor Connector
Front View
A67586
Wire Harness Side:
Fuel Pump Connector F25
B16200
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
05−245
AVENSIS Supplement (RM1045E)
10 CHECK HARNESS AND CONNECTOR(CIRCUIT OPENING RELAY−FUEL PUMP
RESISTOR, FUEL PUMP−FUEL PUMP RESISTOR)
(a) Check the harness and the connector between the circuit
opening relay and the fuel pump resistor.
(1) Remove the C8 circuit opening relay.
(2) Disconnect the F26 fuel pump resistor connector.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Circuit opening relay (C8−3)−Fuel pump resistor (F26−2)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Circuit opening relay (C8−3) or Fuel pump resistor (F26−2)
−Body ground10 kor higher
(4) Reinstall the circuit opening relay.
(5) Reconnect the fuel pump resistor connector.
(b) Check the harness and the connector between the fuel
pimp resistor and the fuel pump resistor.
(1) Disconnect the F25 fuel pump connector.
(2) Disconnect the F26 fuel pump resistor connector.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Fuel pump (F25−4)−Fuel pump resistor (F26−1)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Fuel pump (F25−4) or Fuel pump resistor (F26−1)
−Body ground10 kor higher
(4) Reconnect the fuel pump connector.
(5) Reconnect the fuel pump resistor connector.
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR (See page10−65 of Pub. No.
RM1018E AVENSIS)
OK
11INSPECT IG2 RELAY
(a) Remove the IG2 relay from the engine room R/B No. 4.
(b) Check for continuity in the IG2 relay.
Standard:
Tester ConnectionSpecified Condition
1−2Continuity
3−5No Continuity
3−5Continuity
(Apply battery voltage to terminals 1 and 2)
(c) Reinstall the IG2 relay.
Page 4138 of 5135

A79096
Driver Side J/B:
IGN Fuse
A66267
Ignition Switch Connector
Wire Harness Side:
IG2 I13
Front View
A66053A79064IG2 Relay
Engine Room R/B No. 4:
A66054A81706
IG2 Fuse
Engine Room R/B No.1:
2
1 05−246
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
NG REPLACE IG2 RELAY
OK
12 CHECK HARNESS AND CONNECTOR(IGNITION SWITCH−IG2 RELAY, IG2 FUSE
−IG2 RELAY)
(a) Check the harness and the connector between the igni-
tion switch and the IG2 relay.
(1) Inspect the IGN fuse.
SRemove the IGN fuse from the driver side J/B.
SCheck for continuity in the IGN fuse.
Standard: Continuity
SReinstall the IGN fuse.
(2) Disconnect the I13 ignition switch connector.
(3) Remove the IG2 relay from the engine room R/B
No. 4.
(4) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
IG2 (I13−6)−Engine room R/B No. 4 (IG2 relay terminal 1)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
IG2 (I13−6) or Engine room R/B No. 4 (IG2 relay terminal 1)
−Body ground10 kor higher
(5) Reconnect the ignition switch connector.
(6) Reinstall the IG2 relay.
(b) Check the harness and the connector between the IG2
fuse and the IG2 relay.
(1) Remove the IG2 fuse from the engine room R/B No.
1.
(2) Remove the IG2 relay from the engine room R/B
No. 4.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Engine room R/B No. 1 (IG2 fuse terminal 2)−
Engine room R/B No. 4 (IG2 relay terminal 5)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Engine room R/B No. 1 (IG2 fuse terminal 2) or
Engine room R/B No. 4 (IG2 relay terminal 5)−Body ground10 kor higher
(4) Reinstall the IG2 fuse.
(5) Reinstall the IG2 relay.
Page 4139 of 5135

A66053A79064IG2 Relay
Engine Room R/B No. 4:
123
5
A79099Circuit Opening Relay Connector
Wire Harness Side:
C8
A54404
FC
ECM ConnectorE9
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
05−247
AVENSIS Supplement (RM1045E)
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR
OK
13 CHECK HARNESS AND CONNECTOR(IG2 RELAY−CIRCUIT OPENING RELAY,
CIRCUIT OPENING RELAY−ECM)
(a) Check the harness and the connector between the IG2
relay and the circuit opening relay.
(1) Remove the IG2 relay from the engine room R/B
No. 4.
(2) Remove the C8 circuit opening relay.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Engine room R/B No. 4 (IG2 relay terminal 3)−
Circuit opening relay (C8−1)Below 1
Engine room R/B No. 4 (IG2 relay terminal 3)−
Circuit opening relay (C8−5)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Engine room R/B No. 4 (IG2 relay terminal 3) or
Circuit opening relay (C8−1)−Body ground10 kor higher
Engine room R/B No. 4 (IG2 relay terminal 3) or
Circuit opening relay (C8−5)−Body ground10 kor higher
(4) Reinstall the IG2 relay.
(5) Reinstall the circuit opening relay.
(b) Check the harness and the connector between the circuit
opening relay and the ECM.
(1) Remove the C8 circuit opening relay.
(2) Disconnect the E9 ECM connector.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Circuit opening relay (2)−FC (E9−10)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Circuit opening relay (2) or FC (E9−10)−Body ground10 kor higher
(4) Reinstall the circuit opening relay.
(5) Reconnect the ECM connector.
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR
OK
Page 4140 of 5135
A83889
R21Radiator fun Relay Connector
Front View
Wire Harness Side:
A81695
E12
ECM Connector FPR
05−248
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
14 CHECK HARNESS AND CONNECTOR(RADIATOR FAN RELAY−ECM)
(a) Check the harness and the connector between the radia-
tor fan relay and the ECM.
(1) Remove the R21 radiator fan relay.
(2) Disconnect the E12 ECM connector.
(3) Check the resistance between the wire harness
side connectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
Radiator Fan relay (R21−3)−FPR (E12−7)Below 1
Standard (Check for short):
Tester ConnectionSpecified Condition
Radiator Fan relay (R21−3) or FPR (E12−7)−Body ground10 kor higher
(4) Reinstall the radiator fan relay.
(5) Reconnect the ECM connector.
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR
OK
REPLACE ECM (See page10−65 of Pub. No. RM1018E AVENSIS)
Page 4141 of 5135

A76879
IP1I13
Ignition Switch
IGN Driver Side J/B
E9
E11ECM
Battery FL MAINEFI
No. 1
2
B−G2
118
9
18 4DH
2
E9E9
1 12 31 5
EFI
Relay
D
EEBR GR B−W
DA
J/C 1A
J28IGSW
+B2 MREL
E1
Engine Room
J/B No. 41 4A
4BEngine Room
R/B No. 1 1EFI
AM2
1 211
1 2
B−G6
(RHD) IE4 1 (LHD)
B−R B−RB−R
4 4
4
4
4
4Engine Room
R/B No. 4
Engine
Room
R/B No. 4B−Y
B−W
B−R
ECW−B
B−RB−R B−R
(RHD) (LHD)
D J14D J28 (RHD)(LHD)
D J14
D
J28 D J141
E9 +B (RHD)
(LHD)B−W
B−W (RHD)
(LHD)B−W
J26A
J27E
J8
J/CJ/C
CC
IE12
GR
(LHD)(RHD)IP1 IE42
3
AM2 IG2
Engine Room
J/B No. 1 05−236
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
ECM POWER SOURCE CIRCUIT
CIRCUIT DESCRIPTION
When the ignition switch is turned ON, the positive battery voltage is applied to terminal IGSW of the ECM
and the EFI relay (Markied: EFI) control circuit in the ECM sends a signal to terminal MREL of the ECM
switching on the EFI relay.
This signal causes current to flow to the coil, closing the contacts of the EFI relay and supplying power to
terminals +B and +B2 of the ECM.
If the ignition switch is turned OFF, the ECM holds the EFI relay on for maximum of 2 seconds to allow for
the initial setting of the throttle valve.
WIRING DIAGRAM
05CK0−02
Page 4142 of 5135

A67446
E1 (−)+B (+)
ECM Connecter
E11E9
A81698
E1
E11
ECM Connecter
A67446ECM Connecter
E11E9
E1 ( −)IGSW (+)
−
DIAGNOSTICS SFI SYSTEM (2AZ−FSE)
05 −237
AVENSIS Supplement (RM1045E)
INSPECTION PROCEDURE
1 INSPECT ECM(+B VOLTAGE)
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the terminals of the E9 and
E11 ECM connectors.
Standard:
Tester ConnectionSpecified Condition
+B (E9 −1) − E1 (E11 −1)9to 14V
OK PROCEED TO NEXT CIRCUIT INSPECTION
SHOWN IN PROBLEM SYMPTOMS TABLE
(See page 05 −1 0)
NG
2 CHECK HARNESS AND CONNECTOR(ECM −BODY GROUND)
(a) Disconnect the negative ( −) battery terminal.
(b) Disconnect the E11 ECM connectors.
(c) Check the resistance between the wire harness side con- nector.
Standard (Check for open):
Tester ConnectionSpecified Condition
E1 (E11 −1) −Body groundBelow 1
(d) Reconnect the ECM connector.
(e) Reconnect the negative battery terminal.
NG REPAIR OR REPLACE HARNESS OR CONNECTOR
OK
3 INSPECT ECM(IGSW VOLTAGE)
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the terminals of the E9 and E11 ECM connectors.
Standard:
Tester ConnectionSpecified Condition
IGSW (E9 −9) −E1 (E11 −1)9to14V
OK Go to step 6
NG
Page 4143 of 5135

A79096
Driver Side J/B:
IGN Fuse
B68363
I13 LOCK
ACC
ON
START35_ 35_ 55_
A67446ECM Connecter
E11E9
E1 (−)MREL (+)
05−238
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
4 CHECK FUSE(IGN FUSE)
(a) Remove the IGN fuse from the driver side J/B.
(b) Check for continuity in the IGN fuse.
Standard: Continuity
(c) Reinstall the IGN fuse.
NG CHECK FOR SHORT IN ALL HARNESSES AND
COMPONENTS CONNECTED TO FUSE
OK
5 INSPECT IGNITION OR STARTER SWITCH ASSY
(a) Disconnect the I13 ignition switch connector.
(b) Measure the resistance between the connector terminals
shown in the chart below.
Standard:
Switch PositionTester ConnectionSpecified Condition
LOCKAll Terminals10 kor higher
ACC2−3Below 1
ON1−3, 2−3, 4−6Below 1
START1−3, 4−5, 4−6Below 1
(c) Reconnect the ignition switch connector.
NG REPLACE IGNITION OR STARTER SWITCH
ASSY (GO TO NEXT STEP 6 AFTER THE RE-
PLACEMENT)
OK
CHECK AND REPAIR HARNESS AND CONNECTOR(BATTERY−IGNITION SWITCH, IGNITION
SWITCH−ECM)
6 INSPECT ECM(MREL VOLTAGE)
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the terminals of the E9 and
E11 ECM connectors.
Standard:
Tester ConnectionSpecified Condition
MREL (E9−8)−E1 (E11−1)9to14V
NG REPLACE ECM (See page10−65 of Pub. No.
RM1018E AVENSIS)
OK
Page 4144 of 5135
A66054
Engine Room R/B No.1:
EFI Fuse
B16200
A66053A79065
Engine Room R/B No. 4:
EFI No.1 Fuse
− DIAGNOSTICSSFI SYSTEM (2AZ−FSE)
05−239
AVENSIS Supplement (RM1045E)
7 CHECK FUSE(EFI FUSE)
(a) Remove the EFI fuse from the engine room R/B No. 1.
(b) Check for continuity in the EFI fuse.
Standard: Continuity
(c) Reinstall the EFI fuse.
NG CHECK FOR SHORT IN ALL HARNESSES AND
COMPONENTS CONNECTED TO FUSE
OK
8 INSPECT EFI RELAY
(a) Remove the EFI relay from the engine room R/B No. 4.
(b) Check for continuity in the EFI relay.
Standard:
Tester ConnectionSpecified Condition
1−2Continuity
3−5No Continuity
3−5Continuity
(Apply battery voltage to terminals 1 and 2)
(c) Reinstall the EFI relay.
NG REPLACE EFI RELAY
OK
9 CHECK FUSE(EFI NO.1FUSE)
(a) Remove the EFI No. 1 fuse from the engine room R/B No.
4.
(b) Check for continuity in the EFI No. 1 fuse.
Standard: Continuity
(c) Reinstall the EFI No. 1 fuse.
NG CHECK FOR SHORT IN ALL HARNESSES AND
COMPONENTS CONNECTED TO FUSE
OK
